Summary of Contents for ClearStream 1000NCD
- Page 1 OWNER’S MANUAL • PARTS LIST • OPERATING MANUAL FLOW DIAGRAM • INSTALLATION INSTRUCTIONS DESIGN DRAWINGS AND SPECIFICATIONS SERVICE POLICY• LIMITED WARRANTY MODEL 1000NCD 1000GPD MODEL 1200NCD 1200GPD MODEL 1500NCD 1500GPD CLASS 1 NSF/ANSI 40...
-
Page 2: Process Description
Class 1 with a 30-day average of <25mg/l CBOD and <30mg/l TSS. Actual NSF test results used to determine if Clearstream met Standard 40 requirements averaged 6mg/l BOD5 and 9 mg/l TSS. When Clearstream Model 1100 Spin Filter Assembly was utilized in the Standard 40 Test the results averaged 5mg/l BOD5 and 6mg/l TSS. - Page 3 In the event you experience a problem with your Clearstream Aerobic Treatment System or if service is required, you may reference the Clearstream Control Panel Cover for the name, address and phone number of a local service person that can provide service for your Clearstream Unit.
- Page 4 4. The proper operation of this or any other sewage treatment system depends upon the proper organic loading and the life of the micro-organisms inside the system. Clearstream is not responsible for the in-field operation of a system, other than the mechanical and structural workings of the system itself.
- Page 5 5. When wastewater discharge, into a Clearstream Unit, is seasonal or intermittent to a point that the owner wishes to turn off the electricity (for more than (3) months) to the aerator, the aerator inlet and outlet should be sealed to keep out moisture until the unit is ready to be restarted.
- Page 6 4. Make sure the inlet 4” Sch. 40 PVC pipe is aligned properly to incoming sewage line. 5. For the Clearstream Unit to function properly, the tank must be level. To properly level the tank, lay a three (3) foot level across the tank in several directions. Shift the tank in the hole, as necessary, to make the tank level in all directions.
-
Page 7: Start-Up Procedures
10. For below normal grade installations a Clearstream 20-inch diameter riser may be used. In no case shall more than 18” of maximum riser depth be used on a Clearstream Unit to bring the access covers above the final grade. All risers must be sealed with silicone to prevent ground water intrusion before back-fill is completed. - Page 8 Clearstream control panel. Move it to the on position if it is off. The Clearstream standard control panel has two breakers inside and both must be in the on position. If the system does not come on when the main breaker is turned on DO NOT open the Clearstream control panel.
- Page 9 4. Proper airflow is crucial to the operation of your Clearstream therefore an inspection visual or audible means for the airflow to the aeration chamber is a must. Use of a Clearstream model A2800 Air Tester is recommended. Clearstream has a diffuser system that can get plugged when not in use for extended periods.
- Page 10 SURGE CONTROL WEIR CLARIFIER AIR LINE CONDUIT AERATION CHAMBER TWO (2) DIFFUSERS WALL THICKNESS DIMENSIONS: MODELS NOTE: SOME MODELS MAY NOT BE 1000NCD 75" 146" 60" 143" 3" 58" 18" AVAILABLE AT ALL LOCATIONS. 1200NCD 151" 82" 153" 60" 58"...
- Page 11 CS-114 11. PLASTIC 20" RISER EXTENSION CS-116A (2"0, B (6"), C (12") COMPONENT PARTS MAY BE OBTAINED FROM YOUR LOCAL SERVICING DEALER P.O. BOX 705 BEAUMONT, TX 77726 800-586-3656 CLEARSTREAM INLET OUTLET 3, 4 CLEARSTREAM CLEARSTREAM NCD 1000-1500 SERIES OWNERS MANUAL PAGE 10...
-
Page 12: Specifications
SPECIFICATIONS: Clearstream Units Model 1000NCD Treatment Capacity 1000 G.P.D. BOD Loading 2.5 lbs BOD Aerator (Dual CS-103ET) 4.8 scfm Control Panel (Model CS-114A, AP, AT,AN) Raintight Electrical 120vac/60Hz/1.5A/164 watts Model 1200NCD Treatment Capacity 1200 G.P.D. BOD Loading 3.0 lbs BOD Aerator (Dual CS-103ET) 5.6 scfm... -
Page 13: Limited Warranty
In no event shall Clearstream be responsible for delay or damages of any kind or character resulting from, or caused directly or indirectly by, defective component or materials manufactured by others. - Page 14 CLEARSTREAM WASTEWATER SYSTEMS, INC. P 0 . Box 7568 • Beaumont, Texas 77726-7568 Phone: (409) 755-1500 • Fax: (409) 755-6500 • www.clearstreamsystems.com...
