Panasonic CU-2E15PBD Service Manual
Hide thumbs
Also See for CU-2E15PBD:
- Operating instructions manual (52 pages) ,
- Operating instructions manual (52 pages)
Table of Contents
Advertisement
Quick Links
Please file and use this manual together with the service manual for Model No. CS-E7PKDW CS-E9PKDW CS-E12PKDW
CS-E10JD3EA
CS-E10HB4EA
RAC0503011C2 RAC0602011C2
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this service information by anyone else could result in serious injury or death.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
CS-ME10DTEG,
Order
WARNING
PRECAUTION OF LOW TEMPERATURE
No.
PAPAMY1302030CE
Order No: PAPAMY1303101CE
Air Conditioner
Outdoor Unit
CU-2E15PBD
CU-2E18PBD
Destination
Ukraine
Belarus
Kazakhstan
Hong Kong
PHAAM0901093C8
MAC0803024C8
© Panasonic Corporation 2013
Russia
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic CU-2E15PBD
Summary of Contents for Panasonic CU-2E15PBD
- Page 1 PRECAUTION OF LOW TEMPERATURE In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit. © Panasonic Corporation 2013...
-
Page 2: Table Of Contents
PAGE 13.16 Compressor discharge high pressure 1. Safety Precautions ..........3 protection control ........30 2. Specifications ............. 5 14. Servicing Mode ..........31 CU-2E15PBD ..........5 14.1 Pump down operation.........31 CU-2E18PBD ..........7 14.2 Cooling only function ........31 3. Dimensions ............11 15. -
Page 3: Safety Precautions
1. Safety Precautions Read the following “SAFETY PRECAUTIONS” carefully before perform any servicing. Electrical work must be installed or serviced by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model installed. The caution items stated here must be followed because these important contents are related to safety. - Page 4 18. For R410A models, when connecting the piping, do not use any existing (R22) pipes and flare nuts. Using such same may cause abnormally high pressure in the refrigeration cycle (piping), and possibly result in explosion and injury. Use only R410A materials.
-
Page 5: Specifications
2. Specifications CU-2E15PBD Item Unit OUTDOOR UNIT Indoor Unit Combination 2.2kW + 2.2kW Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit) 4.5 (1.5 ~ 5.0) Capacity BTU/h 15300 (5120 ~ 17100) Running Current 5.75 Electrical Cooling Operation Power Input 1.23 (0.25 ~ 1.35) - Page 6 Item Unit OUTDOOR UNIT Dry Bulb Wet Bulb Maximum °C Cooling Minimum °C Indoor Operation Range Maximum °C — Heating Minimum °C — Maximum °C Cooling Minimum °C — Outdoor Operation Range Maximum °C Heating Minimum °C Note Specifications are subject to change without notice for further improvement.
-
Page 7: Cu-2E18Pbd
CU-2E18PBD Item Unit OUTDOOR UNIT Indoor Unit Combination 3.2kW + 3.2kW Power Source 1 Phase, 230V, 50Hz (Power supply from outdoor unit) 5.2 (1.5 ~ 5.4) Capacity BTU/h 17700 (5120 ~ 18400) Running Current 7.10 Electrical Cooling Operation Power Input 1.52 (0.25 ~ 1.58) Data 3.42 (6.00 ~ 3.42) - Page 8 Item Unit OUTDOOR UNIT Dry Bulb Wet Bulb Maximum °C Cooling Minimum °C Indoor Operation Range Maximum °C — Heating Minimum °C — Maximum °C Cooling Minimum °C — Outdoor Operation Range Maximum °C Heating Minimum °C Note Specifications are subject to change without notice for further improvement.
- Page 9 Multi Split Combination Possibility: A single outdoor unit enables air conditioning of up to two separate rooms for CU-2E15PBD, CU-2E18PBD. Indoor Unit : CS-E7/9/12PKDW, CS-E10JD3EA, CS-E10HB4EA Outdoor Unit : CU-2E15PBD...
- Page 10 Indoor Unit : CS-E7/9/12PKDW, CS-E10JD3EA, CS-E10HB4EA, CS-ME10DTEG Outdoor Unit : CU-2E18PBD...
-
Page 11: Dimensions
3. Dimensions... -
Page 12: Refrigeration Cycle Diagram
4. Refrigeration Cycle Diagram... -
Page 13: Block Diagram
5. Block Diagram... -
Page 14: Wiring Connection Diagram
6. Wiring Connection Diagram... -
Page 15: Electronic Circuit Diagram
7. Electronic Circuit Diagram... -
Page 16: Printed Circuit Board
8. Printed Circuit Board Main Printed Circuit Board... -
Page 17: Cpu Printed Circuit Board
CPU Printed Circuit Board... -
Page 18: Cu-2E15Pbd
9. Installation Information CU-2E15PBD 9.1.1 Check Points 9.1.2 The Shapes of the 3-Way Valve Caps of the Outdoor Unit Have Been Changed Accompanying the changes in the shapes of the 3-way valve caps, the tightening method has also been changed. -
Page 19: Cu-2E18Pbd
CU-2E18PBD 9.2.1 Check Points 9.2.2 The Shapes of the 3-Way Valve Caps of the Outdoor Unit Have Been Changed Accompanying the changes in the shapes of the 3-way valve caps, the tightening method has also been changed. Firmly tighten the 3-way valve caps by hand, and then tighten them up by another 30 degrees or so (one-twelfth of a full turn) using a spanner or adjustable spanner. -
Page 20: Installation Instruction
10. Installation Instruction 10.1 Select The Best Location If an awning is built over the unit to prevent direct sunlight or rain, be careful that heat radiation from the condenser is not obstructed. There should not be any animal or plant which could be affected by hot air discharged. -
Page 21: Connect The Piping
10.4 Connect the Piping Connecting The Piping To Indoor Unit Please make flare after inserting flare nut (locate at Do not over tighten, over tightening may cause gas leakage. joint portion of tube assembly) onto the copper Piping size Torque pipe. -
Page 22: Connect The Cable To The Outdoor Unit
2. Connect the center hose of the charging set to a vacuum pump with check valve, or vacuum pump adaptor. 3. Turn on the power switch of the vacuum pump and make sure that the needle in the gauge moves from 0 cmHg (0 MPa) to -76 cmHg (-0.1 MPa). -
Page 23: Piping Insulation
10.7 Piping Insulation 1. Please carry out insulation at pipe connection portion as mentioned in Indoor/Outdoor Unit Installation Diagram. Please wrap the insulated piping end to prevent water from going inside the piping. 2. If drain hose or connecting piping is in the room (where dew may form), please increase the insulation by using POLY-E FOAM with thickness 6mm or above. -
Page 24: Operation Control
11. Operation Control 11.1 Cooling Operation 11.1.1 Outdoor fan control When cooling operation is enabled, based on outdoor ambient temperature, fan motor control will be adjusted according to figure below: 11.1.2 Annual Cooling control This control is to enable cooling operation when outdoor ambient temperature is low. Control start conditions: Cooling operation is activated with compressor ON. -
Page 25: Heating Operation
11.2 Heating Operation 11.2.1 Outdoor fan control When heating operation is enabled, based on outdoor ambient temperature, fan motor control will be adjusted according to figure below for Heating overload control: 11.2.2 Heating Room Temp Sampling Control To improve the judgment accuracy, indoor room temperature sampling starts when any indoor unit has stopped capability supplied (heating thermo-off) during heating operation with compressor ON, outdoor unit will send signal to all thermo-off indoor units to ON fan motor and get room temperature sample. -
Page 26: Simultaneous Operation Control
12. Simultaneous Operation Control Operation modes which can be selected using the remote control unit: Automatic, Cooling, Dry, Heating and e-ion operation mode. Types of operation modes which can be performed simultaneously Cooling operation and Cooling, Dry or e-ion operation. Heating operation and Heating operation. -
Page 27: Protection Control
13. Protection Control 13.1 Freeze Prevention control (Cool) When received freeze prevention signal from indoor unit, the compressor frequency changes according to indoor heat exchanger temperature. When indoor unit request capability OFF due to freeze condition, immediately the capability supply to targeted indoor unit stops. -
Page 28: Cooling Overload Control (Cool)
13.5 Cooling overload control (Cool) This control detect outdoor pipe temperature and perform the compressor frequency restriction during cooling operation. 13.6 Heating overload control (Heat) This control detect indoor pipe temperature and perform the compressor frequency restriction during heating operation. This control detect outdoor ambient temperature and perform the fan speed adjustment during heating operation. -
Page 29: Deice Control
If the running current does not exceed X value for 5 seconds, compressor frequency will increase. However, if total outdoor unit running current exceeds Y value, compressor will be stopped immediately for 3 minutes. CU-2E18PBD CU-2E15PBD Operation Mode X (A) Y (A) -
Page 30: Protection Control
13.13 Compressor Protection Control (Gas leak detection control 1) Control start conditions For 5 minutes, the compressor continuously operates and total current is low. During Cooling or Soft Dry operation: Indoor intake temperature — indoor piping temperature is below 4°C. During Heating operation: Indoor pipe temperature —... -
Page 31: Servicing Mode
14. Servicing Mode 14.1 Pump down operation Operate the pump down process according to the following procedure Confirm the valve on the liquid side and gas side are open. Short the CN-PUMP button on the Service PCB inside the outdoor unit for more than 5 seconds. Pump down (cooling) operation is performed for 15 minutes. -
Page 32: Troubleshooting Guide
15. Troubleshooting Guide 15.1 Self Diagnosis Function... -
Page 34: Disassembly And Assembly Instructions
16. Disassembly and Assembly Instructions WARNING High voltages are generated in the electrical parts area by the capacitor. Ensure that the capacitor has discharged sufficiently before proceeding with repair work. Failure to heed this caution may result in electric shocks. 16.1 Outdoor Unit Removal Procedure Caution! When handling electronic controller, be careful of electrostatic discharge. - Page 35 16.1.4 Removing the Propeller Fan and Fan Motor 1. Remove the cabinet top plate and cabinet front plate. 2. Remove the propeller fan by removing the nut turning clockwise at its center. 3. Disconnect the connector of the fan motor from the control board.
-
Page 36: Technical Data
17. Technical Data 17.1 Operation Characteristics (CU-2E15PBD) 17.1.1 One Indoor Unit Operation... - Page 38 17.1.2 Two Indoor Unit Operation...
- Page 40 17.2 Operation Characteristics (CU-2E18PBD) 17.2.1 One Indoor Unit Operation...
- Page 42 17.2.2 Two Indoor Unit Operation...
-
Page 44: List
18. Exploded View and Replacement Parts List Note The above exploded view is for the purpose of parts disassembly and replacement. The non-numbered parts are not kept as standard service parts. - Page 45 SAFETY REF. NO. DESCRIPTION & NAME Q’TY CU-2E15PBD CU-2E18PBD REMARK CHASSIS ASSY CWD52K1277 ← FAN MOTOR BRACKET CWD541167 ← FAN MOTOR, AC 50W SINGLE ARW6405AC ← SCREW-FAN MOTOR BRACKET CWH551217 ← SCREW-FAN MOTOR MOUNT CWH55252J ← PROPELLER FAN CWH03K1066 ←...
- Page 46 SAFETY REF. NO. DESCRIPTION & NAME Q’TY CU-2E15PBD CU-2E18PBD REMARK OPERATING INSTRUCTION CWF569017 ← INSTALLATION INSTRUCTION CWF615858 ← INSTALLATION INSTRUCTION CWF615859 ← INSTALLATION INSTRUCTION CWF615885 ← INSTALLATION INSTRUCTION CWF615886 ← CONTROL BOARD COVER CWH131595 ← (Note) All parts are supplied from PAPAMY, Malaysia (Vendor Code: 00029488).
