Skanholz Tokio 4 Manual

Tokio 4 402 x 402cm
Important information
We are pleased that you have chosen a product of SKAN HOLZ.
Please check the construction set for completeness using the position list in good time before starting con-
struction or commissioning your construction team. If individual parts are defective or missing, we will deliver
these as quickly as possible. However, we cannot refund the costs for any resulting construction delays to a
construction company.
Please understand that we cannot assume any guarantee for the following defects:
- incorrect storage before assembly
- incorrect anchoring with the ground or inadequate foundation (foundation according to statics)
- damage due to erection errors, e. g. the house is not level or not right-angled
- damage through a higher level of snow burden than statically envisaged. Recommendation: lad relief of
the roof by removing the snow layer
- storm damage (insurance cases) or violent destruction
- damage through any alteration to the design by the client
- natural formation of cracks, branch holes, twisting, decolouration or similar modification (natural
process; has no influence on the statics)
Storage information until construction :
- store pallet on a level and dry surface.
- Protect from exposure to sunlight and the influences of weather ; wood can warp drastically in a loose
condition!
Maintenance tips:
Please observe the attached information sheet "Care instructions/Colour treatment".
General tips and refers to:
-
1 Foundation according (to the structural calculations, not included in the scope of delivery): concrete C25/30,
strip foundation: w/h = 30/90cm, each 2 Ø 12 top and bottom, bow Ø 6, e < 20cm. Bottom panel: t=14cm,
Q188A, top and bottom throughout. Anchoring of the floor beams on the strip foundation using bolts M12,
e < 60cm (by customer).
-
2
For simplified installation and to guarantee the same height all round, mark the heights (plank height + 1mm) on
each corner post (see point 9).
-
3
The outer wall planks are screwed on to the frame from outside. At the ends, the screws are concealed by strips,
between which the planks are later screwed almost invisibly obliquely from above through the tongues. It is
essential that you drill here in advance, to prevent splitting the tongues.
-
4
The roof boards are placed up to the inside edge of the outer panel. The final roof board must be matched in
width. In the vicinity of the fixing timbers H16/58-00 (33cm), the roof boards must be cut out accordingly.
-
5
Laying the KSK-M membrane:
- Lay the membrane at right angles to the fall; also, begin at the lowest point of the roof (the eaves at the rear).
Roll off approx. 150 cm of the membrane and leave the protective film until it is aligned precisely on the
membrane. Adjust the membrane at the front and fix it in the best position while a person is kneeling on it.
Now pull off approx. 30 cm of the protective film on the entire width and bond this, beginning from the direc-
tion of fixing towards the edge.
- Leave enough membrane overhanging the edge of the roof to guarantee a sound and leakproof closure at
the edge. After the first membrane has bonded completely, now take the second and allow approx. 10 cm to
overlap. Roll it over well in the overlap area.
- After bonding the edges, trim with a cutter.
- We recommend clearing the roof during heavy snowfall!
-
If the door cannot be closed properly, this can be adjusted by turning the hinges.
6
© SKAN HOLZ Europe GmbH D-21227 Bendestorf. Technical modifications reserved. All dimensions are approximate dimensions. 01/2018
604357
