Summary of Contents for Macnica Mpression Sulfur
- Page 1 Getting Started Mpression Sulfur Type-A Development Kit Revision 1.0 2024/04/10 2024/04/10 © Mpression by Macnica Group https://www.m-pression.com...
- Page 2 The information in this document (hereinafter called “Information”) is subject to change without notice. Macnica Inc. (Developer) makes no warranty of any kind regarding this document, or of any liability arising out of the application or use of information in this document, and assumes no responsibility for any errors that may appear in this document.
-
Page 3: Table Of Contents
5.3.1 Agilex™ 5 Boot Flow ........................19 5.3.2 Writing .sof Files .......................... 20 5.3.3 Check the Serial Terminal and Linux Boot ................22 6. Reference Information ______________________________________________________ 23 7. Document Revision History _________________________________________________ 24 Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc. -
Page 4: Read This First
In no event shall Macnica Inc. be liable for any consequence arising from the use of this product. Macnica Inc. shall make effort to provide a workaround or fix for failures of this product, with or without charge. -
Page 5: Developer Information
Mpression Sulfur Type-A Development Kit Warranty: Macnica Inc. offers exchange of this product free of charge only in a set range of cases of initial trouble for this product, and within 90 days from when the customer received delivery of the Board. -
Page 6: For Ensuring Safe Use
Do not plug or unplug the power plug with wet or moist hands. This might cause injuries or equipment malfunctions or failures due to electrical shock. © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit... - Page 7 Board, immediately stop using the Board, turn off the power, and unplug the power plug. If you have any requests for repairs or technical consultation, please contact the local Macnica company or Mpression inquiry URL.
- Page 8 Please contact the local Macnica company or Mpression inquiry URL beforehand if you wish to customize or modify any parts that are not described in this Manual as customizable.
-
Page 9: Preparations
Download the design described above from the following URL: https://www.rocketboards.org/foswiki/Documentation/MpressionSulfurDevelopmentKitForIntelAgilexR5F PGAESeries B. Preparing Tools Prepare the following tools before executing this design: Intel Quartus Prime Pro Edition Programmer and Tools Version 24.1 ⚫ ® ® Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc. - Page 10 Prime Pro Edition Design Software Version 24.1 ⚫ ® ® Arm* Development Studio for Intel SoC FPGA ⚫ ® MCUXpresso Integrated Development Environment (IDE) (for NXP MCU software work) ⚫ © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit...
-
Page 11: Setup
Connector 1.2V / 1.3V (CR1220) for MIPI selector MIPI 22pin FPGA / HPS x4 / x1 connector CN14, 12 SW19 SW1, 2 Figure 2 Layout (Bottom view) Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc. - Page 12 2.54 mm pitch 10 pin header, some MCU ports connected signals LED1, LED2, MCU status LED MCU operation check LED LED3 UART CN26 Connector for UART USB Type-C 40 pin header © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit...
- Page 13 Power input CN42 Power input connector ATX6 pin, +12 V input SW18 Power switch Turn +12 V supply to the carrier board ON/OFF CN43 FAN connector +12 V output Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc.
-
Page 14: Setting Up The Board
MIPI1_I2C, MIPI2_I2C I2C Master Device Selection for MIPI (Setting SW1 for CAMs 1 and 3 and SW2 for CAMs 2 and 4) 1-2: FPGA ⚫ 2-3: HPS ⚫ © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit... - Page 15 1 When using -2: 1.2 V MIPI ⚫ 2 When using -3: 1.3 V Cameralink (LVDS) ⚫ ※ Items grayed out in Table 1 should only be considered when evaluating the relevant interface. Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc.
-
Page 16: Dipsw Settings (Som)
ON-ON-OFF: AS(Fast) mode ⚫ ON-OFF-OFF: AS(Normal) mode ⚫ SW1 [4] SDMMC_SEL Flash Device Selection for HPS ON: SD Card ⚫ OFF: eMMC ⚫ Figure 1 SW1 Configuration for SoM © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit... -
Page 17: Creating An Sd Boot Disk For Sulfur Type-A Kit
Take special care when reusing a card that has already been written Linux image. The formatting tools available for Windows are also available on the SD Association site. Refer to: SD Memory Card Formatter for Windows/Mac | SD Association (sdcard.org) Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc. -
Page 18: Executing The Design
The following describes how to configure Terminal Software. Baud Rate: 115200 ⚫ Parity: none ⚫ Stop: 1 bit ⚫ Flow Control: none ⚫ Figure 3 Terminal Software Configuration Screen (Example: Tera Term) © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit... -
Page 19: Perform Configuration And Boot
SDM loads FPGA data and HPS loads SSBL and OS FSBL from bitstream (.sof) images from SD card itself Load from Figure 4 System Layout and Boot Flow for Agilex™ 5 Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc. -
Page 20: Writing .Sof Files
Press the Hardware Setup button to specify the JTAG hardware and clock frequency to connect to. Then click the Auto Detect button. Figure 6 Hardware Setup and Auto Detect © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit... - Page 21 Click the Start button. If writing is successful, the display will look like the one on the right. Figure 8 Writing start to completion The processor will boot as soon as the .sof file has been written. Getting Started - Mpression Sulfur Type-A Development Kit © 2024 Macnica, Inc.
-
Page 22: Check The Serial Terminal And Linux Boot
Username: root, allows you to log in to Linux without a password. Figure 10 Terminal at the end of Linux startup That's all for running the reference design. © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit... -
Page 23: Reference Information
Mpression Sulfur Type-A Development Kit 6. Reference Information Mpression Sulfur Type-A Development Kit by Macnica ⚫ Macnica Sulfur ~ Development Kit for Agilex™ 5 FPGA E-Series ~ | Documentation | RocketBoards.org Mpression – Solutions by Macnica Group ⚫ Home | Mpression (m-pression.com) Agilex™... -
Page 24: Document Revision History
Mpression Sulfur Type-A Development Kit 7. Document Revision History Date Revision Changes 10 April, 2024 Document created © 2024 Macnica, Inc. Getting Started - Mpression Sulfur Type-A Development Kit...
