Page 1
H a n d C o f f e e G r i n d e r U S E R M A N U A L This user manual applies to the GOAT STORY ARCO Hand Grinder. Please read through this manual before using the grinder.
Page 3
Thank you for choosing ARCO hand coffee grinder! ARCO makes it easy to grind coffee for any brewing method - from ibrik to cold brew - by hand and with spectacular laboratory tested grind precision. All this can only lead to one result – a stellar cup coffee.
Page 4
ARCO HAND GRINDER The ARCO hand grinder is a versatile high precision coffee grinder with 240 easy to adjust grind settings. How to grind coffee with ARCO Hand Grinder: 1. Add coffee into the opening. 2. Attach the hand crank.
GRIND ADJUSTMENT The ARCO grind adjustment system has a total of 240 grind settings that range from very fine (e.g. for ibrik) to very coarse (e.g. for cold brew). The setting system has a setting ring on the outer body of the grinder that allows for quick and accurate grind adjustment.
Page 6
GRIND SIZE CHART ZERO POINT 60 CLICKS 120 CLICKS 180 CLICKS Recommended grind settings: IBRIK ESPRESSO MOKA POT FILTER FRENCH PRESS COLD BREW 0/0-35 0/30-60 1/0-40 1/30–2/20 2/0-60 3/0-60...
Page 7
REMOVING THE BURRS To clean the burrs, you need to disassemble the grinder and remove the inner burr from the grinder. A special tool is needed and is included in the box. Step 1 Insert the burr axe locker into the disassembly hole in the nut and align with the hole in the grinder body.
Page 8
Step 2 Attach the hand crank and turn counterclockwise (to the left) until the shaft is released from the grinder body. TURN LEFT (DISASSEMBLY) TURN RIGHT (ASSEMBLY) HAND CRANK...
Step 3 To assemble the grinder, insert the shaft with all parts in the correct order. Turn the handle clockwise until you feel resistance. Do not overtighten! IMPORTANT: Remove the burr axe locker after cleaning to avoid damage to the grinder!!! CENTRAL SHAFT DANISH SPRING SPACER...
PRODUCT SPECIFICATIONS U n i t d i m e n s i o n s / m m ( H × W × D ) 2 0 0 × 1 9 0 × 6 2 m m U n i t d i m e n s i o n s / I n c h ( H ×...
Page 11
If you submit a valid claim under this warranty, EQUA d.o.o. will either repair, replace or refund your ARCO hand coffee grinder at its own discretion. The benefits of this warranty are in addition to laws provided under local consumer laws.
