Summary of Contents for Pandora Gun Max

  • Page 3: Table Of Contents

    CONTENT 1.Mainboard Picture ·······················································2 1.1 JAMMA Interface Definition ······································ 3 1.2 Mainboard Features ··············································· 4 1.3 Mainboard Specification ·········································· 5 2.System Introduction ···················································· 6 3.System Setting 3.1 Key Setting ··························································· 7 3.2 Coin Setting ·························································· 7 3.3 Exit Mode ····························································· 8 3.4 Auto Exit ······························································...

  • Page 4: Mainboard Picture

    1.Mainboard Picture — 2 —...

  • Page 5: Jamma Interface Definition

    1.1 JAMMA Interface Definition 2P TABLE (Solder Side) 1P TABLE (Parts Side) GROUND GROUND GROUND GROUND 2P BUTTON R2 1P BUTTON R2 SETTING PAUSE COIN 2P START 1P START 2P UP 1P UP 2P DOWN 1P DOWN 2P LEFT 1P LEFT 2P RIGHT 2P RIGHT 2P BUTTON A...

  • Page 6: Mainboard Features

     Gun games only support home version now.  Pandora system based on Windows. It will be very easy to use. The user experience is the same as Pandora, but our PC has more powerful performance than normal Pandora.

  • Page 7: Mainboard Specification

    1.3 Mainboard Specification Intel Celeron N5095 DDR4 4G Configuration SD Card 240GB capacity System Pandora system base on Windows HDMI 1280*720 ( 720P) Video Output 1280*720 ( 720P) 1*HDMI 1*VGA 1*Power Input Port 2*USB Input Ports For Light Gun 2*USB Input Ports For Infrared Receiver Interface & Spare USB...

  • Page 8: System Introduction

    2. System Introduction START button for quick action: Fast switching between game list of 3D and Search. When you input letters to search, fast switching to search results, and then fast switching to clear results. Game Search Function: Games can be searched by first alphabet order(A-Z). Favourite games: Press C button to add games to the list,or remove them from the list.

  • Page 9: System Setting

    3. System Setting In the game menu or in the game, press the machine’s Setting button to enter the setting menu. The Setting button is red button inside the machine. 3.1 Key Setting: a. Key Testing: This project can test the use of joysticks, buttons and gamepads.

  • Page 10: Exit Mode

    3.3 Exit Mode: Long Press Menu: Long press the START button to exit game. Start+Coin: Press the START button and insert a coin to exit game. 3.4 Auto Exit: 3 Minutes Exit: When the player does not operate the game within 3 minutes, the game will exit automatically.

  • Page 11: Graphic Mode

    3.6 Graphic Mode: Open: This will significantly improve the quality of the image in the game, but it will sacrifice a little bit of performance of some games. 3.7 Language: Mainboard supports five languages. lt can be switched between English, Spanish, Korean.

  • Page 12: Edit Game List

    2)Edit Game List: This item can display or hide the games of home page, moving the joystick to select the game you want to hide, press A to hide or display the game, press B to hide all games,press C to display all games. 3)Game Time: This item will only works in console games and not free play mode.

  • Page 13: Time Notification Strategy

    5)Time notification Strategy: Open: The remaining time will always show on the top of screen during game. Close: The remaining time will only show when press the START button. 3.9 Account Management: Default password is 11111111. a)Clear Coins: This need to input current password,Once completed, this will clear the total currency of operating revenue and cannot be recovered.

  • Page 14: Restore Factory Settings

    c)Reset Password: lnput current password to reset the password to default. 3.10 Restore Factory Settings: lf you need to restore the factory settings, please select the factory reset option and press the A button to confirm.This will not restore the account management settings.

  • Page 15: Mainboard Abnormality And Diagnosis

    4. Mainboard Abnormality And Diagnosis Error Description Reason Approach 1.Power adapter Change the power No response after power is abnormal adapter of the same on and the power light is 2.Main board parameters or contact not on is abnormal your supplier Please check whether the HD cable or VGA cable is well...
