- Page 1 Weld Shear MODEL 05100A OPERATION AND MAINTENANCE MANUAL ENG_OMM_WELD_SHEAR_P01 09th November 2021 Partners in excellence...
-
Page 2: Preface
The manual is intended for people who handle and operate the machine. It is originally written in English and translated into the local language by Pandrol. Pandrol reserves the right to change specifications, equipment, instructions and maintenance guidelines without prior notice. -
Page 3: Table Of Contents
8.1. Exclusions to limited warranty 8.2. Limitation of liability Customer information 10. Assembly 10.1. Weld Shear 10.2. Weld Shear Parts List Disclaimer Contact Recycling and Environment OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 3 av 19... -
Page 4: Safety Information
• Pandrol has no control over the tool use or operation once it leaves the plant. Pandrol has no control over operator or maintainer selection. The customer must assume responsibility for the tool suitability for a particular function. -
Page 5: Personal/Safety Equipment
Do not clean or inspectthe tool while it is connected to the power source. Accidental engagement of the tool can cause serious injury. • Always check work area for any trash which my ignite from sparks, weld splatter or slag. • Always check the work area for smoldering ties or trash before leaving site. • Never strike hold downs with any object to loosen shear from the rail. OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 5 av 19... -
Page 6: Qualified Personnel
The machine is only to be used by trained personnel, thoroughly familiar with and trained in general railway workmanship. The equipment should be operated according to the conditions and standard regulations applying to the track they are working on. The equipment must be serviced, maintained, or in any way modified only by trained personnel, who are familiar with the Operation & Maintenance Manual and have received training and information from Pandrol. In order to avoid personal injury and/or material damage, everyone involved with assembling, starting-up or overhaul must possess relevant knowledge of the equipment, its use, maintenance requirements and procedures. OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021... -
Page 7: Summary
4. Summary The Pandrol Weld Shear is lightweight and highly efficient. Spring centered flow control valve permits safe and precise shearing of a Thermite weld. The shield totally protects fittings and hoses. The adjustable hold downs are self locking and will assure a safe clean cut. Fig 1. Fig 2. Fig 3. Flow Pressure Dimensions Weight 5 GPM (19 LPM) 2000 PSI (140 BAR) A - 27" (66.58 cm) 92 lbs (41.73 kg) B - 20" (50.8 cm) C - 13" (33.02 cm) OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021... -
Page 8: Operation
• Place the shear on the rail prior to setting up the weld to adjust the hold down legs. After hold down legs are adjusted, remove shear from rail to prepare weld. OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 8 av 19... -
Page 9: Weld Shear Blade Maintenence
1/32” by moving the cylinder rod adjusting nuts. Retighten cyl-inder rod adjusting nuts, cycle the shear to check gap dimension. Rein-stall and tighten cylinder rod jam nuts. 5.2. Cold weather operation Hydraulic system performance is affected when the temperature drops below 50°F. Therefore, measures should be taken to pre-warm tools and fluids before operating. NOTE! • Refer to operating procedures of this manual before starting OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 9 av 19... -
Page 10: Review Of Hydraulic Principles
If too much pressure builds on the return side, not only is performance effected, but seals may blow. This is why it is very important to direct the flow into the tool correctly. Reversing the hoses to test may result in blown seals, damage to the tool, and personal injury. OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 10 av 19... -
Page 11: Maintenance
7.1. General Maintenance and overhaul is to be carried out by qualified personnel only Warranty is based on parts and spares delivered by Pandrol. Check tools DAILY for proper operation, leaks, or damage. Inspect hoses DAILY. Replace cut, burned, or otherwise damaged hoses. -
Page 12: Warning Labels And Information Symbols
7.2. Warning labels and information symbols Below are examples of warning labels and information symbols on the machine. If any of these labels become damaged or lost, they are to be replaced with new original warning labels that are available from Pandrol. OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 12 av 19... -
Page 13: Limited Warranty
8. Limited warranty Pandrol, INC warrants to the original purchase of this product that the product will be free from defects in material and workmanship for the period of one (1) year after the delivery of such product to the customer. Other equipment and parts used, but not manufactured by Pandrol are covered directly by the warranty of the manufacturer of those products. -
Page 14: Customer Information
9. Customer information Name Company Serial # of your Pandrol tool Upon receiving your Pandrol tool, make sure to list serial number above so that a good record is kept for order information. Pandrol hydraulic tool list All Pandrol Hydraulic Tools operate at 5 GPM (19 LPM) or 10 GPM (38 LPM) @ 2000 PSI (140 BAR) Power units: 00100K – Gasoline powered (1) 10 GPM or (2) 5 GPM circuits... - Page 15 Track tools: 03900A – Reversing rail saw 05100A & 05100B – Power weld shear 03500 – Self feed rail drill 04500D – 1/2” Hydraulic drill impact wrench 08200 – Tamper 02800A – 60 Ton bridge spreader 01200 – Spring anchor applicator 01100A – Spike puller (Single, 2 stage & trigger versions available) 00800A – 16” Rail saw 05000 – Hand pump weld shear 02500 – 10 GPM 1” Impact wrench 08300 – Spike driver 01600A – 5 GPM 1” Impact wrench 01100RM – Light-weight spike puller Other products: Hydraulic manifolds...
-
Page 16: Assembly
10. Assembly 10.1. Parts diagram OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 16 av 19... -
Page 17: Weld Shear Parts List
10.2. Parts list OPERATION AND MAINTENANCE MANUAL I ENG_OMM_WELD_SHEAR_P01 I 09th November 2021 @Pandrol 2021 17 av 19... -
Page 18: Disclaimer
11. Disclaimer Pandrol exempts itself from liability in the event of usage that deviates from that recommended in this manual. 12. Contact Address Phone Internet and E-mail www.Pandrol.com 13. Recycling and Environment Sustainable environment is a great part of Pandrol. - Page 19 Find out more at pandrol.com Pandrol ©Pandrol Partners in excellence...
