Detector Installation
The Pana40 Plus standard detectors have
been designed so that they can be mounted
flush with the leading edge, or as far back on
the car door as required in order to deter
vandalism.
Installation Notes 2D / 3D
1.
Use fixing kits provided with the detectors,
see below
'Mounting Diagram' different installations and
mounting kits.
2.
Detectors with the 'earth' wire must be fitted
to ensure that the unit is properly grounded.
3.
Plastic filter on 744 profiles has to be
removed before mounting; this is done by
removing top end cap screws and sliding
filter out. Once detector is fitted, slide filter
carefully back in with end cap.
Installation Notes 3D
1.
The detectors must be installed 5mm above
sill, and set no more than 10mm apart when
the doors are fully closed and aligned within
the detector's centre line. This is to ensure
reliable operation of the 3D self-test that is
performed when the doors have closed.
2.
The 3D TX detector should be mounted on
the left and the 3D RX on the right when
viewed from the landing.
3.
Detectors should be aligned as closely as
possible for reliable operation.
4.
3D Switch Settings are detailed on the inside
of the Main 3D Controller.
N56 W24720 N. Corporate Circle Sussex, WI 53089 • (800) 527-9156 • www.januselevator.com
Installation Guide
The Pana40 Plus 3D detectors must be
fitted flush with the door edge. This is to
allow the infra-red light for 3D operation to
project onto the landing.
4.
Position the detectors on the doors
approximately 5mm above the sill.
5.
Mark or spot through the 5 fixing holes.
6.
Remove the detectors from the door before
drilling.
7.
Screw the detector to the door using the fixing
kits provided.
8.
If the TX and RX detector positions are
reversed only on 2D profile then countersunk
screws can be used to screw the detector to
the door.
740-850-B44CL
Ver 1
09/21
