Ditel DPN10RF Datasheet

DINOS PADEL SCOREBOARD
DATA SHEET - QUICK START INSTALLATION
1. Power on:
After connecting with 5V/2A adapter or inserting 1-3 18650 batteries,
press the power button on the scoreboard to turn it on
2. Operation of mode selection（remote control）:
After the scoreboard is powered on, press the power button on the re-
mote control to power off, and press the button EDIT on the remote con-
trol to edit modes .
There are two modes to choose from :P- 11 and P- 12.
(P-11: Tennis scoring mode, P-12: Freely scoring mode).
Press the number keys 1 and 2 to edit.
After editing, press the button ENTER to save data and then the score-
board enters the selected mode.
DISEÑOS Y TECNOLOGÍA, S.A.
Xarol, 6B P.I. Les Guixeres
08915 Badalona (Barcelona) - Spain
Tel. +34 933 394 758
Fax +34 934 903 145
Email: comercial@ditel.es ; web:
DPN10RF
www.ditel.es
20240508
