Installing the BVE
b Unclip the protective cover and remove the electronic board.
b Secure the indicator light to the wall using the 2 x 4 mm
diameter screws.
Installing the BVD
b Drill a 12 mm diameter hole in the masonry to insert
the light guide.
b Install the light guide, secure the fi xing lug by blocking it
against the guide and position the assembly.
Standard indication box (BVE)
The end of the guide must be fl ush with the external wall.
If necessary, cut the rod on the external side and surface
the cross-section using 400 grain abrasive.
b Drill the fi xing hole and block the lug (dowel + 4 or 4.5 mm
diameter screw).
Connection
b Use a cable U1000 R02V – 2 x 1.5 mm
for a Flair 3xx.
b Connect the indicator light by inserting the cable through
the cable gland placed under the box.
b Connect the wires using a fl at head screwdriver,
as per the instructions below:
Ref.
BVE
BVD
Anti-vandalism indication box (BVD)
V
C
R
Ref.
BVE
BVD
V
C
R
Dimension of products
BVE
As standards, specifications and designs change from time to time,
please ask for confirmation of the information given in this publication.
Production: Graphème
http://www.merlin-gerin.com
Printing: Imprimerie du Pont de Claix/JPF - Made in France
NT00143-01
2
or 3 x 1.5 mm
Colour of wire
Colour of wire
Ref.
Ref.
As per standard
As per standard
Flair 2xx
ITI (France)
ASE1000 : 2005
HD380 S2 : 2001
Flair 2xD
T200-LAMP
Black
Brown
+
+
Blue
Blue
Colour of wire
Colour of wire
Ref.
As per standard
As per standard
Flair 3xx
ASE1000 : 2005
HD380 S2 : 2001
Brown
Black
V
Black
Grey
C
Blue
Brown
R
BVD
Manuel d'installation
2
Installation manual
Manual de instalación
11-2006
BVE
bicolore - Two-colour - Bicolor
BVE ITI
BVD
T200-LAMP
