BATH MIXING PROGRAM
PROGRAMME DU MITIGEUR POUR LA SALLE DE BAIN
PROGRAMA MEZCLADORES BAÑO
Art. 33095
GESSI SpA
Parco Gessi - 13037 Serravalle Sesia
(Vercelli) ITALY
Tel. +39 0163 454111
Fax +39 0163 459273
www.gessi.com - gessi@gessi.it

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RILIEVO 33095 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gessi RILIEVO 33095

  • Page 1 BATH MIXING PROGRAM PROGRAMME DU MITIGEUR POUR LA SALLE DE BAIN PROGRAMA MEZCLADORES BAÑO Art. 33095 GESSI SpA Parco Gessi - 13037 Serravalle Sesia (Vercelli) ITALY Tel. +39 0163 454111 Fax +39 0163 459273 www.gessi.com - gessi@gessi.it...
  • Page 2: Caution - Warning

    MUST NEVER BE EXCEEDED, as it may damage and/or cause ruptures and/or leakages and/or even break the product, and present a potential hazard and danger to safety, health and/or property. Following are the technical data with respect to the installation of Gessi plumbing products. ► W orkingpressureshouldnotbelowerthan0,5bar(7,25psi)andnotbehigherthan5bar(72Psi).In case of higher working pressure use a pressure reducer valve.
  • Page 3 Ci-dessous nous indiquons les données techniques concernant l’installation des produits sanitaires Gessi. ► L apressiondeservicenedoitpasêtreinférieureà0,5bar(7,25psi)etsupérieureà5bar(72Psi).En cas de pressions de service plus hautes utiliser une soupape de réduction de la pression.
  • Page 4 1 - ¡CUIDADO!! LES ROGAMOS QUE TENGAN EN CUENTA QUE NUNCA la presión y/o la temperatura máximaaconsejadaNOTIENEQUESERSUPERADA,yaquepodríadañary/ocausarrupturasy/o pérdidasy/oaveríasdelproductoy,porlotanto,representarunriesgoyunpeligropotencialpara la seguridad, la saludad y/o la propiedad. A continuación Les proporcionamos los datos técnicos relativosalainstalacióndelosproductosdegriferíaGessi. ► L apresióndeejercicionotienequeserinferiora0,5bar(7,25psi)ysuperiora5bar(72Psi).Encaso depresionesdeejerciciomayores,utilicenunaválvuladereduccióndelapresión. ►Presiónmáximadeensayodurantelainstalación:8bar(116psi). ► E vitengrandesdiferenciasdepresiónentrelaalimentacióndelaguafríayaquelladelaguacaliente. Lasdiferenciasdepresión,elaguaconunalatocontenidomineralylassustanciasjabonosaspueden...
  • Page 5 PRE-INSTALLATION INFORMATION - PRÉALABLES - PRELIMINARES ART. 33095...
  • Page 6: Données Techniques

    PRE-INSTALLATION INFORMATION - PRÉALABLES - PRELIMINARES Before installation and setting to work Attention! The feeding pipes have to be rinsed thoroughly before the installation of the mixer, so that no shavings, welding or hemp residual or other dirt can be found in the pipes. Foreign bodies can enter the mixer through the rinsed pipes or the general water plant and could damage the washers/ring washers.
  • Page 7 PRE-INSTALLATION INFORMATION - PRÉALABLES - PRELIMINARES Package content: A - Shower head B - Fastening set C - Spacer ring D - Threaded connection for shower head E - Shower head cover Contenu de l’emballage: A - Pomme B - Set de fixage C - Bague entretoise D - Raccord fileté...
  • Page 8 PRE-INSTALLATION INFORMATION - PRÉALABLES - PRELIMINARES 1/8” [3 mm] 3/8” [10 mm] 3/8” [10 mm] - Installation tools - Outils nécessaires pour l’installation - Herramienta necesaria para la instalación...
  • Page 9 PRE-INSTALLATION INFORMATION - PRÉALABLES - PRELIMINARES...
  • Page 10 PRE-INSTALLATION INFORMATION - PRÉALABLES - PRELIMINARES 82-11/16”÷86-5/8” 63”[1600mm] [2100÷2200mm] 82-11/16”÷90-9/16” 66-15/16”[1700mm] [2100÷2300mm] H1+1-3/4"[45mm] 86-5/8”÷92-1/2” 70-7/8”[1800mm] [2200÷2350mm] 86-5/8”÷94-1/2” 74-13/16”[1900mm] [2200÷2400mm] H = Customer height - Hauteur client - Altura cliente H1***= R ecommendedheight-Hauteurconseillée-Alturaaconsejada H2=Waterinletheight-Hauteurpriseeau-Alturatomadeagua To be evaluated according to the rules in force in the installation country À...
  • Page 11: Installation - Installation - Instalación

    INSTALLATION - INSTALLATION - INSTALACIÓN Fig. 1 use hemp or teflon employer chanvre ou teflon usarcáñamooteflon 3/8” [10 mm] Fig. 2...
  • Page 12 INSTALLATION - INSTALLATION - INSTALACIÓN Fig. 3 Fig. 4 Fig. 5...
  • Page 13 INSTALLATION - INSTALLATION - INSTALACIÓN Fig. 6 Fig. 7 Fig. 8 Fig. 9...
  • Page 14 INSTALLATION - INSTALLATION - INSTALACIÓN Fig. 10 3/8” [10 mm] Fig. 11...
  • Page 15 INSTALLATION - INSTALLATION - INSTALACIÓN Fig. 12 3/8” 1/8” Fig. 13 Fig. 14 [10 mm] [3 mm] 3/8” Fig. 15 [10 mm]...
  • Page 16 INSTALLATION - INSTALLATION - INSTALACIÓN Fig. 16...
  • Page 17: Maintenance

    MAINTENANCE - ENTRETIEN - MANUTENCIÓN MAINTENANCE • Should it be necessary to replace one or more components, contact an authorized retailerorvisitWWW.GESSI.COM • Product maintenance should be made only by qualified staff ENTRETIEN • S’il est nécessaire de remplacer un ou plusieurs composants, contacter un centre autoriséouvisiterlesiteWWW.GESSI.COM...
  • Page 18 MAINTENANCE - ENTRETIEN - MANUTENCIÓN Fig. 1 Fig. 2 3/8” [10 mm] Fig. 3 Fig. 4 Fig. 5...
  • Page 19 MAINTENANCE - ENTRETIEN - MANUTENCIÓN Cleaning and Maintenance of Stainless Steel surfaces Mortar and cement splashes can be treated with a solution containing a small amount of phosphoric acid. Rinse withwater(preferablydeionisedwater)anddry.Deionisedwaterreducestheriskofwaterstainingmarks. Proprietary products are available from specialists finishing companies. Never allow mortar removers or diluted hydrochloric acid to be used on stainless steel.
  • Page 20 MAINTENANCE - ENTRETIEN - MANUTENCIÓN • les produits de nettoyage pour l’argenterie. Un torchon humide ou une peau de chamois conviendra habituellement pour enlever les salissures normales, les traces de doigts, etc. Pour des saletés plus tenaces, des éponges donnent généralement de bons résultats. Lestamponsmétalliquesordinaires(lained’acier)oulesbrossesmétalliquesenaciersontprohibés.Enplusde rayerlessurfaces,cesaccessoiresrisquentdeprovoquerunecontamination(dépôtdeparticulesferreuses), quiparlasuitepourraitprovoquerl’apparitiondetâchesderouillesilasurfaceestexposéeàl’humidité...
  • Page 21 NOTES - NOTES - NOTAS ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 22 NOTES - NOTES - NOTAS ..................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
  • Page 24 GIS006900-R1...
