Summary of Contents for Silhouette Auto Sheet Feeder
- Page 1 Auto Sheet Feeder User Manual...
-
Page 2: Table Of Contents
Kiss-cut ..........................................17 Pop-out Cut ......................................... 18 Troubleshooting ............................19 Material Is Jammed in the Auto Sheet Feeder ............................19 Material Is Not Ejected from the Cutting Machine ..........................20 Material Is Not Loading Smoothly ................................20 Safety Precautions ..........................21... -
Page 3: About The Auto Sheet Feeder
Silhouette cutting machine. Place up to 20 sheets of material into the top tray and set the number of copies to be cut in Silhouette Studio®. Then, the Auto Sheet Feeder loads each sheet into the cutting machine for a seamless, matless cut job. -
Page 4: Machine Parts
6. Cover Tabs—Levers for opening the lid at the top of the machine. 7. Paper Guides—Adjust to match the material width being used. 8. Support Tray—An extendable tray that supports the material to be loaded. 9. Feet—Adjusts the height of the Auto Sheet Feeder when used with the Cameo® 4. -
Page 5: Register Your Machine
The first thing to do is sign in, or create a Silhouette account if necessary, and register your machine. If you have an account, input your login credentials and click “Sign In.”... -
Page 6: Connect The Auto Sheet Feeder
Reminder: The Auto Sheet Feeder is only compatible with the Silhouette Portrait® 3 and Cameo® 4. This model is incompatible with the Cameo® 4 Plus and Cameo® 4 Pro. The Auto Sheet Feeder A3 Plus is needed for use with the Cameo® 4 Plus and Cameo®... - Page 7 Silhouette Auto Sheet Feeder User Manual Ensure that the feet at the front of the Auto Sheet Feeder are tucked up into the machine. These feet only need to be extended when the Auto Sheet Feeder is connected to the Cameo® 4, not with the Portrait® 3.
-
Page 8: Cameo® 4 Setup
Next, place the Auto Sheet Feeder onto the left and right pegs on the positioning base. The Auto Sheet Feeder should be stable and firmly in place. If the Auto Sheet Feeder shifts out of place at any point, it may need to be repositioned on the positioning base. - Page 9 Silhouette Auto Sheet Feeder User Manual Use the power divider cable included with the Auto Sheet Feeder to connect the machine to the Cameo® 4. Plug the AC cable that came with your Cameo® 4 into the base of the power divider cable, then into your power outlet.
-
Page 10: Prepare The Auto Sheet Feeder
Turn On the Auto Sheet Feeder Turn the Auto Sheet Feeder on by pressing the power button on the right side of the machine. The machine will make a quick whirring sound as it starts up, and the light will turn green. You will also need to turn on your cutting machine. -
Page 11: Load Material
If you meet resistance while loading material into the Auto Sheet Feeder, do not try to force it through the machine. Media will not fully roll through the machine when first loaded into the Auto Sheet Feeder. You may also be trying to load too many sheets at once;... -
Page 12: Download And Install Silhouette Studio
Download and Install Silhouette Studio® If you already own a Silhouette cutting machine, which is required to operate the Silhouette Auto Sheet Feeder, you do not need to reinstall Silhouette Studio®. Instead, confirm that Silhouette Studio® is updated to the latest version. The Auto Sheet Feeder is only compatible with versions 4.5 and higher. -
Page 13: Navigate Silhouette Studio
When you open Silhouette Studio® with the Auto Sheet Feeder connected or turn on the machine with the software open, you will receive a pop-up asking if you want to set the Auto Sheet Feeder as your active machine. Select “Yes” in order to access the needed features for use with the Auto Sheet Feeder. -
Page 14: Print & Cut
Silhouette machine for cutting. This is done using registration marks, which are printed on the corners of your page. Print & Cut can be used without an Auto Sheet Feeder, but cutting multiple Print & Cut pages is one of the most common machine uses. - Page 15 A bleed is a small border that is printed around the cut lines that matches your design. This bleed accounts for any marginal differences between your printed design and where your Silhouette machine will cut. It is most commonly used for designs with a printed color that extends to the cut line so there won’t be any thin border of the unprinted...
-
Page 16: Barcodes
Auto Sheet Feeder to the software regardless of which edition is being used. By printing barcodes onto your Print & Cut projects, you can load different cut jobs into the Auto Sheet Feeder at once. The cutting machine scans each page as it is loaded into the machine. If a barcode is present, the Silhouette machine can cut files saved to your Library without needing to open them. -
Page 17: Send Panel
Feeder. Before hitting “Send,” finalize all of this information so that it matches your material and desired cut settings. When the Auto Sheet Feeder is set as the active machine, you will see one small change in the Send Panel. Next to the “Send”... -
Page 18: Cut Designs
If your Auto Sheet Feeder is set up properly, the Send Panel should show your machine name as “Portrait 3 with Auto Sheet Feeder (A4)” or “Cameo 4 with Auto Sheet Feeder (A4). The status will read “Ready to load.” With all of these settings correct and the number of copies set, you are ready to send the cut job to the machine. -
Page 19: Kiss-Cut
There are two types of matless cutting: kiss-cut and pop-out cut. A kiss-cut is used when you are cutting materials that have a backing, while pop-out cuts slice all the way through a range of materials. When using the Auto Sheet Feeder, you must use one of these two matless cutting options. -
Page 20: Pop-Out Cut
Pop-out cuts will cut all the way through material but leave the shape in place using strategic perforation cuts. Because of a channel that runs under the blade area, your Silhouette machine can cut all the way through the material without a cutting mat. -
Page 21: Troubleshooting
Material Is Jammed in the Auto Sheet Feeder First, turn off the Auto Sheet Feeder. Then, pull the two tabs at the base of the cover towards you to release the lid. This will allow you to pull the media out of the Auto Sheet Feeder. -
Page 22: Material Is Not Ejected From The Cutting Machine
To clean the inside of the Auto Sheet Feeder, use a standard printer cleaning sheet to remove any dust. Turn off the Auto Sheet Feeder and pull the two cover tabs towards you to open the lid. Insert the cleaning sheet and close the cover. -
Page 23: Safety Precautions
Do not use the Auto Sheet Feeder in a location subject to excessive vibration or electrical noise. Do not use or store the Auto Sheet Feeder in a location exposed to direct sunlight or a direct draft of an air conditioner or heater. -
Page 24: Where To Find More Information
Silhouette Auto Sheet Feeder User Manual Where to Find More Information Complete Software Manual View the complete, illustrated User’s Manual within Silhouette Studio® by clicking Help > User’s Manual. Website Visit silhouetteamerica.com to access software updates, troubleshooting guides, FAQs, and other tutorials.
