SET SOLAR MRac L Installation Manual

Rail tin roof solar mounting system
Hide thumbs

Advertisement

Table of Contents

Setsolar Installation Manual
MA H47 Rail Tin Roof Solar Mounting
System
 Catalogue
1. Product Introduction ............................................................................................ 2
2. Installation Tool .................................................................................................... 3
3. Components ........................................................................................................... 3
4. System Overview................................................................................................... 4
5. Installation Guide ................................................................................................ 5
6. Maintenance ........................................................................................................ 12
Tel: 021 535 1741 | 021 535 1794 | 021 535 1978 | 021 535 7293
Address: UNIT 1, 10 TECHNO CRESCENT, WP PARK, EPPING, CAPE TOWN 7460
Email: tessa@setsolar.co.za
Web: http://www.setsolar.co.za

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MRac L and is the answer not in the manual?

Questions and answers

Summary of Contents for SET SOLAR MRac L

  • Page 1: Table Of Contents

    Setsolar Installation Manual MA H47 Rail Tin Roof Solar Mounting System  Catalogue 1. Product Introduction .................... 2 2. Installation Tool ....................3 3. Components ......................3 4. System Overview....................4 5. Installation Guide ....................5 6. Maintenance ......................12 Tel: 021 535 1741 | 021 535 1794 | 021 535 1978 | 021 535 7293 Address: UNIT 1, 10 TECHNO CRESCENT, WP PARK, EPPING, CAPE TOWN 7460 Email: tessa@setsolar.co.za...

  • Page 2: Product Introduction

    1. Product Introduction MRac L feet & MA rail H47 mounting system is specially designed by Setsolar for metal roof. The system mainly suitable for metal roof PV systems. The product is consistent with the metal roof, which makes it very tight and has good wind resistance.

  • Page 3: Installation Tool

    2. Installation Tool L-shaped hexagon Adjustable wrench Torque wrench Electrical Tools wrench Laser level Nylon thread Tape measure L-square 3. Components Components MA Rail H47 Spice for MA Rail MA Inter Clamp Kit MA End Clamp Kit L Feet Kit Water-proof Pad Tel: 021 535 1741 | 021 535 1794 | 021 535 1978 | 021 535 7293 Address: UNIT 1, 10 TECHNO CRESCENT, WP PARK, EPPING, CAPE TOWN 7460...

  • Page 4: System Overview

    4. System Overview 1. MA Rail H47 2. MA End Clamp Kit 3. L Feet Kit 4. Spice for MA Rail 5. MA Inter Clamp Kit 6. Water-proof Pad Tel: 021 535 1741 | 021 535 1794 | 021 535 1978 | 021 535 7293 Address: UNIT 1, 10 TECHNO CRESCENT, WP PARK, EPPING, CAPE TOWN 7460 Email: tessa@setsolar.co.za Web: http://www.setsolar.co.za...

  • Page 5: Installation Guide

    5. Installation Guide 5.1 Installation of MA Clamp Kit 5.1.1 The picture on the right shows how to install the MA Clamp. You must ensure that the thread of the hexagon socket bolt does not pass through the bottom of the MA Clamp.
  • Page 6 5.2.2 According to the installation plan, the L Feet is mounted on metal roof with a self-tapping screw as the picture shows. 5.3 Installation of MA Rail H47 5.3.1 According to the plan, if the rail is not long enough, please connect the MA Rail with the Splice for MA Rail as shown on the right, and lock it...
  • Page 7 5.3.3 Place the MA rail on the side of the L Feet support and fasten them with the M8 bolt assembly. The rail connectors are on the same side, as shown on the right The rail connectors are on the same side.
  • Page 8 5.3.4 Install the planned location according to the engineering plan and install all the rails in step four to ensure that the bolts are locked. 5.4 Installation of Solar Panels 5.4.1 According to the plan, put the panel flat on the rail, slide the MA End Clamp Kit, tightly attach the solar panel assembly, and then tightly lock the bolt...
  • Page 9 5.4.3 Then slide another solar panel assembly to the side of the previously installed solar panel assembly and lock the MA inter clamp assembly (recommended torque: 10-12 N·m). Please note that the anti-skid protection device should fall in the middle of the slot of the bottom row rail.
  • Page 10 5.4.5 . Slide the first solar panel in the next row from top to bottom to the row below the corresponding solar panel. Because of the light, some space from the solar panel on the bottom row is required. Inter Clamp Kit (MA) can be used as a separator to keep the solar panel evenly spaced vertically and...
  • Page 11 5.5 Installation of Grounding System 5.5.1 If there are Grounding Clip and Grounding Lug in the project design, please insert Grounding Clip into Mid Clamp Kit before installation (Picture 1), and then install Mid Clamp Kit with Picture 1 Picture 2 Grounding Clip into the rail.

  • Page 12: Maintenance

    6. Maintenance In order to ensure the reliable operation of the solar mounting structure and improve the safety of the equipment, a daily patrolling inspection system should be established in the daily operation and maintenance work. Patrolling inspection should be conducted at least once every month. The purpose of inspection work is to discover hidden troubles in time, prevent them before occurrence, and effectively improve the reliability of solar mounting structure.

This manual is also suitable for:

Ma h47
