Summary of Contents for Motion Concepts Matrx Back Interface
- Page 1 Matrx Back Interface for the UANTUM ALANCE EATING YSTEM INSTALLATION INSTRUCTIONS TRD0357, Rev B...
- Page 2 Motion Concepts Dealer, who has the necessary training and equipment to meet your needs, or you may contact Motion Concepts directly for assistance. The more we are able to understand your needs, the better we will be able to meet them.
-
Page 3: Safety Information/Warnings
- 3 - 1.0 SAFETY INFORMATION/WARNINGS PLEASE READ ALL SAFETY INFORMATION THOROUGHLY BEFORE INSTALLATION! 1.1 General Safety Warnings The contents of this manual are based on the expectation that a mobility device expert has fitted the Matrx Back Interface to the user and has assisted the prescribing healthcare professional in the instruction and safe use of this device IMPORTANT! Please be certain read and follow the safety warnings included in your Quantum Power Base Owners/Operators Manual (provided separately) - Page 4 NOT be used as a vehicle seat! • Your Matrx Back Interface (in combination with the OEM wheelchair power base) has not been tested to the requirements of ISO 7176-19:2001 or ANSI/RESNA WC-19 and may not under any circumstances be used as a vehicle seat or to transport the user in a vehicle.
-
Page 5: Weight Capacity
Use of non-approved Motion Concepts accessories may result in serious injury or damage. • Motion Concepts products are specifically designed and manufactured for use in conjunction with Motion Concepts accessories. Accessories designed by other manufacturers have not been tested, and are not recommended for use with Motion Concepts products. -
Page 6: Tools Required For Installation
- 6 - 2.0 MATRX INTERFACE KIT 2.1 Matrx Interface Kit Contents (for Quantum Tru-Balance 3) IMPORTANT! 3 different sizes (thicknesses) of spacers/washers are provided to address any dimensional variations b/w the universal mounting brackets and the back shell to which they are installed. Where necessary, install the most appropriate sized spacers/washers between the mounting brackets and the back shell to eliminate any gaps. -
Page 7: Installation Procedure
- 7 - 4.0 INSTALLATION PROCEDURE 4.1 Removing the Quantum Back Shell 1. Remove the outer cushion/cover from the OEM (Quantum) back shell. 2. Remove and retain the thumb knob* from the Quantum back shell (refer to image A below). If necessary, refer to the Pride Mobility/Quantum Wheelchair Owners Manual (provided separately) for further instructions on removing the existing back shell. -
Page 8: Mounting Bracket Installation
- 8 - 4.0 INSTALLATION PROCEDURE 4.1 Preparing the Pride Mobility/Quantum Wheelchair Base (...cont’d) Remove the three (3) mounting pins/posts from the Quantum recline plate, as indicated in image D below. The original mounting post hardware is no longer required. Quantum Back Mounting Plate remove original... - Page 9 - 9 - 4.0 INSTALLATION PROCEDURE Fig. 1. OUNTING RACKET RIENTATION TANDARD VS NVERTED Mounting Bracket Inverted Bracket Standard Bracket Configuration Configuration Interface Plate FRONT FRONT Fig. 2. NTERFACE LATE SSEMBLY IDTH DJUSTMENT Mounting Brackets adjust to fit Matrx Back widths: 16W - 20W Width Adjustments 1/2”...
- Page 10 4.0 INSTALLATION PROCEDURE Installing the Interface Plate (onto the Quantum Wheelchair) IMPORTANT! For ease of installation the Matrx Back Interface plate must installed onto the Quantum Power Base (Seating System) PRIOR to installation of the Matrx Back. 1. Using the mounting hardware (screws x4) provided, align the (vertical) mounting holes on the Interface Plate...
- Page 11 Install spacers when necessary at each of the mounting pin locations If you have any concerns or questions regarding the Matrx Back Interface Installation, please contact our Technical Service Department for assistance. USA: 888-433-6818 CAN: 800-680-4191...
- Page 12 CANADA Motion Concepts LP Tel (local): 905-695-0134 84 Citation Drive, Unit 1-7 Tel (toll free): 866-748-7943 Concord, Ontario Fax: 905 695 0138 L4K 3C1 Tech Service: 800-680-4191 info@motionconcepts.com www. www.motionconcepts.com Motion Concepts Tel (local): 716-447-0050 700 Ensminger Rd, Suite 112...
