- Page 1 USER MANUAL S100 SART Search and Rescue Transponder English www.oceansignal.com...
- Page 2 Ocean Signal Ltd. For permission requests or inquiries, please contact help@oceansignal.com Ocean Signal Ltd. reserves the right to change or update the contents of this manual without prior notice. While every effort has been made to ensure the accuracy of the information provided, Ocean Signal Ltd.
- Page 3 S100 SART USER MANUAL IN CASE OF EMERGENCY Press release Break off clear Holding the green Whilst holding latch and remove protective cover switch to the the red switch from bracket. over the the green left, push the red down, release and red switches.
-
Page 4: Table Of Contents
S100 SART USER MANUAL Contents GENERALITES Exposition aux rayonnements électromagnétiques Important Contenu du S100 SART S100 – VUE GENERALE INSTALLATION Installation du Support Installation de la batterie UTILISATION Activation Indications optiques lors de l’activation Déploiement Désactivation TEST Test de fonctionnalité BATTERIES Remplacement de la pile ANNEXES... -
Page 5: Generalites
S100 SART USER MANUAL GENERAL Exposure to RF Electromagnetic Energy This product has been evaluated for compliance with the FCC RF exposure limits given in CFR 47 part 2.1093: Portable Devices Warnings Always operate the S100 SART with any part of the device at least 6cm (2.4in) away from your body The S100 SART is designed for use in emergency only. -
Page 6: S100 - Vue Generale
S100 SART USER MANUAL S100 SART OVERVIEW 1. Lanyard Attachment Point 2. Test Switch 3. Activation Switch 4. Clear Protective Cover 5. Indicator LED 6. Interlock Switch 7. Attachment Point for Optional Pole 8. Battery Module with Expiry Date 912S-00678 v02.00 29/04/2024... -
Page 7: Installation
Although the S100 SART is rugged and waterproof, Ocean Signal recommends mounting the unit in a protected position whenever possible. Do not mount the S100 SART closer than 1 meter to any steering compass as this may affect the accuracy of the compass. -
Page 8: Installation De La Batterie
S100 SART USER MANUAL Battery Installation The battery pack is retained by a single hex head screw using the 3mm hex key provided. Insert the battery pack into the bottom of the S100 SART, ensuring that the rubber seal is correctly in position. Tighten the screw until the battery is fully home within the S100 SART body, torque not exceeding 0.5Nm. -
Page 9: Indications Optiques Lors De L'activation
S100 SART USER MANUAL Optical Indications on Activation During operation, the red LED next to the Test switch will flash once every 2-3 seconds to indicate the SART is operational: When activated by a received radar pulse the red LED will start flashing rapidly: Deployment The lanyard should be unwound and tied securely to the life raft to ensure the... -
Page 10: Désactivation
Release the green switch. It is not possible for the user to replace the clear protective cover. Return the S100 SART to an Ocean Signal authorised service centre for replacement. TESTING Function test This test should be carried out once per year. -
Page 11: Batteries
The battery should be replaced before the expiry date has passed to ensure reliable operation and full capacity in emergency situations. Always use batteries manufactured by Ocean Signal. Failure to do so will invalidate the type approval and may mean the unit does not operate correctly in a distress situation. -
Page 12: Remplacement De La Pile
S100 SART USER MANUAL Battery Replacement The battery may be changed by the user, although commercial vessels may be subject to local regulations relating to Shore Based Maintenance that prevent this. Remove the S100 SART from its mounting bracket and turn it over. The battery pack is retained by a single hex head screw. -
Page 13: Annexes
Make sure the optional telescopic pole (if provided) is still present and is free to extend. Check for correct SART operation using the Test Mode (section 5). If the S100 SART appears to fail testing, contact a service representative at Ocean Signal. Battery Safety Information Manufacturer name: LB3S Volts: 3.0V nominal... -
Page 14: Transportation
The (LB3S) SART battery module has been tested in accordance with subsection 38.3 of part III of the UN Manual of Tests and Criteria. Summary test reports are available from Ocean Signal on request. This battery module should be transported by air in accordance with the IATA dangerous goods regulations: class 9, UN3090, proper name “Lithium metal batteries”... -
Page 15: Approvals
Your S100 SART is warranted against manufacturing defects in materials and workmanship for a period of two years from date of purchase. Ocean Signal will, at its discretion, repair or replace a faulty product free of charge, including return carriage costs to the owner. - Page 16 Ocean Signal Ltd. Unit 4, Ocivan Way Margate CT9 4NN United Kingdom help@oceansignal.com www.oceansignal.com...
