- Page 2 CyberTank Antenna Installation Guide KAC926...
-
Page 3: Table Of Contents
Thank you for buying this Kress Commercial product. We are dedicated to developing high quality products to meet your commercial landscaping requirements. The Kress brand is synonymous with premium quality service. Over the years of your product's life, if you have any questions or concerns about your product, please... - Page 4 We are confident you will enjoy working with your Kress product for years to come. INTENDED USE The product is intended for enhancing the 4G signal for the CyberTank in closed environments.
-
Page 5: Component List
COMPONENT LIST ANTENNA SIGNAL TRANSMISSION CABLE... -
Page 6: Product Safety
PRODUCT SAFETY expressly approved by the party responsible for compliance could void the user’s authority to operate GENERAL SAFETY WARN- the equipment. c) NOTE: This equipment generates, uses and can INGS radiate radio frequency energy and, if not installed and used in accordance with the instructions, may WARNING Read all safety warnings and cause harmful interference to radio communications. - Page 7 Maintenance ABN: Australian Business 1) Have your equipment serviced by a qualified repair Number. By this number, business person using only identical replacement parts. information such as entity type, This will ensure that the safety of the equipment is status, business location etc. can maintained.
- Page 8 CYBERTANK ANTENNA Pickup + Box Trailer INSTALLATION GUIDE Recommended installation position for dif- ferent vehicles Box Truck...
-
Page 9: Assembly
when drilling the hole. Assemble the antenna with the vehicle. ASSEMBLY Use a hole saw attachment (1.2 in/30mm) on your power Tool to create a hole above the position where the CyberTank is located NOTE: It is important to ensure that the hole is drilled on a flat surface and is at a safe distance from any electrical systems, such as wire harnesses, to avoid damaging them. - Page 10 Connect the antenna with your CyberTank. NOTE: Connect the cable to the 4G and GPS port respectively.
- Page 11 strength of the signal in your current location, and an external antenna only enhances the signal strength within an enclosed environment. SETTING UP THE ANTENNA IN APP Read App Download and Connection Guide and con- nect your CyberTank with the APP. To enable the external antenna to function properly, follow the instructions in the app to switch from the built-in antenna to the external one.
-
Page 12: Technical Data
TECHNICAL DATA KAC926 Cable length Weight 200 g Technical data for 4G Maximum Average Band TX (MHz) RX (MHz) Conducted Output Power (dBm) GSM 900 880-915 925-960 35.00 DCS 1800 1710-1785 1805-1880 32.00 WCDMA Band I 1920-1980 2110-2170 26.00 WCDMA Band V... - Page 13 LTE Band 8 880-915 925-960 25.00 LTE Band 28 703-748 758-803 25.00 LTE Band 40 2300-2400 2300-2400 25.00 Technical data for GPS TX (MHz) RX (MHz) GPS L1 1559-1610 GLONASS G1 1559-1610 1559-1610 Calileo (E1) 1559-1610...
- Page 14 ENVIRONMENTAL PROTECTION Environmentally friendly disposal Old electrical appliances must not be disposed of together with the residual waste, but have to be disposed of separately. The disposal at the communal collecting point via private persons is for free. The owner of old appliances is responsible to bring the appliances to these collecting points or to similar collection points.
- Page 16 Copyright © 2023, Positec. All Rights Reserved. V0-AU-KAC926-M-20230529...
