ELITEGROUP COMPUTER SYSTEMS CO., LTD.
CONTENTS
1. INTRODUCTION
1.1 FEATURES
2.PRECAUTIONS FOR INSTALLATION, OPERATION AND HANDLING
1. INTRODUCTION
1.1 FEATURES
. 6X rotational speed, 900KBytes/s data transfer rate.
. Half height, 5.25 inch form factor.
. Motorized tray loading, Open/Close is controlled by the EJECT button or by a software command.
. CD-DA, CD-ROM/XA, Photo-CD(Multi-Session), CD-I/VIDEO CD,CD Plus Compatible.
. Audio playback capability -- controlled by a software utility.
. MPC level 2 compliant.
CD-ROM DRIVE UNIT
VERTOS 600 SERIES
INSTRUCTION MANUAL
REV. 1.0
Interface: IDE/ATAPI

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VERTOS 600 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Elitegroup Computer Systems VERTOS 600 Series

  • Page 1: Table Of Contents

    CD-ROM DRIVE UNIT VERTOS 600 SERIES INSTRUCTION MANUAL REV. 1.0 Interface: IDE/ATAPI ELITEGROUP COMPUTER SYSTEMS CO., LTD. CONTENTS 1. INTRODUCTION 1.1 FEATURES 1.2 POWER SAVE MODE 1.3 SAFETY NOTICE 2.PRECAUTIONS FOR INSTALLATION, OPERATION AND HANDLING 2.1 INSTALLATION PRECAUTIONS 2.2 OPERATION PRECAUTIONS 2.3 HANDLING PRECAUTIONS...
  • Page 2: Power Save Mode

    . Head phone connector on front panel with volume control. 1.2 POWER SAVE MODE . When the drive unit waits for a command from the host for more than five minutes, it enters the power save mode. The spindle motor and laser stop. .
  • Page 3: Specifications

    AUDIO DC INPUT 39-----------------------------1 OUTPUT +5 G G +12 40-----------------------------2 1. AUDIO LINE - OUT CONNECTOR - Two channels, left and right audio outputs. 2. DRIVE MODE SELECT JUMPERS - To determine the drive mode (Master or Slave) MASTER SLAVE CABLE SELECT Note : The factory default is the Slave mode.
  • Page 4 (1)Disc diameter 12cm,8cm (2)Disc speed(CLV) 200 ~ 3180rpm (3)Disc Capacity 660 MBytes(mode 1,12 cm disk) (4)Data transfer rate 900 KBytes/s(6x speed) (5)Access time (6x speed) 1/3 stroke average 190ms* Random 200ms (6)Buffer Size 256K Bytes <B> HSD Type: (1)Disc diameter 12cm,8cm (2)Disc speed(CLV) 200 ~ 3180rpm...
  • Page 5: Error Rates

    (1)Disc diameter 12cm,8cm (2)Disc speed(CLV) 200 ~ 3180rpm (3)Disc Capacity 660 MBytes(mode 1,12 cm disk) (4)Data transfer rate 900 KBytes/s(6x speed) (5)Access time (6x speed) 1/3 stroke average 190ms* Random 200ms (6)Buffer Size 256K Bytes <D> HTD Type: (1)Disc diameter 12cm,8cm (2)Disc speed(CLV) 200 ~ 3180rpm...
  • Page 6: General Specifications

    (1)Number of channels (2)Frequence response 20Hz ~ 20KHz (3)S/N ratio 80dB (4)Distortion < 0.2%(1 KHz) (5)Output level Line out 0.8Vrms (1KHz) Head phone 0.6Vrms(32 Head phone connected) 4.4 GENERAL SPECIFICATIONS <A> ESD Type : <B> HSD Type : <C> EMD Type : (1)Power Requirements Voltage DC+5V 5%...
  • Page 7: Environmental Conditions

    4.5 ENVIRONMENTAL CONDITIONS <A> ESD Type <B> HSD Type <C> EMD Type <D> HTD Type MTBF 100,000 POH OPERATING NON-OPERATING Temperature +5 C to +45 C -20 C to + 60 C Humidity 20% to 85% 8% to 90% (No condensation) (No condensation) Shock Vibration...
  • Page 8: Guide To Operation

    1. Connect the 40-conductor data cable to the CD-ROM drive and IDE/ATAPI interface card. 2. Plug the power supply cable into the CD-ROM drive 4-pin white connector. 6. GUIDE TO OPERATION This CD-ROM device driver software is compatible with MS-DOS versions 3.1 or later. The installation diskette contains the software needed to install and operate the CD-ROM drive.
  • Page 9: Device Driver (Ecscdide.sys) Parameter List

    Do you want the INSTALL program to automatically modify the CONFIG.SYS and AUTOEXE.BAT files? If you select ‘Yes’, an extra command line DEVICE=C:\ECS\ECSCDIDE.SYS /D:ECSCD003 will be added to your CONFIG.SYS file. The INSTALL program will also add a new command line C:\ECS\MSCDEX /V /D:ECSCD003 /M:10 to your AUTOEXE.BAT file.
  • Page 10: Microsoft Cd-Rom Extensions Parameters

    where the arguments are: /D:<device_names> The character device names that will be used by MSCDEX.EXE to find and communicate with the device driver (default is "ECSCD003"). /P:<port address> The port address to be used to communicate with the card. If this parameter is omitted, the device driver will scan port address automatically during initialize process.
  • Page 11: Windows 95, Nt & Os2 Warp

    Instructs the computer to use expanded memory, if available. For example : C:\ECS\MSCDEX.EXE /D:ECSCD003 /E Note:That you must first load an expanded memory driver before using this option. If no expanded memory driver is loaded, the following error message appears: Expanded memory not present or not usable 6.5 WINDOWS 95' NT &...
  • Page 12: Maintainence & Trouble Shooting

    Playing in a random order, the unit will play all the selections or just the selections you desire. To play only desired selections in random mode, you can delete the undesired selections before or during play. 3. Repeat play REPEAT play has three sub-modes. REPEAT NONE : To cancel REPEAT play.
