Summary of Contents for ZKTeco TBM01
- Page 1 Installation Guide TBM01/TBM02 Version: 1.3 Due to the regular upgrades of systems and products, ZKTeco could not guarantee exact consistency between the actual product and the written information in this manual.
-
Page 2: Safety Instructions
Safety Instructions Please read this manual before installation, including important information related to the safety, installation, use and maintenance. Any operation not specified in this manual was not allowed. Improper use may damage the product or even injure people and property. Please keep this manual properly for the future use. - Page 3 It is forbidden to place objects or stand or walk when dropping the pole. This manual is not used as a basis for product style. If there is a problem that cannot be solved using this manual, please contact our company's customer service department.
- Page 4 Temporary parking vehicles can pick up the tickets from the TBM01 to enter the venue, pay with a small ticket and leave the venue. Fixed cars can enter and exit the venue by swiping cards.
- Page 5 1.2 Components TBM01: 8-inch LED Keyhole Display Screen Card Reading Area Paper Ticket Printer Indicator Print Ticket Button Heat Emission Hole Speaker TBM02: 8-inch LED Keyhole Display Screen Card Reading Area Paper Ticket Scanner Indicator Heat Emission Hole Speaker...
-
Page 6: Packing List
2 Packing List The package consists of the following items: Accessories TBM01 TBM02 Thermal Paper Rolls Power Cable Expansion Screw 4 * M12 4 * M12 Card Reader (optional, comes with an ID card for testing) -
Page 7: Installation And Commissioning
3.1 Speci cation for Intersection Installation Taking the safety island as an example, the specification matters of the intersection installation of the parking ticket dispenser are shown below. TBM02 Barrier Gate Entrance Channel Control room Barrier Gate TBM01 Safety island intersection installation specification diagram... - Page 8 3.2 Preparation To install the device you must have: A Screwdriver: To remove or install the screw on the device. A Pencil: To mark the screw hole. A Electric Drill: To drill holes in accordance to the marked screw holes. A Wrench: To secure the M12 expansion screw on the device.
-
Page 9: Installation
3.3 Installation The installation of the TBM01 and TBM02 is roughly the same. The following is an example of the installation of an TBM01. Place the device vertically on the concrete floor or on the safety island. According to the customer's requirements and referring to the site conditions, place the device on the installation location (3.5 meters from the device to the barrier gate, the nearest one is not... - Page 10 Draw the screw hole on the fixed hole with a pencil. 200mm Remove the device, and use an electric drill to drill holes according to the marks, the depth of the hole is better than the length of the screw. Clean up the fragments and dust after drilling, then place the device on the installation site again.
- Page 11 Align the device with the drilled holes. Then, insert the bolts accordingly and fix them with a wrench. Finally, insert the washer and nut, tighten it with a wrench. Bolt Washer ① ② 3.4 Commissioning After installing the parking ticket dispenser, please strictly follow the steps below to commission the parking ticket dispenser controller.
- Page 12 A paper ticket is a certificate used for temporary parking vehicles to enter and exit the parking lot, which is convenient for the control and management of non-card-swiping vehicles. Put the thermal paper rolls in the designated position of the TBM01. Fix the thermal paper rolls.
- Page 13 4 Connecting the Wiring Terminal Paper ticket Close limit Ground sensing Wiegand power Wiegand out print button of the gate detector IO10 LED power Open limit QR code Speaker Ground supply of the gate scanner...
- Page 14 The wiring diagram of TBM01: Loop Detector Reader Wiring Red Black +12V AUX1 AUX2 AUX3 SPK- SPK+ GND +12V +12V COM1 COM2NO2 485A 485B CLOSE GND OPEN Printer 220 AC...
- Page 15 The wiring diagram of TBM02: Reader Wiring Red Black +12V AUX1 AUX2 AUX3 SPK- SPK+ GND +12V +12V COM1 COM2NO2 485A 485B CLOSE GND OPEN 220 AC...
- Page 16 5 Connect to the Server After the system hardware is tested and debugged, please install the server software on the computer, then add each controller in the server management software, and assign the IP address of each controller. After adding the controller to the server management software, you need to modify and confirm the controller's local IP address and server IP address.
- Page 17 6 The Debugging with ZKParking After installing and logging in ZKParking, by setting the relevant functions and parameters, you can control and manage the vehicles in the parking lot and maintain an orderly and civilized social phenomenon. Installation the ZKParking. →...
- Page 18 Login the ZKParking, and choose to register online or register offline. Setting the relevant functions and parameters.
- Page 19 For details, please refer to Parking Ticket Dispenser User Manual.
- Page 20 FAQs After entering the IP address of the Login Device in the Internet Explorer, the Login interface is not getting connected. To install the plugin and turn on the ActiveX control permissions, click "Internet options" - - "Security" -- "Custom level" -- "Enable all ActiveX controls and plugins" in the IE toolbar. When the card is placed close to the Parking ticket dispenser reader, a "beep"...
- Page 21 ZKTeco Industrial Park, No. 32, Industrial Road, Tangxia Town, Dongguan, China. Phone : +86 769 - 82109991 : +86 755 - 89602394 www.zkteco.com Copyright © 2022 ZKTECO CO., LTD. All Rights Reserved.
