Valley Comfort Systems Blaze King CLARITY CL2714.SP Operation & Installation Manual

Direct vent gas fireplace insert

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

CLARITY CL2714.SP

DIRECT VENT GAS FIREPLACE INSERT

with Standing Pilot Ignition (SP)

For use with Natural Gas (NG) or Propane (LPG)

OPERATION & INSTALLATION MANUAL

Blaze King recommends that its gas hearth products be installed

and serviced by professionals who are certified in the U.S. by the

National Fireplace Institute (NFI) as NFI Gas Specialists.

Installer: Please COMPLETE THE DETAILS ON THE LAST PAGE

and leave this manual with the homeowner.

Homeowner: Please SAVE THESE INSTRUCTIONS for future reference.

PFS REPORT: #F18-431

MANUFACTURED BY

Valley Comfort Systems Inc., 1290 Commercial Way, Penticton BC, Canada, V2A 3H5

web: www.blazeking.com email: info@blazeking.com

ATTENTION: The authority having jurisdiction (municipal building department, fire department, etc.) should be

consulted before installation to determine the need to obtain a permit.

Pour la version française de nos manuels S.V.P. vous référez à notre site web: www.blazeking.com

180-CL2714.SP v2.00

August 19, 2022

Table of Contents

Need help?

Do you have a question about the Blaze King CLARITY CL2714.SP and is the answer not in the manual?

Questions and answers

Summary of Contents for Valley Comfort Systems Blaze King CLARITY CL2714.SP

Page 1 Homeowner: Please SAVE THESE INSTRUCTIONS for future reference. PFS REPORT: #F18-431 MANUFACTURED BY Valley Comfort Systems Inc., 1290 Commercial Way, Penticton BC, Canada, V2A 3H5 web: www.blazeking.com email: info@blazeking.com ATTENTION: The authority having jurisdiction (municipal building department, fire department, etc.) should be consulted before installation to determine the need to obtain a permit.
Page 2 This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes. FIRE OR EXPLOSION HAZARD Failure to follow safety warnings This appliance is only for use with the type of gas exactly could result in serious injury, indicated on the rating plate.
Page 3 PREFACE CL2714.SP Page 3 The content within this manual describes the installation TEST CERTIFICATION DATA and operation of the Blaze King Clarity CL2714. It is Natural Gas Propane against federal regulations to operate this appliance in a (NG) (LPG) manner inconsistent with the operating instructions in this Steady State Efficiency 66.87% 69.48%...
Page 4: Table Of Contents
TABLE OF CONTENTS CL2714.SP Page 4 SPECIFICATIONS ___________________________________________________________________ 5 APPLIANCE DIMENSIONS ___________________________________________________________ 6 SAFETY CLEARANCES _______________________________________________________________ 8 SAFETY PRECAUTIONS ______________________________________________________________ 10 VENTING __________________________________________________________________________ 11 OPTIMAL VENTING PERFORMANCE ....................11 VENTING CONFIGURATIONS ......................11 TERMINATION ABOVE ROOF......................11 EXTERIOR WALL PASS THROUGH ....................11 VENT TERMINATION LOCATION ......................
Page 5: Specifications
SPECIFICATIONS CL2714.SP Page 5 CLARITY 2714 SP, CL2714.SP SPECIFICATIONS Flue Vent Size 3” x 3” Co-Linear Electrical Rating 120 V.A.C. Shipping Weight 200 lbs (90.7 kg) Natural Gas (NG) Propane (LPG) Manifold Pressure 3.8” w.c. (0.95 kPa) 11.0” w.c. (2.74 kPa) Minimum Supply Pressure for 7.0”...
Page 6: Appliance Dimensions
APPLIANCE DIMENSIONS CL2714.SP Page 6 35" " SECONDARY TRIM " " SAFETY SCREEN TRIM " RATING & LIGHTING POWER " DANGER INSTRUCTIONS CORD LABELS " GAS INLET LABELS " INTAKE EXHAUST " " " S.Z4981 - SHROUD 24.5” x 36.5” "...
Page 7 APPLIANCE DIMENSIONS CL2714.SP Page 7 40" S.Z4983 - SHROUD 29” x 40” 29" 44" S.Z4984 - SHROUD 32” x 44” 32" S.Z4990 - 45” SHELF WITH RISERS *CAN BE INSTALLED WITH ANY SHROUD OPTION " 45" S.Z4994 - ANGLED SHROUD BASE **CAN ONLY BE INSTALLED WITH: S.Z4981 OR S.Z4982 "...
Page 8: Safety Clearances
SAFETY CLEARANCES CL2714.SP Page 8 MINIMUM CLEARANCES TO COMBUSTIBLES A Appliance to sidewall. 4.5” (115 mm) - Bottom of appliance to underside of mantel (Fig. 1) 48" (1219 mm) - With S.Z4991 Mantel Shield kit (Fig. 2) 40" (1016 mm) - With S.Z4993 Under Mantel Shield kit (Fig.
Page 9 SAFETY CLEARANCES CL2714.SP Page 9 MINIMUM FIREPLACE DIMENSIONS Refer to the diagrams below for the minimum fireplace dimensions required to properly install this appliance: THE LEVELLING BOLTS AT THE BASE OF THE APPLIANCE CAN BE ADJUSTED IF THE COMBUSTIBLE FLOOR IN FRONT OF THE APPLIANCE IS NOT LEVEL WITH THE HEARTH.
Page 10: Safety Precautions
SAFETY PRECAUTIONS CL2714.SP Page 10 FIRE OR EXPLOSION HAZARD. FAILURE TO FOLLOW SAFETY WARNINGS EXACTLY COULD RESULT IN PROPERTY DAMAGE, SERIOUS BODILY HARM, OR DEATH. YOUR SAFETY • To prevent injury, do not allow anyone who is unfamiliar with the appliance to operate it. •...
Page 11: Venting
VENTING CL2714.SP Page 11 OPTIMAL VENTING PERFORMANCE For best venting performance, follow these guidelines: 1. This appliance must be vented using the following listed and approved vent components: Selkirk (Direct-Temp), Amerivent, M&G Duravent, BDM, Olympia, and ICC. Read the manufacturer’s installation instructions before installing the venting system.
Page 12: Vent Termination Restrictions
VENTING CL2714.SP Page 12 VENT TERMINATION RESTRICTIONS TABLE 1 - VENT TERMINATION CLEARANCES 12 in (30.5 cm) to 24” (61 cm) 180-CL2714.SP v2.00 August 19, 2022...
Page 13: Installation
INSTALLATION CL2714.SP Page 13 NOTE: THIS SECTION OF THE MANUAL IS FOR THE USE OF QUALIFIED SERVICE PERSONS ONLY. GAS CONNECTIONS Have a qualified gas fitter run a gas supply line to the appliance. The line must be properly sized and fitted according to the installation codes.
Page 14: Fireplace Modifications
INSTALLATION CL2714.SP Page 14 FIREPLACE MODIFICATIONS Before installing this appliance into an existing fireplace, consider the following: • Cutting any existing sheet metal parts in a solid fuel burning fireplace is prohibited. • The fireplace flue damper should be removed or fixed in a fully open position. •...
Page 15: Initial Setup
CL2714.SP INSTALLATION Page 15 INITIAL SETUP 1. Locate the x6 Levelling Bolts beneath the appliance (Fig. 5) and level the appliance from side to side and front to back. If levelling is not required, the bolts can be removed. Fig. 5 2.
Page 16: Vent Connector
INSTALLATION CL2714.SP Page 16 VENT CONNECTOR The Vent Connector is installed on the appliance from factory, but can be removed and attached to the Flex Vent and then reconnected to the appliance to ease the installation process. Follow these instructions to remove: 1.
Page 17: Mobile Home Installation
CL2714.SP INSTALLATION Page 17 MOBILE HOME INSTALLATION This appliance is approved for installation in a manufacture (mobile) home. A manufactured home (USA only) or mobile home OEM installation must conform with the Manufactured Home Construction and Safety Standard Title 24 CFR Part 3280 or, when such a standard is not applicable, the Standard for Manufactured Home Installations ANSI / NCSBCS A225.1 or Standard for Gas Equipped Recreational Vehicles and Mobile Housing CSA Z240.4.
Page 18: Air Shutter Adjustment
INSTALLATION CL2714.SP Page 18 AIR SHUTTER ADJUSTMENT The air shutter allows the amount of air coming into the burner to be adjusted in order to accommodate different climates and venting arrangements. To access the Air Shutter Lever, follow these steps: 1.
Page 19: Sit Wiring Diagram
CL2714.SP INSTALLATION Page 19 CLARITY 26 MILLIVOLT SIT WIRING DIAGRAM Pilot assb 610.0712 on/off switch 145.0725 600.0842.VC 600.0721.A thermocouple thermopile pilot line 600.820.644 SIT Nova valve connect to rear of valve OPTIONAL THERMOSTAT & WALL SWITCH WIRING DIAGRAM connect to rear of valve 70 °...
Page 20: Sit Valve Schematic
INSTALLATION CL2714.SP Page 20 SIT VALVE SHCEMATIC 15 6 820 NOVA VALVE ON/PILOT/OFF Knob Manual HI-LO adjustment or pressure regulator adjustment Pilot adjustment Thermocouple connection Mounting for piezo & bracket Inlet pressure test point Outlet pressure test point Main operator Pilot outlet Main gas outlet Flange mounting screw holes...
Page 21: Fuel Conversion
CL2714.SP INSTALLATION Page 21 FUEL CONVERSION This appliance is approved to operate on either natural gas or propane. The factory pre-set is for natural gas. If converting to propane (or back to natural gas), a conversion kit is required. Each kit contains: •...
Page 22 INSTALLATION CL2714.SP Page 22 Pilot Fuel Conversion: 1. Use a 7/16” wrench to slightly loosen the pilot hood (Fig. 14). 2. Locate the tab at the base of the pilot hood and push it in (Fig. 15). This will force a tab with a stamped hole to pop out on the oposite side (Fig.
Page 23 CL2714.SP INSTALLATION Page 23 installationi i n n s s t t r r u u c c t t i i o o n n s s 820 NOVA HI/LO Conversion Kit WARNING! The installation of this conversion kit must only be undertaken by a qualified and certified gas appliance installer.
Page 24: Lighting Instructions
LIGHTING INSTRUCTIONS CL2714.SP Page 24 Note: Turning on the appliance when it has been off for a while may cause condensation to appear on the glass. This is a normal occurance as your appliance heats up. 180-CL2714.SP v2.00 August 19, 2022...
Page 25 CL2714.SP LIGHTING INSTRUCTIONS Page 25 PILOT LIGHT Refer to the Lighting Instruction Label on how to light the pilot. Ensure the pilot has fully engulfed the thermocouple assembly. (Fig. 17) LIGHTING THE BURNER The appliance controls are located behind the hinged door beneath the firebox.
Page 26: Maintenance And Service
CL2714.SP MAINTENANCE and SERVICE Page 26 ROUTINE MAINTENANCE Blaze King recommends that you regularly: • Clean away any lint accumulations or debris from the grills and combustion/convection passageways. • Keep the area around the appliance free from combustible materials such as paper, wood, clothing, gasoline, flammable solids, liquids, and vapors.
Page 27 VENTING COMPONENTS CL2714.SP Page 27 M&G DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST DESCRIPTION PART OLD PART Aluminum Flex Length - 3” 3DFA-35 Flex Coupling - 3” 3DFA-FC Co-Axial to Co-linear Appliance Connector 46DVA-GCL Chimney Liner Termination Kit 46DVA-GK Co-Linear Kit w/ Flex 46DVA-CL33-25 Co-Linear Kit w/ Flex...
Page 28: Venting Components
VENTING COMPONENTS CL2714.SP Page 28 BDM PARTS LIST ORDER # DESCRIPTION PROFORM 35’ INSERT CO-LINEAR TERMINATION KITS: 94203370 3"X3"VCL PROFORM KIT 35'X 2 94203370B 3"X3"VCL PROFORM KIT 35'X 2 W/ BLACK CAP PROFORM INSERT CO-LINEAR INSULATED KITS: 942103360 3"X3"VCL PROFORM INSULATED KIT 30'X 2 942103360B 3"X3"VCL PROFORM INSULATED KIT 30'X 2 W/ BLACK CAP 942103370...
Page 29 CL2714.SP RIGID VENTING PARTS LIST VENTING COMPONENTS Page 29 OLYMPIA PARTS LIST KITS PART DESCRIPTION VDV-CKVCCH33 3”x3” Co-Linear Kit that includes a High Wind Vertical Cap, 2 3”x35’ rolls of Aluminum Liner and 4 hose clamps VDV-CK33CC Square Style 3”x3” Stainless Steel Co-Linear Cap and 2 Hose clamps. The cap has 2 built-in Hose Clamps VDVB-CK33CC Square Style 3”x3”...
Page 30 PARTS LIST CL2714.SP Page 30 ITEM PART DESCRIPTION NUMBER 4911 BAFFLE Z4910 FLOOR PLATE 640-4900 14” WIDE BURNER 610-0712 PILOT ASM ADJ NG/LPG PSE Z4914 SP VALVE ASM Z4917 CL2714 DOOR ASSEMBLY 4980 SECONDARY TRIM 645-1630 SAFETY SCREEN 16” X 30.5” S.Z4921 SAFETY SCREEN TRIM w/ SCREEN 145-0725...
Page 31: Trouble Shooting
CL2714.SP TROUBLESHOOTING Page 31 Please ensure instructions were followed exactly before attempting to trouble shoot the appliance. Troubleshooting and servicing of the gas and electircal components of the appliance should be conducted by a qualified service person. PROBLEM POSSIBLE CAUSE ACTION The pilot flame has gone out •...
Page 32 TROUBLESHOOTING CL2714.SP Page 32 • Turn the system off by pressing the ON/OFF button on the transmitter • After approximately 2 seconds press the ON/OFF button on the transmitter again. Locking conditions Reset the Proflame IFC board • In the manual flame control mode, use the down arrow button to reduce the flame to off, indicated by the word OFF displayed on the transmitter LCD screen.
Page 33: Warranty
CL2714.SP WARRANTY Page 33 BLAZE KING GAS LIMITED WARRANTY Blaze King and Valley Comfort’s respective brands extend the following warranty for gas appliances purchased from an authorized Blaze King / Valley Comfort dealer and installed in the United States of America or Canada. Warranty starts with date of purchase by the original owner (End User) except as noted for replacement parts.
Page 34 WARRANTY CL2714.SP Page 34 Blaze King Gas Limited 10 Year Warranty Blaze King is the manufacturer of the Blaze King line of heating products. At Blaze King, our commitment to the highest level of quality and customer service is the most important thing we do. Each Blaze King stove is built on a tradition of using only the finest materials and is backed by our limited lifetime warranty to the original purchaser.
Page 35 CL2714.SP WARRANTY Page 35 If you are not satisfied with the service provided by the Blaze King dealer, write to Blaze King at the address listed on the last page of the Owner’s Manual. Include a copy of the original purchase invoice and a description of the problem. Exclusions and Limitations: 1.
Page 36 WARRANTY CL2714.SP Page 36 19. The Limited Warranty does not cover any loss or damage incurred by the use or removal of any component or apparatus to or from the Blaze King fireplace or stove without the express written permission of Blaze King and bearing a Blaze King label of approval.
Page 37: Notes
CL2714.SP NOTES Page 37 Installer - Please complete the following information: Dealer Name & Address:________________________________________________________ ____________________________________________________________________________ Installer Name (print): _________________________________________________________ Installer Signature: ___________________________________________________________ Installer Phone #: ____________________________________________________________ Date Installed:________________________________________________________________ Appliance Serial No.: __________________________________________________________ 180-CL2714.SP v2.00 August 19, 2022...
