Mail Boss Combination Lock Manual

1/2
MAIL BOSS
LOCKING SECURITY MAILBOXES
The Mail Boss combination lock with key override and customizable code retrieval capabilities offers
convenient keyless access and can be installed on any Mail Boss locking box. Below you will find a list of
hardware parts and detailed installation instructions. Please take the time to carefully sort the hardware and
familiarize yourself with the function of each piece for ease of installation.
If you require assistance with assembly, part replacement, or any other matter, contact the toll-free Epoch
Design Service Center from anywhere in the Continental United States, M-F 9 AM - 5 PM PST at 1-800-589-7990.
You may also email your request or comments to info@mailboss.com and a service representative will respond.
Additional helpful hints, tips and tricks can also be found on our website: www.mailboss.com.
A- Over-Ride Key
(Two provided)
F- Code Pin
Hooked
Cam
Over-Ride
Key Hole
Open
Reset Button
Combination Lock
Combination Lock
®
Parts and Hardware List
C- Large Nut
D- Washer
B- Combi-Lock
Set Your Own Combination: The combination can be changed in seconds
without special tools or disassembly.
• Set Numbered Dials to opening combination (factory default all 0's)
• Depress Reset Button and hold down while changing Numbered Dials
to desired combination.
• Release the Reset Button and the new combination is set.
Code Pin
Locked
Over-Ride Key
Have a question?... Need a part ASAP?...1-800-589-7990
Copyright © 2019 Epoch Design™ All rights reserved
®
F- Nut
*E- Mail Boss /
*E- Mail Manager /
Drop Box Cam
Package Master Cam
*E = The cam you receive/use will depend on the model/door of your Mail Boss
Finding unknown Combinations:
• Open the lock by using the Master Over-Ride Key.
• Remove the lock from the door by unscrewing the small
nut on the back side of the lock and removing the
Hooked Cam. Then remove the large nut holding the lock
to the door.
• With the lock removed from the box, insert the code pin
into one of the four holes centered on the back side of the
lock behind the Numbered Dials.
• Turn the dial associated with that inserted pin until it
stops.
• Repeat this step with the remaining three holes.
• When finished the numbers on the Dials will show your
combination, please write this combination down and
keep it safe yet accessible.
1-June-2020
Thank you.
*E- Street Safe /
Latitude Rear Cam
