Summary of Contents for JZ T10 MATRIX LAMP
- Page 1 JZ_ T10 MATRIX LAMP User manual V1.0 2024.03...
-
Page 2: Reading Tips
Reading Tips Usage precautions 1. Please do not stare directly at the spotlight. 2. Please do not block or deform the heat dissipation fins on the back cover. 3. Please do not forcefully interfere with the stability and calibration of the lamp assembly. 4. - Page 3 Table of Contents Reading Tips ....................... 2 Usage precautions ......................2 Table of Contents ..............错误 ! 未定义书签。 Product Overview ....................4 Introduction ........................4 Component Names ......................4 Installation and startup ..................5 Supported aircraft types ....................5 Installation on the aircraft ..................... 5 Control with DJI PILOT 2 ...................
-
Page 4: Product Overview
Product Overview Introduction The JZ_T10 MATRIX LAMP, designed for DJI consumer drones. Using the same laser lamp bead and aspherical quartz concentrating lens of luxury car laser headlamps, combined with Fresnel plane lens, converging 14° sharp light column, effective lighting distance of 100m. The whole machine weighs only 20 grams, the original digital mode is precisely leveled, and the center of gravity of the head is not changed after installation. - Page 5 5. All the above steps should be performed with the aircraft powered off. First, turn on the remote controller and then power on the aircraft. *You can visit https://jzdrones.com//static/video/T10-Tutorials_en.mp4 to watch a detailed installation tutorial. T10 MATRIX LAMP © 2024 JIZHI Technology All rights reserved...
-
Page 6: Safety Precautions
Control with DJI PILOT 2 To connect to the DJI Pilot 2 app 1. Power on the aircraft and the remote controller, and ground the mobile device. 2. Once the connection is established, the T10 can control the light status and mode switching through the perception gimbal movement.
