- Page 1 195 cm max. 120 kg max. 120 kg ~ 30 - 60 Min. ~ 20 Min. 33 kg 63 kg L 123 | W 64 | H 104 L 108 | B 56 | H 139 TWMCL.01.03 Art. No. TW-MC-L...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly Overview Optional Cradle Function Turning around the Footrest OPERATING INSTRUCTIONS Button and Function Description STORAGE AND TRANSPORT General Instructions Transportation Wheels TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar... - Page 5 European VAT Number: DE813211547 Disclaimer © Taurus Wellness is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
- Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and fi rst use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
- Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ATTENTION This notice indicates potentially hazardous situations which, if not avoided, may result in property damage.
-
Page 8: General Information
GENERAL INFORMATION Technical Data Programmes in total: Automatic programmes: Manual programmes: Automatic timer: 15 Minutes Power input: 220 V, 50 Hz Power consumption: 100 W Amount of motors: Dimensions and Weight Package dimensions (L x W x H) approx.: 157 cm x 74 cm x 78 cm Set-up dimensions (L x W x H) approx.: 123 cm x 64 cm x 104 cm Reclined dimensions (L x W x H) approx.:... -
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly aff ected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 10: Electrical Safety
Electrical Safety ⚠ DANGER In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 11: Set-Up Place
Set-Up Place ⚠ WARNING Do not place the equipment in main corridors or escape routes. To avoid fi res, do not place the appliance near or in rooms with high heat (e.g. near a heater). ⚠ CAUTION Choose the place in which to set up the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. -
Page 12: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suff ocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 13: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fi t properly. Tighten the screws using the tool only when you are instructed to do so. -
Page 14: Overview
Overview Side View Pillow Backrest Cover Seat Control Panel Smartphone Holder with USB Charger Footrest Rear View Power Plug Power Switch Mains Socket Transportation Wheels... -
Page 15: Optional Cradle Function
Internal Parts L-Massage Track L-Shaped Massage Track 3D Massage Mechanism 3D Massage Function Massage Ball Massage Rollers Air Bag (Calf Area) Calf Airbag Optional Cradle Function Loosen the screws on the rear cover and remove the cover. To enable the cradle function, remove the small safety pin fi rst, then the large one. -
Page 16: Turning Around The Footrest
Turning around the Footrest The foot section can be used as a simple footrest or for calf massage. To unlatch the footrest, pull the upper end of the footrest towards you (fi g. a). Turn the footrest 180° down and towards you. After turning, pull the strap just above to lock the footrest (fi g. -
Page 17: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Button and Function Description... - Page 18 Button Description Rotary Wheel Turn to raise or lower the backrest. Calf Massage Press to start or stop the calf massage. Press to activate/deactivate the heat function on the lower back. Press and hold to activate/deactivate Bluetooth. Heat Function/Bluetooth NOTICE To connect your device to the massage chair, open the Bluetooth settings on your device and connect it to...
- Page 19 A choice of three automatic programmes: Sport Recovery Sleep Automatic Programmes NOTICE The selected programme is indicated by an indicator light (8) on the control panel. programme stops after minutes automatically. Press and hold to adjust the massage speed. ...
-
Page 20: Storage And Transport
STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. -
Page 21: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may aff ect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 22: Maintenance And Inspection Calendar
Error Codes and Troubleshooting The electronics of the equipment continuously carries out tests. In case of deviations, an error code appears on the display and normal operation is stopped for your safety. Please contact the contract partner for technical support. Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. -
Page 23: Serial Number And Model Name
The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate fi eld. Serial number: Brand / Category: Taurus Wellness / massage chair Model Name: Taurus Wellness Massage Chair Large Article Number: TW-MC-L... -
Page 24: Serial Number And Model Name
WARRANTY Products from Taurus Wellness® are subject to strict quality control. However, if a fi tness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. -
Page 25: Warranty
Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance. -
Page 26: Contact
CONTACT TECHNIK TEKNIK OG SERVICE CUSTOMER SUPPORT �� �� �� +49 4621 4210-900 80 90 16 50 00800 2020 2772 +494621 4210 944 +49 4621 4210-945 �� +49 4621 4210-698 �� �� info@fi tshop.dk info@fi tshop.co.uk �� technik@fi tshop.de �� ��... - Page 27 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Fitshop is Europe’s largest specialist store for www.fi tshop.co.uk home fi tness equipment with currently over 70 www.fi tshop.de/blog stores and one of the world’s most renowned online mail order companies for fi tness equipment.
- Page 28 Notes...
- Page 29 Notes...
- Page 30 Notes...
