- Page 1 Occupancy Plus Sensor Instruction Manual MSMW24-BP.11 Before using this product, please read this manual carefully and keep it properly！ Document Version：C...
- Page 2 Upon proper installation and commissioning, end users can proceed linkage control between this product and other intelligent devices through mobile phone App. Key Functions: HDL Buspro communication protocol Human presence detection: 24GHz millimeter wave radar technology, accurate and high sensitivity for detecting human motion and breath Illuminance monitoring: Real-time illuminance can be detected by the device, providing smart scene control in accordance with actual illuminance.
-
Page 3: Technical Data
◇◆ Technical Data Rated voltage 24V DC Rated current ≤40mA/24V DC Input voltage 12 - 30V DC Dry contact 2 dry contacts Communication protocol Buspro Cable diameter of Buspro terminal 0.6 - 0.8mm Detection frequency for micro motion 24GHz-24.25GHz Detection range for micro motion Φ6m (in terms of diameter) Note: Installation height is 3m. -
Page 4: Safety Precaution
Warning: The installation and testing for the product must be carried out by HDL Automation Co., Ltd. (hereinafter referred to as HDL) or its appointed service agencies. The electric construction shall comply with local laws and safety regulations. -
Page 5: Installation
◇◆ Wiring Tips: For Buspro connection, a hand-in-hand connection is recommended. HDL Buspro Cable Guide HDL Buspro HDL Buspro Cable CAT5 / CAT5E... - Page 6 Note: The detection range of the device is oval-like, as shown in Figure 12, Edge (a) detects the short side of the diameter, Edge (b) detects the long side of the diameter, and the length of each edge varies according to different spaces and environments.
- Page 7 Step 1. Make a proper opening on the ceiling. Note: The opening size for installation is Φ60mm; The installation height should be 2.5 - 3.5m. Step 2. Get the necessary cables ready in the ceiling. Step 3. Flip up the spring bracket and push the device into the opening on the ceiling. Step 4.
-
Page 8: Operation
◇◆ Operation The device is configured with one reset button and one indicator, as described below. Indicator Tips: It is supported to turn off the indicator through commissioning software. Status Description Make the device power-on, then the indicator slowly Device initializing... flashes. - Page 9 Scene 1 - Enable or Disable the basic function as below: Tips: All basic functions are enabled by default. If users disable any of them, the corresponding one will stop running. Temperature sensor, brightness sensor, human presence sensor Dry contact 1, dry contact 2 UV switch 1, UV switch 2 Logic status as condition, group status as condition Scene 2 - Compensate settings for current temperature and illuminance...
- Page 10 1. Human presence indicator: When enabled, it will indicate according to the detection results. Human presence detected: Green light is on. Human presence not detected: Green light flashes once every 2s. Device abnormal: Red light is on. 2. Working status indicator: When enabled, it will indicate according to the running status of the device. Success: Green light quickly flashes for 2s then off, which indicates successful operation, such as successful firware update.
- Page 11 Illuminance: ＞threshold value / ＜threshold value / within threshold range Human presence sensor: Motion / No motion + Duratio n; Duration refers to how long the detected / undetected state lasts before the condition is met. If the duration is set to 0, it will be triggered immediately when human presence / no human presence is detected.
- Page 12 5. Automation Setting Step 1. Click "Automation" to enter the setting page. --> Step 2. Click "Add" to create automation. Tips: To proceed further setting for the automation item, please right click and select. Step 3. Click "Add" to create the condition and repeat date. --> Step 4. Click "Add" to create execution action. Tips: To proceed further setting for the items, please right click and select.
- Page 13 6.1. Sensor Test Step 1. Click "Category". Step 2. Click "Function", here it shows all function bound with the current project, which have been already set by HDL Studio. Click the tab to enter the setting page. For instance, click "Sensor".
- Page 14 Step 1. Click "Smart". Step 2. Click "Automation", here it shows all automation bound with the current project, which have been already set by HDL Studio. Click the tab to enter the automation setting page, as shown in Scene 1.
-
Page 15: Packing List
◇◆ Legal Statemen HDL has all the intellectual property rights to this document and contents thereof. Reproduction or distribution for third parties are prohibited without written authorization from HDL. Any infringement of HDL’s intellectual property rights will be investigated the legal liability. -
Page 16: Technical Support
◇◆ Technical Support E-mail: hdltickets@hdlautomation.com Website: https://www.hdlautomation.com...
