OWNER'S MANUAL
INSTALLATION INSTRUCTIONS
SARATOGA™ PATIO HEATER
ENCLOSED MODEL
MODEL NUMBER: PH1500
ASSEMBLY AND OPERATING INSTRUCTIONS
Optional Stand Accessory available: Model Number TP01
250 West Laurel Street, Colton CA 92324 • WWW.WILLIAMSCOMFORT.COM • 1-888-444-1212
VISITEZ NOTRE SITE WEB POUR LA VERSION FRANÇAISE DE CE MANUEL
VISITE NUESTRA PÁGINA WEB PARA LA VERSIÓN EN ESPAÑOL DE ESTE MANUAL
https://www.williamscomfort.com/product/saratoga-patio-heater/

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SARATOGA PH1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for Williams SARATOGA PH1500

  • Page 1 OWNER’S MANUAL VISITEZ NOTRE SITE WEB POUR LA VERSION FRANÇAISE DE CE MANUEL INSTALLATION INSTRUCTIONS VISITE NUESTRA PÁGINA WEB PARA LA VERSIÓN EN ESPAÑOL DE ESTE MANUAL https://www.williamscomfort.com/product/saratoga-patio-heater/ SARATOGA™ PATIO HEATER ENCLOSED MODEL MODEL NUMBER: PH1500 ASSEMBLY AND OPERATING INSTRUCTIONS Optional Stand Accessory available: Model Number TP01 250 West Laurel Street, Colton CA 92324 •...

  • Page 2: Warning Instructions

    WARNING INSTRUCTIONS THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND No liability can be accepted for any damage caused by RETAINED FOR FUTURE REFERENCE, non-compliance with these instructions or any other improper use or mishandling. We cannot be liable for any damages caused by failure to observe these instructions.
  • Page 3 soline, paint, or flammable liquids are used or stored. . Parts of the heater may exceed 200℃ , contact with the heating tube, reflector, or INSTRUCTIONS etal parts near the heating tube, may cause severe BURNS . To avoid burns, do not let re skin touch hot surface.

  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS Tools needed: This heater should be installed by a competent person, i.e. a qualified electrician. Pencil, Hammer, Level, Screw Driver, Power Drill and Drill Bits Always disconnect the heater from the electricity supply and allow it to cool before installation. A wall mounting bracket is provide with the heater which For ceiling mounting, the lowest part of the heater must has been specifically designed to allow this product to be...

  • Page 5: Proper Installation

    PROPER INSTALLATION Figure 2 - Position 1 WARNING: to reduce the risk of fire CAUTION: Keep combustible materials, such as furniture, pillows, curtains at least 3 feet (0.9m) from the front of the heater and keep them away from the sides and rear. CAUTION: Do NOT use outlet with an extension Figure 3 - Position 2 cord or relocatable power tap (outlet/power strip).
  • Page 6 ASSEMBLY INSTRUCTIONS Wall mounted installation Wall mounted installation Figure 5 - Wall Mounted Installation a) The heater must be properly installed before it is used. b) The heater can be used indoors or in a well-protected outdoor area. c) Instructions must be followed for user-operated devices intended to reduce the risk of fire, electric shock, and/or injury to persons.

  • Page 7: Power Button

    Figure 6 - Ceiling Mounted Installation REMOTE CONTROL INSTRUCTIONS Ceiling mounted installation The heater must be installed at least POWER BUTTON: Turn the heater off. UP BUTTON: Increase timer and level. Attention: cable should not passing tho Min. 20” DOWN BUTTON: Decrease timer and level. LEVEL BUTTON: Use to adjust the heat levels (L1-L3).

  • Page 8: Troubleshooting

    TROUBLESHOOTING Inserting Batteries (not included) Cleaning nsert 2 AAA/ Alkaline type batteries into your remote Regular and careful cleaning helps your infrared heater control operate efficiently for many trouble free years. To clean your heater follow steps below: Flip the backside of your remote control and pull out battery cover.
