HAND TRIGGER
& LANYARD
INSTRUCTION MANUAL
CODiScan Accessories
©2023-2024 Datalogic S.p.A. and/or its affiliates
• All rights reserved • Without limiting the rights
under copyright, no part of this documentation
may be reproduced, stored in or introduced into
a retrieval system, or transmitted in any form or
by any means, or for any purpose, without the
express written permission of Datalogic S.p.A.
and/or its affiliates • Datalogic and the Datalogic
logo are registered trademarks of Datalogic S.p.A.
in many countries, including the U.S. and the E.U.
www.datalogic.com
822004680 (Rev. A) January 2024
CODISCAN ACCESSORIES
CODiScan HS7600 can be used in standalone mode
or in conjunction with the following accessories to
extend user comfort:
y HT1-HS7600KR: Adjustable Right Hand Trigger
y HT1-HS7600KL: Adjustable Left Hand Trigger
y LH-HS7600: Extensible Lanyard for Neck and
Belt
NOTE: The adjustable hand trigger has
a different part number for right-and
left-handed users. Choose the part
number that best suits your needs.
The following spare parts are available for purchase:
y HT5-HS7600KR: Adjustable Right Hand Trigger
- 5 Pcs
y HT5-HS7600KL: Adjustable Left Hand Trigger - 5
Pcs
y SG5-HS7600KR: Spare Right Fabric - 5 Pcs
y SG5-HS7600KL: Spare Left Fabric - 5 Pcs
y ST1-HS7600K: Spare Trigger System (No Fabric)
- 1 Pc
y ST5-HS7600K: Spare Trigger System (No Fabric)
- 5 Pcs
y SS5-HS7600K: Spare Fabric - Adjustable Strap
Only - 5pcs
PARTS OF THE GLOVE
b.
c.
a.
d.
e.
a) Adjustable Straps
d) Closing strap
b) Trigger
e) Washable Fabric
c) Holder
WEARING THE HAND TRIGGER
Before wearing the hand trigger, make sure to cho-
ose the right part number whether you are right- or
left-handed.
To wear the hand trigger:
1. Put on the hand trigger on top of your hand and,
while holding the trigger in place with the thumb,
fasten it using the closing strap.
2. Adjust the size to comfortably fit your hand using
the adjustable straps.
3. Adjust the position of the trigger to reach it easily
with your thumb.
NOTE: After the first time, use only
the closing strap to wear the hand
trigger.
1
2
3
