Nematron Smart T6009 User Manual

Based mini-itx m/b
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Based Mini-ITX M/B
Trademark:
*
Specifications and Information contained in this documentation are
furnished for information use only, and are subject to change at any time
without notice, and should not be construed as a commitment by
manufacturer.
Smart T6009
®
Intel
H310 Express Chipset
User's Manual
Revision: 2.0
Release date: December 8, 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart T6009 and is the answer not in the manual?

Questions and answers

Related Manuals for Nematron Smart T6009

Summary of Contents for Nematron Smart T6009

  • Page 1 Smart T6009 ® Intel H310 Express Chipset Based Mini-ITX M/B User's Manual Revision: 2.0 Release date: December 8, 2022 Trademark: Specifications and Information contained in this documentation are furnished for information use only, and are subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

  • Page 2: Table Of Contents

    Preface Table Of Content Environmental Protection Announcement ........ 2 Environmental Safety Instruction ..........2 USER’S NOTICE ................3 Manual Revision Information............3 Item Checklist ................4 Chapter 1 Introduction of the Motherboard ......5 1-1 Feature of Motherboard ..............5 1-2 Specification ...................

  • Page 3: Environmental Protection Announcement

    Preface Environmental Protection Announcement Do not dispose this electronic device into the trash while discarding. To minimize pollution and ensure environment protection of mother earth, please recycle. Environmental Safety Instruction ⚫ Avoid the dusty, humidity and temperature extremes. Do not place the product in any area where it may become wet.

  • Page 4: User's Notice

    Preface ⚫ The increasing temperature of the capacitor may decrease the life of computer. Using the close case may decrease the life of other device because the higher temperature in the inner of the case. ⚫ Attention to the heat sink when you over-clocking. The higher temperature may decrease the life of the device and burned the capacitor.

  • Page 5: Item Checklist

    Preface Item Checklist  Motherboard  Cable(s)

  • Page 6: Chapter 1 Introduction Of The Motherboard

    Chapter 1 Introduction of the Motherboard Chapter 1 Introduction of the Motherboard 1-1 Feature of Motherboard ⚫ ® Intel H310 express chipset ⚫ ® LGA1151 CPU socket supports Intel Coffee Lake-S series processor (TDP﹤65W) ⚫ Support DC 12~24V Input ⚫ Support 2×DDR4 2133MHz SO-DIMM up to 64GB ⚫...
  • Page 7 Chapter 1 Introduction of the Motherboard ⚫ 1×M.2 E-key slot, type-2230 with PCIe interface (M2E) ⚫ 1×SATAIII 6G/s port (SATA1) Storage ⚫ 1×M.2 M-key slot, type-2242 with SATA interface (M2M) ⚫ Integrated with 1×Intel I219-V 1.0Gigabit Ethernet LAN chip ⚫ Integrated with 1×Intel I225V 2.5Gigabit Ethernet LAN LAN Chip chip...

  • Page 8: Layout Diagram

    Chapter 1 Introduction of the Motherboard ⚫ 1×eDP wafer 1-3 Layout Diagram Rear IO Diagram Motherboard Internal Diagram-Front...
  • Page 9 Chapter 1 Introduction of the Motherboard Motherboard Jumper Position: Connectors Name DCIN1 12V~24V DC–in Power Jack VGA Port Connector HDMI HDMI Port Connector USB1/USB2 USB 3.0 Port Connector X4 LAN1 1.0Gbps RJ-45 LAN Connector LAN 2 2.5Gbps RJ-45 LAN Connector HMIC Audio MIC Connector HOUT...
  • Page 10 Chapter 1 Introduction of the Motherboard Headers & Wafer Name Description Pitch Front Panel Header (PWR LED / 9-pin Block 2.54mm HD LED / Power Button / Reset) FP_USB1/ USB 2.0 Port Headers 9-pin Block 2.0mm FP_USB2 FP_USB3 USB 2.0 Port Header 4-pin Block 2.0mm PS2KBMS...

  • Page 11: Chapter 2 Hardware Installation

    Chapter 2 Hardware Installation Chapter 2 Hardware Installation 2-1 Jumper Setting JBAT (3-pin): Clear CMOS RAM Settings Pitch=2.0mm JAT_ATX(3-pin): ATX Mode/ AT Mode Select Pitch=2.0mm *ATX Mode Selected: Press power button to power on after power input ready; AT Mode Selected: Directly power on as power input ready.
  • Page 12 Chapter 2 Hardware Installation JP2 (2-pin): ME Features Select Pitch=2.0mm COPEN (2-pin): Case Open Message Display Function Pitch=2.0mm Pin 1-2 Short: When Case open function pin short to GND, the Case open function was detected. When Used, needs to enter BIOS and enable ‘Case Open Detect’...
  • Page 13 Chapter 2 Hardware Installation JP5 (4-pin): LVDS Panel Power VCC Select Pitch=2.0mm JP16 (3-pin): LVDS Inverter Backlight VCC Select Pitch=2.0mm JP12 (4-pin): COM1 Pin9 Function Select Pitch=2.0mm...

  • Page 14: Connectors, Headers And Wafers

    Chapter 2 Hardware Installation JP13 (4-pin): COM2 Pin9 Function Select Pitch=2.0mm 2-2 Connectors, Headers and Wafers 2-2-1 Connectors (1) Rear Panel Connectors *Refer to Page-3 Rear IO Diagram. Icon Name Function 12V~24V DC–in system power connector DC-In For user to connect compatible power adapter Power Jack to provide power supply for the system.
  • Page 15 Chapter 2 Hardware Installation (2) DCIN3 (2-pin block):Internal 12V~24V Power Connector Pin No. Definition +12V～24V Warning: Find Pin-1 position before connecting power cable to this 2-pin power connector. WRONG INSTALLATION DIRECTION WILL DAMAGE THE BOARD!! (3) CPUFAN (4-pin): CPU Fan Connector...
  • Page 16 Chapter 2 Hardware Installation (4) SYSFAN (4-pin): System Fan Connector (5) SATA1 (7-pin): SATA III Port connector SATA1 is a high-speed SATAIII port that supports 6GB/s transfer rate. Pin No. Definition (6) PWROUT (4-pin): SATA Power Out Connector Warning: Make sure that Pin-1 of compatible SATA Power connector is inserted into corresponding Pin-1 of SATAPW to avoid possible damage to the board and hard disk driver!

  • Page 17: Headers & Wafers

    Chapter 2 Hardware Installation (7) BATCON (2-pin): Battery Connector 2-2-2 Headers & Wafers (1) FP (9-pin): Front Panel Header Pitch=2.54mm (2) FP_USB1/FP_USB2 (9-pin): USB 2.0 Port Headers Pitch=2.0mm...
  • Page 18 Chapter 2 Hardware Installation (3) FP_USB3 (4-pin): USB 2.0 Port Header Pitch=2.0mm (4) PS2KBMS (6-pin): PS/2 Keyboard & Mouse Header Pitch=2.0mm (5) SMBUS (5-Pin): SMBUS Header Pitch=2.0mm (6) FP_AUDIO (9-pin): Front Panel Audio Header Pitch=2.0mm This header connects to Front Panel Line-out, MIC-In connector with cable.
  • Page 19 Chapter 2 Hardware Installation (7) SPEAK_CON (4-pin): 3W Amplifier Wafer Pitch=2.0mm Pin No. Definition (8) COM1/2/3/4 (9-pin): RS232 Serial Port Header Pitch=2.0mm...
  • Page 20 Chapter 2 Hardware Installation (9) GPIO (10-pin): GPIO Header Pitch=2.54mm (10) INVERTER1 (6-Pin): LVDS Inverter Header Pitch=2.0mm Pin No. Definition BKLT_PWR1 BKLT_PWR2 BKLT_EN BKLT_PWM GND1 GND2 Warning! Find Pin-1 location of the inverter and make sure that the installation direction is correct! Otherwise serious harm will occur to the board/display panel!! (11) LVDS (30-Pin): LVDS Port Wafer Pitch=1.25mm...
  • Page 21 Chapter 2 Hardware Installation Pin NO. Pin Define Pin NO. Pin Define Pin 1 LVDSB_DATAN3 Pin 2 LVDSB_DATAP3 Pin 3 LVDS_CLKBN Pin 4 LVDS_CLKBP Pin 5 LVDSB_DATAN2 Pin 6 LVDSB_DATAP2 Pin 7 LVDSB_DATAN1 Pin 8 LVDSB_DATAP1 Pin 9 LVDSB_DATAN0 Pin 10 LVDSB_DATAP0 Pin 11 NC/DDC_DATA...
  • Page 22 Chapter 2 Hardware Installation Pin 6 Lane2_N Pin 26 Pin 7 Lane2_P Pin 27 Pin 8 Pin 28 Pin 9 Lane1_N Pin 29 Pin 10 Lane1_P Pin 30 Pin 11 Pin 31 Pin 12 Lane0_N Pin 32 BL_ENABLE Pin 13 Lane0_P Pin 33 BL_PWM_DIM...

  • Page 23: Chapter 3 Introducing Bios

    Chapter 3 Introducing BIOS Chapter 3 Introducing BIOS Notice! The BIOS options in this manual are for reference only. Different configurations may lead to difference in BIOS screen and BIOS screens in manuals are usually the first BIOS version when the board is released and may be different from your purchased motherboard.

  • Page 24: Function Keys

    Chapter 3 Introducing BIOS The following diagram show a general BIOS menu screen: BIOS Menu Screen 3-3 Function Keys In the above BIOS Setup main menu of, you can see several options. We will explain these options step by step in the following pages of this chapter, but let us first see a short description of the function keys you may use here: ⚫...

  • Page 25: Menu Bars

    Chapter 3 Introducing BIOS Main Menu The on-line description of the highlighted setup function is displayed at the top right corner the screen. Status Page Setup Menu/Option Page Setup Menu Press [F1] to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.

  • Page 26: Advanced Menu

    Chapter 3 Introducing BIOS System Date Set the date. Please use [Tab] to switch between date elements. System Time Set the time. Please use [Tab] to switch between time elements. 3-7 Advanced Menu ► Connectivity Configuration Use this item to configure Connectivity related options. Press [Enter] to...
  • Page 27 Chapter 3 Introducing BIOS make settings for the following sub-items: CNVi present CNVi Configuration CNVi Mode This option configures Connectivity. The optional settings: [Disabled Integrated]; [Auto Detection]. [Auto Detection] means that if Discrete Solution is discovered it will be enabled by default. Otherwise Integrated Solution (CNVi) will be enabled; [Disabled Integrated] disables Integrated Solution.
  • Page 28 Chapter 3 Introducing BIOS Port Use this item to enable or disable device connected respective port. The optional settings: [Disabled]; [Enabled]. Hot Plug Use this item to Designates this port as Hot Pluggable The optional settings: [Disabled]; [Enabled]. Port The optional settings: [Disabled]; [Enabled]. Use this item to enable or disable M2M port.
  • Page 29 Chapter 3 Introducing BIOS ACPI Sleep State Use this item to select the highest ACPI sleep state the system will enter when the suspend button is pressed. The optional settings are: [Suspend Disabled]; [S3 (Suspend to RAM)]. ► Wake-up Function Settings Press [Enter] to make settings for the following sub-items: Wake-up System with Fixed Time Use this item to enable or disable system wake on alarm event.
  • Page 30 Chapter 3 Introducing BIOS ► Super I/O Configuration Press [Enter] to make settings for the following sub-items: Super IO Configuration ERP Support The optional settings: [Disabled]; [Auto]. *Note: This item should be set as [Disabled] if you wish to have all active wake-up functions.
  • Page 31 Chapter 3 Introducing BIOS Change Settings Use this item to select an optimal setting for super IO device. Changing setting may conflict with system resources. The optional settings: [IO=3E8h; IRQ=11]; [IO=3F8h; IRQ=3,4,5,7,10,11] ; [IO=2F8h; IRQ=3,4,5,7,10,11] ; [IO=3E8h; IRQ=3,4,5,7,10,11] ; [IO=2E8h; IRQ=3,4,5,7,10,11] ]; [IO=3E0h; IRQ=3,4,5,7,10,11] ];...
  • Page 32 Chapter 3 Introducing BIOS settings in ‘SmartFAN Configuration’. ► SmartFAN Configuration Press [Enter] to make settings for SmartFan Configuration: SmartFAN Configuration CPUFAN / SYSFAN Smart Mode The optional settings are: [Disabled]; [Enabled]. When set as [Enabled], the following sub-items shall appear: CPUFAN / SYSFAN Full-Speed Temperature Use this item to set CPUFAN/SYSFAN full speed temperature.
  • Page 33 Chapter 3 Introducing BIOS Data Bits The optional settings: [7]; [8]. Parity A parity bit can be sent with the data bits to detect some transmission errors. The optional settings: [None]; [Even]; [Odd]; [Mark]; [Space]. [Even]: parity bit is 0 if the num of 1’s in the data bits is even; [Odd]: parity bit is 0 if num of 1’s in the data bits is odd;...
  • Page 34 Chapter 3 Introducing BIOS Console Redirection Settings Redirection COM Port For user to select a COM port to display redirection of legacy OS and Legacy OPROM messages. The optional settings are: [COM1]; [COM1(Pci Bus0, Dev0, Func0) (Disabled)]. Resolution This item is for user to select the number of Rows and Columns supported redirection.
  • Page 35 Chapter 3 Introducing BIOS must be matched on the other side. Long or noisy lines may require lower speeds. The optional settings: [9600]; [19200]; [57600]; [115200]. Flow Control Flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a “stop” signal can be sent to stop the data flow.
  • Page 36 Chapter 3 Introducing BIOS Use this item to set the time-out value for control, bulk, and interrupt transfers. The optional settings are: [1 sec]; [5 sec]; [10 sec]; [20 sec]. Device reset time-out Use this item to set USB mass storage device start unit command time- out.

  • Page 37: Chipset Menu

    Chapter 3 Introducing BIOS Option ROM execution Network This option controls the execution of UEFI and Legacy PXE OpROM. The optional settings are: [Do not launch]; [Legacy]. Storage This option controls the execution of UEFI and Legacy Storage OpROM. The optional settings are: [Do not launch]; [UEFI]; [Legacy]. Other PCI devices This item is for PCI devices other than Network, Mass storage or video defines which OpROM to launch.
  • Page 38 Chapter 3 Introducing BIOS The optional settings are: [Enabled]; [Disabled]. ► Memory Configuration Press [Enter] to view brief information for the working memory module. ► Graphics Configuration Press [Enter] to make further settings for Graphics Configuration. Graphics Configuration Primary IGFX Boot Display Use this item to select the video device which will be activated during POST.
  • Page 39 Chapter 3 Introducing BIOS 768 24bit Single]; [1440 x 900 18bit Dual]; [1440 x 900 24bit Dual]; [1280 x 1024 24bit Dual]; [1680 x 1050 24bit Dual]; [1920 x 1080 24bit Dual]. ► PCH-IO Configuration Press [Enter] to make settings for the following sub-items: PCH-IO Configuration HD Audio This item controls detection of the HD-Audio device.

  • Page 40: Security Menu

    Chapter 3 Introducing BIOS 3-9 Security Menu Security menu allow users to change administrator password and user password settings. Administrator Password If there is no password present on system, please press [Enter] to create new administrator password. If password is present on system, please press [Enter] to verify old password then to clear/change password.
  • Page 41 Chapter 3 Introducing BIOS Standard mode. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication. *When set as [Custom], user can make further settings in the following items that show up: ►...

  • Page 42: Boot Menu

    Chapter 3 Introducing BIOS Public Key Certificate in: EFI_SIGNATURE_LIST EFI_ CERT_X509 (DER encoded) EFI_ CERT_RSA2048 (bin) EFI_ CERT_SHAXXX (bin) Authenticated UEFI Variable EFI PE/COFF Image (SHA256) Key Source: Factory, External, Mixed. 3-10 Boot Menu Boot Configuration Setup Prompt Timeout Use this item to set number of seconds to wait for setup activation key. Bootup Numlock State Use this item to select keyboard numlock state.
  • Page 43 Chapter 3 Introducing BIOS Save Options Save Changes and Reset This item allows user to reset the system after saving the changes. Discard Changes and Reset This item allows user to reset the system without saving any changes. Default Options Restore Defaults Use this item to restore /load default values for all the setup options.
