Projector
CP-D10/CP-D20
User's Manual (concise)
Thank you for purchasing this projector.
Please read through this manual before using this product, in order to use safely
and utilize well the product.
WARNING ►Before using this product, be sure to read all manuals for this
product. See the "Using the CD manual" (16) to read the manuals in the CD.
After reading them, store them in a safe place for future reference.
►Heed all the warnings and cautions in the manuals or on the product.
►Follow all the instructions in the manuals or on the product.
NOTE • In this manual, unless any comments are accompanied, "the
manuals" means all the documents provided with this product, and "the product"
means this projector and all the accessories came with the projector.
Contents
First of all ............................................ 2
Important safety instruction ..............................2
Regulatory notices .............................. 3
Contents of package........................... 5
Loading batteries
Arrangement ....................................... 6
Connecting your devices .................... 8
Connecting power supply ................... 9
Turning on the power .......................... 9
Displaying the picture ....................... 11
3
Turning off the power ........................ 12
Replacing the lamp ........................... 13
Using the CD manual ....................... 16
Specifications ................................... 17
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-D20 and is the answer not in the manual?

Questions and answers

Related Manuals for Hitachi CP-D20

Summary of Contents for Hitachi CP-D20

  • Page 1: Table Of Contents

    Projector CP-D10/CP-D20 User's Manual (concise) Thank you for purchasing this projector. Please read through this manual before using this product, in order to use safely and utilize well the product. WARNING ►Before using this product, be sure to read all manuals for this product.

  • Page 2: First Of All

    First of all Entries and graphical symbols explanation The following entries and graphical symbols are used for the manuals and the product as follows, for safety purpose. Please know their meanings beforehand, and heed them. WARNING This entry warns of a risk of serious personal injury or even death. CAUTION This entry warns of a risk of personal injury or physical damage.

  • Page 3: Regulatory Notices

    Responsible Party Hitachi America, Ltd. Address 900 Hitachi way, Chula Vista, CA 91914-3556 U.S.A. Telephone Number +1 -800-225-1741 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.This equipment has...

  • Page 4: About Waste Electrical And Electronic Equipment

    Regulatory notices (continued) About Waste Electrical and Electronic Equipment The mark is in compliance with the Waste Electrical and Electronic Equipment Directive 2002/96/EC (WEEE). The mark indicates the requirement NOT to dispose the equipment including any spent or discarded batteries or accumulators as unsorted municipal waste, but use the return and collection systems available.

  • Page 5: Contents Of Package

    Holding the hook part of the battery cover, remove it. Align and insert the two AA batteries HITACHI MAXELL, Part No.LR6 or R6P according to their plus and minus terminals as indicated in the remote control. Replace the battery cover in the direction of the arrow and snap it back into place.

  • Page 6: Arrangement

    Arrangement <CP-D10> Refer to the illustrations and tables below to determine screen size and projection distance. The values shown in the table are calculated for a full size screen: 1024 x 768 a Screen size (diagonal) b Projection distance (±8%) c1 , c2 Screen height •...
  • Page 7 Arrangement (continued) <CP-D20> Refer to the illustrations and tables below to determine screen size and projection distance. The values shown in the table are calculated for a full size screen: 1024 x 768 a Screen size (diagonal) b Projection distance (±8%) c1 , c2 Screen height •...

  • Page 8: Connecting Your Devices

    Connecting your devices Be sure to read the manuals for devices before connecting them to the projector. Make sure that all the devices are suitable to be connected with this product, and prepare the cables required to connect. Please refer to the following illustrations to connect them.

  • Page 9: Connecting Power Supply

    Connecting power supply Put the connector of the power cord into the AC IN (AC inlet) of the projector. Firmly plug the power cord’s plug into the outlet. In a couple of seconds after the power supply connection, the POWER indicator will light up in steady orange.

  • Page 10: Adjusting The Projector's Elevator

    Adjusting the projector's elevator When the place to put the projector is slightly uneven to the left or right, use the elevator feet to place the 3° projector horizontally. Using the feet can also tilt the projector in order to project at a suitable angle to the screen, elevating the front side of the projector within 3 degrees.

  • Page 11: Displaying The Picture

    Displaying the picture Activate your signal source. Turn the signal source on, and make it send the signal to MY SOURCE/ VIDEO COMPUTER DOC.CAMERA the projector. AUTO ASPECT SEARCH BLANK VOLUME+ button FREEZE PAGE VOLUME MAGNIFY Use the VOLUME + / VOLUME - buttons VOLUME- button DOWN to adjust the volume.

  • Page 12: Turning Off The Power

    Turning off the power STANDBY/ON button Press the STANDBY/ON button on the POWER indicator projector or the remote control. INPUT STANDBY/ON MENU LAMP The message “Power off?” will appear on TEMP the screen for about 5 seconds. POWER Press the STANDBY/ON button again while the message appears.

  • Page 13: Replacing The Lamp

    Preparation of a new lamp and early replacement are recommended. To prepare a new lamp, make contact with your dealer and tell the lamp type number. Type number : <CP-D10>DT01091 / <CP-D20>DT01121 Turn the projector off, and unplug the power cord.
  • Page 14 Replacing the lamp (continued) HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE WARNING ►The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.

  • Page 15: Cleaning And Replacing The Air Filter

    Cleaning and replacing the air filter The air filter has two kinds of filters inside. Please check and clean the air filter periodically. When the indicators or a message prompts you to clean the air filter, comply with it as soon as possible.

  • Page 16: Using The Cd Manual

    Using the CD manual The other manuals for this product are written into the included CD-ROM titled “User’s Manual (detailed)”. Before using the CD-ROM, please read the following to ensure the proper use. System requirements The system for using the CD-ROM requires the following. Windows OS:Microsoft Windows...

  • Page 17: Specifications

    Specifications <CP-D10> Item Specification Product name Liquid crystal projector Liquid Crystal Panel 786,432 pixels (1024 horizontal x 768 vertical) Lamp 180 W UHB Speaker Power supply AC 100-120 V/2.8 A, AC220-240 V/1.4 A Power consumption 250 W Temperature range 5 ~ 35 °C (Operating) 333 (W) x 103 (H) x 303 (D) mm Size * Not including protruding parts.
  • Page 18 Specifications (continued) <CP-D20> Item Specification Product name Liquid crystal projector Liquid Crystal Panel 786,432 pixels (1024 horizontal x 768 vertical) Lamp 210 W UHP Speaker Power supply AC 100-120 V/3.2 A, AC 220-240 V/1.5 A Power consumption 280 W Temperature range 5 ~ 35 °C (Operating)

  • Page 19: Troubleshooting - Warranty And After-Service

    They will tell you what warranty condition is applied. Please check the following web address where you may find the latest information for this projector. http://www.hitachi.us/digitalmedia http://www.hitachidigitalmedia.com NOTE • The information in this manual is subject to change without notice.
