Installation Instructions
ARTISAN ROTARY DIMMER WITH INTEGRAL ON/OFF SWITCH
Thank you for purchasing this quality MFL product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this dimmer. Please keep instructions for future reference.
Warranty
• This dimmer is covered by a 5-year warranty. The warranty is from the date of purchase, not the date of installation.
• If the dimmer is not installed by a licensed electrician, the warranty will be void.
• Please retain proof of purchase and evidence of installation by a licensed electrician for any warranty enquiries.
• Warranty will be void if there is any damage due to improper usage or modification to the dimmer.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.
Installation Requirements
•
Must be wired and installed by a licensed electrician and in accordance to the current local and national
wiring rules. AS/NZS 3000 Electrical Installations (the latest edition).
•
This MFL dimmer is designed for use with Lucci, MFL by Masson and Made by Mayfair branded families of
dimmable LED luminaires. Where the loads are on the same electrical circuit, it must be Mains 240V dimmable
LED retrofit luminaries which have a dimmable LED driver.
NOTE: A dimmable electronic transformer is not considered to be a dimmable LED Driver.
•
Problems encountered when using other types of dimmable 240V luminaires NOT recommended in this
installation guideline are NOT covered by the warranty.
•
Do not exceed the rated output load listed below:
For Mains 240V LED load: Max. 150W
-
For Mains 240V Halogen / Incandescent load: Max. 300W
-
ELV halogen with dimmable converter/transformer: Max. 300VA
-
•
Not suitable for inductive load, non-dimmable load, mixed loads and ELV halogen with iron core transformers.
•
Do not exceed rated power input specification.
•
This product is suitable for indoor use only.
•
Only the front cover of the rotary dimmer is rated IP44 after it is fully installed. This must be maintained during
installation. NOTE: The recessed parts of the rotary dimmer are rated IP20.
Installation Preparation
Before carrying out the installation the following must be considered:
-
An isolation wall switch must be included in the wiring installation. The isolation wall switch allows disconnecting
of the dimmer and loads from the mains 240VAC power during maintenance and cleaning of the connected load.
This dimmer does not provide full disconnection/off-state. The circuit on the load side of the dimmer should be
.
considered live
-
Ensure the power to the electrical circuit is switched OFF.
-
All electrical wiring connection & disconnection must be in accordance with Australian & New Zealand wiring rules
e.g. AS/NZS 3000 (the latest edition).
CAUTION:
For your safety, this electronic dimmer must be installed by a licensed electrician.
1 | P a g e
SKU# 197015, 197016, 197017, 197018
Rated Voltage 220-240V~ 50Hz
v 1 . 0 ( 0 8 / 2 0 2 2 )
