- Page 1 Dametric AB GIR-PS1 GIR PoE Splitter dametric GIR-PS1 GMS Industrial PoE Splitter Description GIR‐PS1 EN.docx Feb. 19, 2016 / BL Page 1 of 5 ...
-
Page 2: Table Of Contents
Dametric AB GIR-PS1 GIR PoE Splitter Table of contents Page 1 GENERAL ........................... 2 2 TECHNICAL DATA ......................2 3 DIMENSION ........................3 4 CONNECTIONS ......................... 4 4.1 Power supply ......................4 4.2 DATA OUT ....................... 4 4.3 PoE IN........................4 ... -
Page 3: Dimension
Dametric AB GIR-PS1 GIR PoE Splitter Dimensions Width 25, height 109, depth 88 mm Dimension Unit = mm (inch) Side view Front view Rear view To view GIR‐PS1 EN.docx Feb. 19, 2016 / BL Page 3 of 5 ... -
Page 4: Connections
Dametric AB GIR-PS1 GIR PoE Splitter Connections 4.1 Power supply The detachable connector for the power supply is placed on the top of the unit (2). Connect to 0V Connect to +24VDC Connect to ground 4.2 DATA OUT Connect the short Ethernet cable from the GIR-DM1 router unit into the DATA OUT socket (5). -
Page 5: Valmet Article Number
Dametric AB GIR-PS1 GIR PoE Splitter Valmet article number VAL0372769 Contact Development, production and service: dametric Dametric AB Jägerhorns Väg 19, SE-141 75 Kungens Kurva, Sweden Phone: +46-8 556 477 00 Telefax: +46-8 556 477 29 e-mail: service@dametric.se www.dametric.se GIR‐PS1 EN.docx ...
