Industrial Electronic Devices
User Manual
Revision 1.000
English
Multiprotocol Router with NAT
(Order Code: HD67H99-B2)
For Website information:
www.adfweb.com?Product=HD67H99-B2
For Price information:
www.adfweb.com?Price=HD67H99-B2
Benefits and Main Features:
Very easy to configure
Power Supply 18...35V DC
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual Multiprotocol Router with NAT
Document code: MN67H99_ENG
For others products, see also the following links:
RS232 / RS485 / USB / Ethernet
www.adfweb.com?Product=HD67118
www.adfweb.com?Product=HD67119
www.adfweb.com?Product=HD67038
Converter)
CAN / CANopen / Modbus / Modbus TCP
www.adfweb.com?Product=HD67001
Converter)
www.adfweb.com?Product=HD67502
Converter)
www.adfweb.com?Product=HD67011
Converter)
www.adfweb.com?Product=HD67012
Converter)
www.adfweb.com?Product=HD67514
Converter)
Modbus RTU Slave / Modbus TCP Master - Converter
www.adfweb.com?Product=HD67510
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.000
Page 1 of 25
(RS232 / RS485 - Converter)
(USB / RS485 - Converter)
(RS485 / RS232 / Ethernet -
(CANopen / Modbus Master -
(CANopen / Modbus Slave -
(CAN / Modbus Master -
(CAN / Modbus Slave -
(CAN / Modbus TCP Master –
Advertisement
Table of Contents
Summary of Contents for ADF Web HD67H99-B2
- Page 1 Page 1 of 25 Industrial Electronic Devices User Manual Revision 1.000 English Multiprotocol Router with NAT (Order Code: HD67H99-B2) For Website information: www.adfweb.com?Product=HD67H99-B2 For Price information: For others products, see also the following links: www.adfweb.com?Price=HD67H99-B2 RS232 / RS485 / USB / Ethernet www.adfweb.com?Product=HD67118...
-
Page 2: Table Of Contents
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 2 of 25 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Dear customer, we thank you for your attention and we remind you that Page you need to check that the following document is: INDEX UPDATED DOCUMENTATION Updated... -
Page 3: Security Alert
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 3 of 25 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 4 of 25 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 5 of 25 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67H99-B2 ADFweb.com S.r.l. -
Page 6: Characteristics
Revision 1.000 Page 6 of 25 Industrial Electronic Devices CHARACTERISTICS: The HD67H99-B2 is a Multiprotocol Router with NAT. It allows the following characteristics: Electrical isolation between Ethernet and Power Supply; Mountable on 35mm Rail DIN; Wide power supply input range: 18…35V DC;... -
Page 7: Power Supply
Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 12…35V DC. For more details see the two tables below. Vmin Vmax Consumption at 24V DC: Device Consumption [W/VA] HD67H99-B2 Caution: Not reverse the polarity power HD67H99-B2 ADFweb.com S.r.l. -
Page 8: Leds
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 8 of 25 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information of the functioning status. Meanings of the LEDs when the device is ON are described in the table below. -
Page 9: Ethernet
The Ethernet port is used for programming the device and for Ethernet communication. The Ethernet connection must be made using Connector2 and/or Connector3 of HD67H99-B2 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 10: Recovery Button
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 10 of 25 Industrial Electronic Devices RECOVERY BUTTON: In order to recover the device in case of wrong firmware updating or any error that compromises correct functioning of the device, it is necessary to press the BTN1. -
Page 11: Use Of Adfweb Discovery Tool Software
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 11 of 25 Industrial Electronic Devices USE OF ADFWEB DISCOVERY TOOL SOFTWARE: To discover the device into the network and see its IP Address, use the available software that runs with Windows called “ADFweb Discovery Tool”. -
Page 12: Use Of Webserver
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 12 of 25 Industrial Electronic Devices USE OF WEBSERVER: To configure the device, it is necessary to use the integrated webserver. Communication will be done over the HTTPS protocol, so with encrypted communication. The default IP address from factory is 192.168.2.206 for Ethernet 0 port and the device is reachable at this url: https://192.168.2.206/ As soon as the browser is launched and connected to the IP address of the device, the login page appears. - Page 13 User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 13 of 25 Industrial Electronic Devices When login is done, the main page with device info will appear. In the top-left corner, there will be a menu that allows to open a drawer with all sections of the webserver.
-
Page 14: Webserver Device Info
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 14 of 25 Industrial Electronic Devices WEBSERVER DEVICE INFO: This section shows main info about the device. Figure 5: “Device Info” page The means of the fields for the “Device Info” section are: In the field “Device Type”... -
Page 15: Webserver Firmware Update
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 15 of 25 Industrial Electronic Devices WEBSERVER FIRMWARE UPDATE: This section is used to download and update the firmware of the device and export/import full configuration. If required, it is possible to reset the device to Factory settings. Figure 6: “Firmware update”... -
Page 16: Webserver User Settings
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 16 of 25 Industrial Electronic Devices WEBSERVER USER SETTINGS: This section is used to change the username and/or password of the webserver. All settings of this page can be imported or exported by pressing the related buttons. Figure 7: “User settings”... -
Page 17: Webserver Network Settings
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 17 of 25 Industrial Electronic Devices WEBSERVER NETWORK SETTINGS: This section is used to set the Network interfaces of the device. All settings of this page can be imported or exported by pressing the related buttons. Figure 8: “Network settings”... - Page 18 User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 18 of 25 Industrial Electronic Devices The means of the fields for the “Network settings” section are: In the field “NTP Server” it is possible to set a NTP server for date and time synchronization; In the field “Interface configuration”...
-
Page 19: Webserver Webserver Settings
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 19 of 25 Industrial Electronic Devices WEBSERVER WEBSERVER SETTINGS: This section is used to update the certificate and key for TLS encryption. By default, the device has its own certificate, but it is possible to update it to be recognized, trusted and configured in the final installation. -
Page 20: Webserver Router
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 20 of 25 Industrial Electronic Devices WEBSERVER ROUTER: This section is used to set all rules of NAT router. All settings of this page can be imported or exported by pressing the related buttons. Figure 10: “Router settings”... - Page 21 User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 21 of 25 Industrial Electronic Devices By clicking on ‘+’, it is possible to add a new rule. It is possible to create the NAT in two different ways: By port: it is possible to address the TCP and/or UDP messages to a specific port and the router will now the local device to which forwarding it;...
-
Page 22: Mechanical Dimensions
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 22 of 25 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 9: Mechanical dimensions scheme for HD67C00-xxx-B2 ADFweb.com S.r.l. -
Page 23: Ordering Informations
Enclosure Type B: Modulbox 2M, 35mm DIN Rail mounting Device Family HD67H99: Multiprotocol Router with NAT Order Code: HD67H99-B2 Multiprotocol Router with NAT ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz – 12 V DC Order Code: AC34012 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 24: Disclaimer
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 24 of 25 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. For losses due to fire, earthquake, third party access or other accidents, or intentional or accidental abuse, misuse, or use under abnormal conditions repairs are charged to the user. -
Page 25: Warranties And Technical Support
User Manual Multiprotocol Router with NAT Document code: MN67H99_ENG Revision 1.000 Page 25 of 25 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com. Otherwise contact us at the address support@adfweb.com RETURN POLICY: If while using your product you have any problem and you wish to exchange or repair it, please do the following: Obtain a Product Return Number (PRN) from our internet support at www.adfweb.com.
