PRODUCT MANUAL

72" BBS0202B72 PICK UP SWEEPER

Please read the product manual completely before assembly Check

against the parts list to make sure all parts are received

Wear proper safety goggles or other protective gears while in assembly

Table of Contents

Need help?

Do you have a question about the BBS0202B72 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nexus BBS0202B72

Page 1 PRODUCT MANUAL 72" BBS0202B72 PICK UP SWEEPER Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly...
Page 2: Table Of Contents
TABLE OF CONTENTS TO THE OWNER..........................3/19 SAFETY PRECAUTIONS........................4/19 PICK UP SWEEPER ASSEMBLY......................8/19 OPERATION INSTRUCTIONS......................14/19 MAINTENANCE INSTRUCTIONS.......................17/19 STORAGE INSTRUCTIONS........................18/19 SPECIFICATIONS..........................19/19...
Page 3: To The Owner
TO THE OWNER GENERAL COMMENTS Congratulations for having this concrete mixer! Your concrete mixer was carefully designed and manufactured to give you years of dependable service. Your concrete mixer will require some minor maintenance(such as cleaning and lubricating) to keep it in top working condition. Be sure to observe all safety precautions and maintenance procedures as described in this manual.
Page 4: Safety Precautions
SAFETY PRECAUTIONS The concrete mixers are designed to be easy to use and maintain. They are operated by the skid steer auxiliary hydraulics. The concrete mixers mount to the toolbar or quick attach mechanism for easy mounting. BEFORE OPERATION 1. The operator must read the operation manual carefully before installation, operation or maintenance.
Page 5 SAFETY PRECAUTIONS These are common practices that may or may not be applicable to the products described in this manual.
Page 6 SAFETY PRECAUTIONS...
Page 7 SAFETY PRECAUTIONS...
Page 8: Pick Up Sweeper Assembly
PICK UP SWEEPER ASSEMBLY...
Page 10 PICK UP SWEEPER ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE GB2673-2000 0202B72-01 ScrewsM12X35 GB97.1-2000 0202B72-02 Flat mat 12 GB93-2000 0202B72-03 Spring washer12 GB6170-2000 0202B72-04 Nut M12 0202B72-05 Wear- resistant plate 0202B72-06 Rear bucket 0202B72-07 Nylon cover GB5783-2000 0202B72-08 BoltM8X30 GB97.1-2000 0202B72-09...
Page 11 PICK UP SWEEPER ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 0202B72-24 Homemade flat mat 0202B72-25 0202B72-26 Bolt M8X30 GB5783-2000 0202B72-27 Flat mat8 GB97.1-2000 0202B72-28 Spring washer 8 GB93-2000 0202B72-29 Rear-push plate 0202B72-30 Rear dust-shielding plate 0202B72-31 ScrewsM5*20 GB/T 70.2-2000 0202B72-32 Pedals 0202B72-33...
Page 12 PICK UP SWEEPER ASSEMBLY PART NO. S/N NUMBER PART DESCRIPTION QTYS NOTE 0202B72-52 Spring washerD8 0202B72-53 Motor shield 0202B72-54 Bolt M12*40 0202B72-55 Spring washerD12 0202B72-56 Flat matD12 0202B72-57 Bolt M12 0202B72-58 Motor 0202B72-59 Cotter pinsD6*80 0202B72-60 Engine-mounting plate 0202B72-61 Screws M8*30 0202B72-62 Spring washerD8 0202B72-63...
Page 13 97.1-1985 0202B72-78 Nut M12 GB6170-2000 0202B72-79 Bolt M8*20 GB/T 5783-2000 0202B72-80 Flat mat D8 GB/T 97.1-1985 0202B72-81 Spring washerD8 GB/T 93-1987 0202B72-82 Bearing shield 0202B72-83 Right angle elbow A 0202B72-84 Straight connectorA 0202B72-85 Quick coupling A(female ) Oil drain port 0202B72-86 Right angle elbowB 0202B72-87...
Page 14: Operation Instructions
OPERATION INSTRUCTIONS THE MAIN FEATURES OF THE PRODUCT The pick up sweeper can be installed on machines such as skid loaders, small loaders, etc. . It can clean dust and waste on the road surface and quickly clean parking lots, sidewalks, docks, warehouses and ports. The trash can be cleaned in the hopper, put into the designated position.
Page 15 4. When operating the sweeper on rough terrain, reduce speed to prevent the sweeper from jumping and minimize damage to the sweeper. 5. Keep away from people, buildings, vehicles, or other items that could be easily damaged 6. According to the actual road conditions to adjust the sweeper speed and the host speed.
Page 16 Sweeper work diagram 5 .In order to reduce the brush wear ,should minimize the sweep down pressure action. After using for a period of time should check the brush wear, and by adjusting the bolt to adjust the brush compaction, to ensure a better cleaning effect.
Page 17: Maintenance Instructions
MAINTENANCE INSTRUCTIONS 1. Check the security label.Replace damaged or blurred labels in a timely manner. 2.Please pay attention to protect the product nameplate, product nameplate missing or missing will not be able to warranty. 3. Check the brush wear ,adjust or replace brush in time. 4.
Page 18: Storage Instructions
STORAGE INSTRUCTIONS 1. Before storage, should be the product on the soil, dirt, grease clean. The hydraulic oil pipe and motor interface are covered and sealed. 2. The product should be stored in a dry non-corrosive environment to avoid corrosion. 3.Storage the brush must not touch the ground, in order to prevent long-term bending deformation of the brush, affect the use of the effect of the brush.
Page 19: Specifications
SPECIFICATIONS MODEL BBS0202B72 TOTAL LENGTH (MM) 1325 TOTAL WIDTH (MM) 2100 TOTAL HEIGHT (MM) TOTAL WEIGHT (KGS) BUCKET CAPACITY (M3 ) 0.46 EFFECTIVE CLEAN WIDTH(MM) 1830 φ550 BRUSH ROLL DIAMETER (MM) ALLOW MAXIMUM PRESSURE(MPA) SYSTEM FLOW (L/MIN) 50-70 ADAPTIVE MACHINE...
