Summary of Contents for MYSTIC Circuits ANA2

Page 1 Ana2 Official Manual...
Page 3: Table Of Contents
Contents ANA2 INSTALLATION QUICK REFERENCE INPUT SECTION CHANNEL CONTROL KNOBS OUTPUT SECTION PATCHING WITH ANA Ana2 Official Manual...
Page 5: Ana2
While this all may seem complicated, by the end of this manual you will become an Ana master. www.mysticcircuits.com Ana2 Official Manual...
Page 6: Installation
Module power cable orientation is correct at both the rack and module side. Use the IDC ribbon cable supplied with the module. • Ensure the rack earth / grounding is correct. • Take care to avoid patch cables falling into the rack or touching module PCB’s Ana2 Official Manual...
Page 7 I/ 0 CHANCE LENGTH PARAM I/ 0 I/ 0 I/ 0 OUTPUTS MYSTIC MYSTIC MYSTIC MYSTIC Analog Logic Power -12V Connect power to the upper IDC Connector, red stripe to -12V STEP STEP SWAP SWAP MYSTIC Front Back Ana2 Official Manual...
Page 8: Quick Reference
QUICK REFERENCE Analog Logic STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 9 Mag Output: Difference between both channels, output is always positive. Step Output: Track and hold, clocked from the two inputs. Swap Output: Switched output from either of the two inputs or no input. Box Output: Bipolar comparator, generates a 3-level square wave. Ana2 Official Manual...
Page 10: Input Section
Channel 1 Inputs x3 Channel 2 Inputs x3 MAIN MULTIPLY Inputs x2 Inputs x2 Inputs x2 Ana2 Official Manual...
Page 11: Channel Control Knobs
When a signal is also patched into either the main or multiply inputs any signal patched into the sum input will be added to the results of the attenuverter voltage processor. No Offset Shifted Down Shifted Up Ana2 Official Manual...
Page 12: Output Section
Switch output: an output where both channels are dynamically switched on or SWAP off, output is either channel 1, channel 2 or 0. Bipolar comparator: outputs a 3 level square wave that allows us to pulse- width modulate the positive and negative portions of a wave. Ana2 Official Manual...
Page 13 VCAs are notoriously difficult to "zero out". This means that even with no signal plugged into the multiply input for either channel there will probably be some input bleeding into the output Ana2 Official Manual...
Page 14 Keep in mind that like with a normal XOR gate, two positive voltage inputs will result in a negative voltage output. Ana2 Official Manual...
Page 15 For you feedback freaks out there MAG is quite useful for introducing chaotic behavior to a feedback loop, try using it with a filter to recreate some classic strange-attractor chaos circuits. Ana2 Official Manual...
Page 16 BOX output. Just like XOR, this output likes to modulate parameters that mostly want to be at a specific value but can wander off in either direction. This output's simplicity betrays its utility, something interesting is always going on at the SWAP output. SWAP Ana2 Official Manual...
Page 17 Another nifty feature of this output is that since it also generates a negative gate stream you can invert the voltage of the signal to get an extra gate pattern. Try using the multiply inputs for some pseudo-phase modulation on this output. Ana2 Official Manual...
Page 18: Patching With Ana
I decided to add the MIX output to Ana v2. It's an incredibly simple patch but when you need it you will be glad that Ana can do this. Analog Logic Attenuverter Control. Offset Control. Input. Output. STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 19 If you would like a VCA with no bleed I suggest trying out 3DVCA. Analog Logic Input 1 Attenuverter. Input 2 Attenuverter. Input 1. Input 3. Input 2. Input 4. Output. STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 20 SUM 2 input but keep in mind that this will also shift the level of the STEP output. Analog Logic Attenuvert Control. Sample Behavior. Sample Input. Clock Input. STEP STEP SWAP SWAP Output. MYSTIC Ana2 Official Manual...
Page 21 Analog Logic Attenuvert Control. Gate Threshold Voltage Sequence. Gate Output. STEP STEP SWAP SWAP Warped Voltage Sequence Out. MYSTIC (Optional) Voltage Inverter Gate Output 2. Ana2 Official Manual...
Page 22 LFO but will also change the switching behavior of the SWAP output. Analog Logic LFO1 Attenuvert. LFO2 Attenuvert. Synced LFO 1. Synced LFO 2. STEP STEP SWAP SWAP LFO1 & LFO 2. MYSTIC (Combination) Ana2 Official Manual...
Page 23 Analog Logic LFO Attenuverter. Envelope Attenuverter. LFO Input. Envelope. Filter Cutoff, VCA Levels etc. STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 24 LFO into the main input instead of the SUM input is important to be able to fine-tune the portamento behavior and avoid sea-sick pitch wobbles. Analog Logic Sequencer Transpose. Vibrato Amount. Quantized Voltage LFO Input. Sequencer. Voltage Sequencer STEP STEP SWAP SWAP Output. MYSTIC Ana2 Official Manual...
Page 25 Analog Logic Envelope Shape. Swell Control. Envelope Output (Mult to VCA/Filter etc) Fall Input. Rise Input. STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 26 Based on my experiments this particular setup would never feedback so much that it becomes silent but feel free to experiment with other feedback paths. Analog Logic Snarl. Bark. Audio Input. STEP STEP SWAP SWAP Distortion Output. MYSTIC Ana2 Official Manual...
Page 27 This method is not perfect but will work in a lot of cases and yield interesting results even when not working perfectly. Analog Logic Input 1. Sin LFO 0 Deg. Cosine LFO 90 Deg. Input 2. Crossfade Output. STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 28 "bloom" feedback that grows in amplitude without having that feedback turn into garbage. Analog Logic Feedback Attenuverter. Feedback Clip Level. Audio Source. From Effect Output. Main Output. To Effect Input. STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 29 Analog Logic Audio Attenuverter. Pan Control. Audio input. Pan CV input. Audio Output. Audio Output. (Right) (Left) STEP STEP SWAP SWAP MYSTIC Ana2 Official Manual...
Page 31 Notes Ana2 Official Manual...
Page 32 / or expansion cables, or any unauthorized modification of the product’s hardware or firmware. Mystic Circuits reserves the right to determine what qualifies as misuse at their discretion and may include but is not limited to damage to the product...
Page 33 This manual or any portion thereof may not be reproduced or used in any manner whatsoever without the express written permission of the publisher except for personal use and for brief quotations in a review. Version 1.0 March 2024 Manual Update v1 www.mysticcircuits.com Manual designed by Synthdawg www.synthdawg.com Ana2 Official Manual...
