Summary of Contents for Schubert Prime Extend DP Box
- Page 1 Operating instructions Prime Extend DP Box Transmitter Standalone Box Version 1.20 19. Apr. 2022...
- Page 2 Designated use of the system Warning: Products from Schubert System Elektronik GmbH may only be used for the purposes intended in the technical documentation and only in conjunction with third party devices or components that are recommended or approved by us.
- Page 3 Prime Extend DP Box | To be observed in general Qualification of the personnel Only qualified personnel may perform the following work on the products: Installation, commissioning, operation, maintenance. Qualified personnel in the sense of the safety instructions are persons who are authorized to commission, ground and label devices, systems and circuits in accordance with the standards of safety engineering.
- Page 4 Germany Note The Operating instructions Prime Extend DP Box describes the Prime Extend DP Box on Transfer of video and USB data. Please read the Operating instructions before using the device for the first time and keep it in a safe place for later use.
-
Page 5: Table Of Contents
Prime Extend DP Box | Table of contents Table of contents Characteristics ......................... 3 Connections and transmission ..................4 Installation ........................5 Unpacking and checking delivery contents ..............5 Storage and transport ......................5 Installation .......................... 6 2.3.1 Temperature ........................6 2.3.2... - Page 6 Plug connector for 5 V DC / 12 V DC / 24 V DC and functional ground ....11 Fig. 3-3: Connections to the peripherals .................12 Fig. 3-4: Interface Prime Extend – LEDs ..................13 Fig. 4-1: Prime Extend DP Box – Device- and installation dimensions ........16 Operating instructions 1.20 Page 2 of 17...
-
Page 7: Characteristics
Max. transmission distance 100 m All signals are transmitted via a single CAT Ethernet cable. This requires the standalone Prime Extend DP Box as the transmitter (TX) on the computer side and the corresponding receiver (RX) on the terminal side. -
Page 8: Connections And Transmission
The graphics interface supports a maximum resolution of 1920 x 1200 pixels at 60 Hz and offers latency-free transmission in full HD. In addition, the Prime Extend DP Box has to be connected to the USB interface of the box PC and a separate power supply (5V/12V/24V). -
Page 9: Installation
Prime Extend DP Box | Installation Installation Unpacking and checking delivery contents ◼ Check the packaging of the Prime Extend DP Box for transport damage. ◼ Remove the packaging carefully to avoid damage. Keep the original packaging in case you need to transport the Prime Extend DP Box again. -
Page 10: Installation
The Prime Extend DP Box is designed for operation in closed rooms. The following points are to be observed to ensure trouble-free operation of the Prime Extend DP Box and to avoid damage. Please also refer to the “Technical data” chapter when installing the Prime Extend DP Box . 2.3.1 Temperature ◼... -
Page 11: Installation Position And Mounting
Prime Extend DP Box | Installation 2.3.3 Installation position and mounting The Prime Extend DP Box is designed for installation in control cabinets. The unit is installed on a top-hat rail in a vertical position with the power supply facing upwards. -
Page 12: Connection, Commissioning And Operation
The earth connection takes place via a terminal in the supply plug. Warning: Do not open the device The Prime Extend DP Box is a fully configured device. An extension by the user is not intended. WARNING... -
Page 13: Expanding The Prime Extend Dp Box
(ESD guidelines). ◼ Before plugging in the cables, the static charge of your body, that of the Prime Extend DP Box and the cables must be brought to the same potential. ◼ Divert electrostatic charges from your tools. ◼... -
Page 14: Connecting The Power Supply
Prime Extend DP Box | Connection, commissioning and operation Connecting the power supply Supply voltage 5 V DC / 12 V DC / 24 V DC Warning: The device has to be supplied by SELV- or PELV-circuits, rated 24 VDC (4.6…31.2 V) according UL/EN 61010-2-201. -
Page 15: Plug Connector For 5 V Dc / 12 V Dc / 24 V Dc And Functional Ground
Plug connector for 5 V DC / 12 V DC / 24 V DC and functional ground Supply voltage 5 V DC, 12 V DC or 24 V DC The Prime Extend DP Box can be supplied with one of these three voltages and automatically detects the respective power supply. -
Page 16: Connecting Peripheral Devices
Prime Extend DP Box | Connection, commissioning and operation Connecting peripheral devices 3.4.1 Access and arrangement of connections The connections to the peripherals are located on the front of the housing. Fig. 3-3: Connections to the peripherals Connections are standardized contacts with the known standard pin assignments. -
Page 17: Interfaces
The interface is to be connected to the DisplayPort on the box PC. Prime Extend ◼ The Prime Extend DP Box is to be connected to the remote operator terminal via this interface. A standardized CAT-6a Ethernet cable must be used for the connection. -
Page 18: Technical Data
Prime Extend DP Box | Technical data Technical data General Component Description Designation Device system Transfer of video and USB data Prime Extend Transmitter Standalone Box Prime Extend DP Box Material no. 63 10 068 Housing Insulated housing, built-in unit... - Page 19 Prime Extend DP Box | Technical data Component Description Ambient temperature range Operation -20 ºC to +50 ºC Vertical installation position [power supply upwards] with natural convection Storage/transport -20 ºC to +55 ºC Relative humidity 10% … 80%, non-condensing Ambient atmosphere...
-
Page 20: Mechanical Dimensions
Prime Extend DP Box | Technical data Mechanical dimensions Dimensions in mm General tolerance ISO 2768 – mK Fig. 4-1: Prime Extend DP Box – Device- and installation dimensions Operating instructions 1.20 Page 16 of 17... - Page 21 The forwarding or reproduction of this document as well as the use or disclosure of its contents are prohibited unless expressly permitted. Any violations will result in compensation claims. All rights reserved in the case of the granting of a patent or utility model registration. Schubert System Elektronik GmbH take-off Gewerbepark 36 Tel. + 49 7467 9497-0 info@schubert-system-elektronik.de...
