AMERICAN IMAGE DISPLAYS Promotional Umbrella Quick Start Manual

www.american-image.com
Promotional Umbrella
The Umbrella is ideal for outdoor fairs, sporting events, restaurants, bars, concerts,
festivals and more. Can be used for commercial or residential use. Strong, solid,
stable, wind-resistant & durable. Graphics are long-lasting and can endure exposure
to outdoor elements.
Stock Colors
Burgundy
Hunter Green
Off-white
We are continually improving and modifying our product range and reserve the right to vary the specifications without prior
notice. All dimensions and weights quoted are approximate and we accept no responsibility for variance. E&OE. See Graphic
Templates for graphic bleed specifications.
01/28/14
Carry bag included with frame
features and benefits:
- NEW
- Promotional umbrella can be used for
commercial or residential use
- Steel poles and arms are white
- Black base sold seperately
- Overall height with umbrella = 93"h
dimensions:
Hardware
Assembled unit:
Umbrella Frame: 104.625"dia. x 93"h
2718mm(dia.) x 2388mm(h)
Weight (includes graphic):
14 lbs / 6.35 kgs
Weight – Base:
45 lbs / 20.4 kgs
Shipping
Shipping dimensions - ships in 2 boxes:
Umbrella: 57.87"l x 5.9"w x 5.9"h
1470mm(l) x 150mm(w) x 150mm(h)
Base: 22.64"l x 20.47"w x 4.92"h
575mm(l) x 520mm(w) x 125mm(h)
Approx. shipping weight:
Umbrella: 11 lbs / 5 kgs (frame only)
Base: 44.09 lbs / 20 kgs
800-676-3976 • 425-556-9511 • fax 425-556-9611
- Carry bag included
- One year limited hardware warranty
against manufacturer defects
- Six month graphics limited warranty
- Usage in adverse weather voids all warranties
Graphics
Total graphic area w/bleed:
102.5"w x 102.5"h
2603.5mm(w) x 2603.5mm(h)
Single panel safe zone:
36"w x 42.6"h
914.4mm(w) x 1082mm(h)
Top circle visual area:
18"w x 18"h
457mm(w) x 457mm(h)
Refer to related graphic template for
more information.
additional information:
Custom digital print graphic material:
6.5 oz outdoor canvas
Stock color options: off-white, hunter green,
burgundy
Color swatch provided is closest match
• 4054 148th Ave. NE • Redmond, WA 98052
