BXB Electronics HDR-731 User Manual

Streaming media processor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HDR-731
Streaming Media Processor
User Manual
Publication date: September 2022 | Revision: V2.1.5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDR-731 and is the answer not in the manual?

Questions and answers

Related Manuals for BXB Electronics HDR-731

Summary of Contents for BXB Electronics HDR-731

  • Page 1 HDR-731 Streaming Media Processor User Manual Publication date: September 2022 | Revision: V2.1.5...

  • Page 2: Table Of Contents

    Table of Contents Quick Reference Guide……………………………………………. 1 Button………………….…………………. 123 Safety Instruction……………….…………………………………. 2 Remote Setting……….…………………. 124 System Diagram……………………………………………………. 3 Storage………………….…………………. 127 Description of the Panel …………………………………………. 4 Update………………….…………………. 128 Web GUI Interface Backup………………….…………………. 130 Log In………………………………………………….………. 6 Account……………………………………………. 132 Dashboard……………………………….…………………. 8 Panel Operation………………………………………………..

  • Page 3: Quick Reference Guide

    Quick Reference Guide Web GUI Interface Log In………………………………….…………….………. 6 Dashboard…………………………….…………….…….…. 8 Add Camera……………………………………………...…. 86 Template………………………………………………….…. 25 Schedule………………………………………………….…. 53 Media Center………………….……………………….…. 70 Streaming HLS ……………………………………………………….…. 97 Youtube …………………….…………………………..…. 103 Facebook …………………………………………….…. 109 HDMI 1 Director View……………………………………………..141 Panel Operation……………………………………………..…..136...

  • Page 4: Safety Instruction

    Safety Instruction Read the instruction manual carefully before installing and using this unit and keep this manual properly preserved. Please follow the instructions and be aware of warning indications. Do not use any spare parts without the recommendation of your dealer. Please use the fixing accessories offered by BXB. If the system is broken due to the improper fixing, BXB would not bear the responsibility for compensation.

  • Page 5: System Diagram

    System Diagram...

  • Page 6: Description Of The Panel

    Description of the Panel Front Panel 1. USB 3.0 port: connects USB hard disk drive to save files. 2. Recording function button: start/exit recording. 3. Streaming function button: start/exit live-streaming. 4. Layout switch button: switch layouts sequentially.
  • Page 7 Description of the Panel Rear Panel 1. CH1 input: connects HDMI, 3.5mm audio input as recording / 7. HDMI 1 output: outputs the director view to configure settings streaming signal. with mouse connected to USB port. 2. CH2 input: connects HDMI, 3.5mm audio input as recording / 8.
  • Page 8 Web GUI Interface Log In HDR-731 settings can be configured via web browser at the computers in the same domain of LAN. http://192.168.168.130 Choosing Web Browser HDR-731 can perform editing via currently popular web Enter the IP address of HDR-731 in URL bar (DHCP or browsers, such as Chrome, Safari and Microsoft Edge.
  • Page 9 Web GUI Interface Log In Select display language required . “Chinese”, “English” After entering ID and password, click “Log in” to enter and “Thai” are supported. management page after validation. The default ID is “admin”; password is “00000”.
  • Page 10 Web GUI Interface Dashboard_Setting of Video Source Connected HDMI 1~4 signals and the camera in LAN can be selected as video sources. To add a new camera, go to “Device” (refer to Page 86). Click the video source to be changed and then open the Select HDMI input signal source or the streaming camera signal source list.
  • Page 11 Web GUI Interface Dashboard_Setting of Video Source After applying, the real-time screen will change. If the selected signal source cannot be displayed normally, the system will remind with icon “Not Displayable” (within the blue frame). Please check the wiring of related equipment.
  • Page 12 Web GUI Interface Dashboard_Layout Switch The main layout can be selected to apply to the output screen. There are 9 main layouts. To add new layouts, you can go to “Template” page (details refer to Page 25). Select the icon “Layout Switch” on the tool bar. There are Click the layout to be applied.
  • Page 13 Web GUI Interface Dashboard_Layout Switch After applying the selected layout, the real-time screen of The HDMI 2 output screen, streaming and recording web management page will change as well. screen will be displayed based on the applied layout.
  • Page 14 Web GUI Interface Dashboard_Camera Control BXB's HDC-713, HDC-715 and HDC-716 cameras are supported. You can control camera screen and set/call the preset point screen of camera. It is suggested, when switching to camera control page, select camera signal as video source simultaneously to watch the real-time image. New added cameras must be set on “Device”...
  • Page 15 Web GUI Interface Dashboard_Camera Control Use navigation buttons to move camera screen or Adjust camera to the required angle and position, enter operate “+” & “-” to zoom in/out. the preset position number and then click “SET” to save the preset point. If it is necessary to call the preset point, just entering the preset position number and then click “Go”...
  • Page 16 Web GUI Interface Dashboard_Audio Setting HDR-731 has eight audio inputs and two audio outputs. You can manage the audio settings of recording, streaming and HDMI output via Dashboard page. Click to adjust the volume level of the corresponding Click the icon at the bottom of audio channel to turn on/off audio channel.

  • Page 17: Dashboard

    By will be compulsorily turned off and the eight input audio switching layout, HDR-731 will automatically adjust the channels cannot be turned on and their volume cannot be ON / OFF of the audio channel.
  • Page 18 Web GUI Interface Dashboard_Audio Setting Activate “Vol Indicator” mode, the audio input / output status will be displayed in real time on the volume level scale.
  • Page 19 Web GUI Interface Dashboard_Streaming HDR-731 supports live-streaming platform, HLS, RTMP and RTSP stream output. Before starting streaming, it is necessary to configure settings on “Streaming” page (Page 97). After starting streaming, the system will perform live-streaming on the platform based on your setting.

  • Page 20: Dashboard

    Web GUI Interface Dashboard_Streaming When streaming is in progress, icon “LIVE” will be After streaming is over, click icon “LIVE” again to displayed at the left upper corner of the real-time window disconnect the streaming platform. on dashboard.
  • Page 21 Web GUI Interface Dashboard_Recording The default recording mode is “PGM”. Streaming can be performed simultaneously during recording. The recording mode and resolution can be set on page “Recording” (refer to 93). If the recording mode is set to “PGM + 4 Inputs”, the streaming would not be performed Page simultaneously during recording.
  • Page 22 Recording timer is counting time simultaneously. storage space of HDR-731. To browse or download them, please go to “Media Center”. ※ As saving file, please do not unplug the USB 3.0 device or the file saving will be failed.
  • Page 23 Dashboard_Snapshot HDR-731 can perform “Snapshot” during recording and streaming to create image files from present PGM output screen and save them in the internal storage space of HDR-731. To browse and download them, please go to “Snapshot” under “Media Center”.
  • Page 24 Web GUI Interface Template_Main Template There are nine scenes built in “Template”. “Main Template” will switch scenes corresponding to layout switch list on dashboard or external USB/keyboard. Select “Template” to enter the layout editing page. “Main Template”: nine layouts are reserved for quick switch selection.
  • Page 25 Web GUI Interface Template_Main Template Select a layout and click “Copy” to copy that layout to the Select a layout and click “Export” to export that layout to a list as the new layout for editing. computer for backup.
  • Page 26 Web GUI Interface Template_Main Template Drag out a layout from “Main Template” to remove that Drag a layout from “Template List” to “Main Template” to layout from the quick switch list. replace or add layout.
  • Page 27 Web GUI Interface Template_Add Template There are nine layouts built in "Template". To customize the layout , you can duplicate the existing layout or add a blank layout for modification. Layouts can be exported as configuration file for backup. Click “+ Add” on “Template List” to add a blank layout for Click “EDIT”...
  • Page 28 Web GUI Interface Template_Add Template Click “SELECT” to complete the setting of video input Select a HDMI input source or select the camera added in the domain to bind signal source for display accordingly. source.
  • Page 29 Web GUI Interface Template_Add Template Click “Refresh” icon to refresh screens of each input Click the input screen in the list to add that screen to the channel. layout for editing.
  • Page 30 Web GUI Interface Template_Add Template Double click on the screen to open “Crop” function and Drag the frame of screen to zoom in / out the displayed screen. drag the frame to adjust the display range.
  • Page 31 Web GUI Interface Template_Add Template Click the frame to adjust screen cropping. Double click on screen to exit cropping.
  • Page 32 Web GUI Interface Template_Add Template ”Screen Group” of Layer: to edit the overlapped sequence Click the image of other input sources to add the screen to the layout (screen of the same input source cannot be of each input screen. added repeatedly).
  • Page 33 Web GUI Interface Template_Add Template Click “Background” to set the background color. Click “Text” to add text blocks on the layout.
  • Page 34 Web GUI Interface Template_Add Template Text Text Drag the text block to the required position on layout. Click the frame of the text block and drag it to zoom in / out the text display.
  • Page 35 Web GUI Interface Template_Add Template Enter the text to be displayed. Select the text color.
  • Page 36 Web GUI Interface Template_Add Template Rectangle BXB Seminar Add a rectangular block on the layout for editing. Drag the block to required position.
  • Page 37 Web GUI Interface Template_Add Template 1920 1920 BXB Seminar BXB Seminar BXB Seminar BXB Seminar 1920 1920 Click the frame of the block and drag it to zoom in / out. Edit the border color and border width of the block.
  • Page 38 Web GUI Interface Template_Add Template 1920 BXB Seminar BXB Seminar 1920 Click icon “+” under “Image” to add a new image. Select the block color.
  • Page 39 Web GUI Interface Template_Add Template BXB Seminar BXB Seminar Click the image to add it on the layout for editing. After selecting the local image, click “ADD” to upload it to HDR-731.
  • Page 40 Web GUI Interface Template_Add Template BXB Seminar BXB Seminar BXB Seminar BXB Seminar 1260 1260 Click the frame of the image and drag it to zoom in / out. Drag the image to move its position on layout.

  • Page 41: Template Main Template

    Web GUI Interface Template_Add Template BXB Seminar BXB Seminar BXB Seminar BXB Seminar Select “Background” and then click icon “+” to add a Select the background file to be added and click “ADD” to background page. upload it to HDR-731.
  • Page 42 Web GUI Interface Template_Add Template Click the background image to apply it to layout. If it is not necessary to display the applied background, just click “Background” under “Layer” to delete the background image.
  • Page 43 Web GUI Interface Template_Add Template Time Select a layout from the nine templates built in “Layout” Click “Time” to add date / time display. The present for editing content. system time can be displayed on the output PGM screen.
  • Page 44 Web GUI Interface Template_Add Template 2021/08/20 15:53:45 2021/08/20 15:53:45 There are multiple display formats of date / time Enter the value to adjust the font size of date / time combination built in HDR-731. Click the required mode for display. editing.
  • Page 45 Web GUI Interface Template_Add Template 2021/08/20 15:53:45 2021/08/20 15:53:45 Select the color to change the display color of date / time. Drag and move the display position.
  • Page 46 Web GUI Interface Template_Add Template Copy 2021/08/20 15:53:45 2021/08/20 15:53:45 After selecting the object on layout, click “Copy” to copy Change the display level overlapped of the selected object. that object.
  • Page 47 Web GUI Interface Template_Add Template Delete 2021/08/20 15:53:45 2021/08/20 15:53:45 The copied object is repeatedly displayed on the editing After selecting the object, click “Delete” to delete it from screen. the editing screen.
  • Page 48 Web GUI Interface Template_Add Template 2021/08/20 15:53:45 2021/08/20 15:53:45 After selecting the object, click “Lock” icon in the layer list, Enter the name of the layout for identification after saving that object can not be selected and edited anymore. To edit that object again, it is necessary to click the “Lock”...
  • Page 49 Web GUI Interface Template_Add Template Save 2021/08/20 15:53:45 Click “Save” icon to complete this layout editing.
  • Page 50 Web GUI Interface Template_Manage Template You can edit, copy, or delete the saved layout in Template List. 2021/08/20 15:53:45 Click the required layout in Template List and then select That layout would be opened for editing and modification. “Edit” under function items.
  • Page 51 Web GUI Interface Template_Manage Template Seminar 2021/05/19 06:36:06 The layout would be copied as the basis for editing and Select the required layout in Template List and then select “Copy” under function items. modification.
  • Page 52 Web GUI Interface Template_Manage Template Select the required layout in Template List and then Select storage space sequentially to backup the select “Export” under function items. configuration file of that layout.

  • Page 53: Template

    Web GUI Interface Template_Manage Template Click “DELETE” for confirmation to delete that layout in Click unapplied template (with white asterisk) in Template List and then select “Delete” under function items. Template List.
  • Page 54 Web GUI Interface Template_Manage Template Click “IMPORT” icon and then select the previously After importing the layout successfully, it will be displayed exported backup configuration file to import the layout. in Template List.
  • Page 55 Web GUI Interface Schedule_Reserve Weekly Cycle Schedule You can perform recording, streaming or backup through pre-defined date and time. Select “Schedule” to enter the page. Click “+” icon to add a work schedule.
  • Page 56 Web GUI Interface Schedule_Reserve Weekly Cycle Schedule Enter text in “Name” to name that schedule. You can select “Not Repeat” or “Weekly” for the working mode. If you select “Weekly”, the system will reserve weekly cycled execution.
  • Page 57 Web GUI Interface Schedule_Reserve Weekly Cycle Schedule Select the date interval to reserve the execution period of Select the weekly working day of the reserved schedule. that schedule.
  • Page 58 Web GUI Interface Schedule_Reserve Weekly Cycle Schedule Define the start time and finish time of the schedule Select the action to be implemented during the reserved sequentially. schedule. You can select recording, streaming or backup; if backup is selected, recording and streaming are not allowed to be reserved at the same time.
  • Page 59 Web GUI Interface Schedule_Reserve Weekly Cycle Schedule To reserve the recording or streaming in that schedule, Click “SAVE” to complete this scheduling reservation. you must select a template to be applied.
  • Page 60 Web GUI Interface Schedule_Reserve Weekly Cycle Schedule The reserved schedule will start implementing the task Click the schedule in calendar to see the reserved content. one minute ahead. HDR-731 will give an indication.
  • Page 61 Web GUI Interface Schedule_Reserve Single-day Schedule You can perform recording, streaming or backup through pre-defined date and time. Click icon “+” to add a working schedule. Enter text in “Name” to name that schedule.
  • Page 62 Web GUI Interface Schedule_Reserve Single-day Schedule Select “Not Repeat” mode to reserve a working schedule Select the date to reserve single-day schedule. That of specific date. schedule will implement the reserved task on that day.
  • Page 63 Web GUI Interface Schedule_Reserve Single-day Schedule Select the reserved task to be implemented. “Backup” is Select the start time and finish time of the task to be implemented. set for this example.
  • Page 64 Web GUI Interface Schedule_Reserve Single-day Schedule Click “SAVE” to complete schedule reservation. Select the storage location for backup. External storage space (USB) or remote storage space (NFS, FTP) are available for selection.

  • Page 65: Reserve Single-Day Schedule

    Web GUI Interface Schedule_Reserve Single-day Schedule Select the reserved schedule to modify / delete If two schedules are configured at the same time and day, reservation content. If that schedule is “Weekly Cycle” an exclamation mark will be shown to indicate time mode, it will modify / delete the same reversed schedule conflict.
  • Page 66 Web GUI Interface Schedule_Holiday Setting If the selected date is set as “Holiday”, the reserved tasks such as recording and streaming will not be implemented on that day. Click “Holiday Setting” to open the setting page. Click “SELECT COUNTRY HOLIDAY” to apply holiday settings based on the cloud database.
  • Page 67 Web GUI Interface Schedule_Holiday Setting Click “CONFIRM” to apply the holiday information to Select a country. Presently, BXB cloud database only supports “Taiwan” and “Korea”. HDR-731.
  • Page 68 Web GUI Interface Schedule_Holiday Setting Multiselect the selected date (displayed in yellow color) Click the unselected date (displayed in white color) to add that date as holiday. “Recording” and “Streaming” will not on calendar to cancel the holiday setting. be implemented on that date.
  • Page 69 Click “IMPORT HOLIDAY” to select holiday configuration Click “EXPORT HOLIDAY” to save the holiday setting as file and then import it to HDR-731 to apply holiday setting. configuration file for backup or provide it for other HDR- 731 to import.
  • Page 70 Web GUI Interface Schedule_Holiday Setting Click “CLEAR ALL” to clear holiday setting on all dates. Click “SAVE” to complete holiday setting.
  • Page 71 Web GUI Interface Schedule_Holiday Setting Chinese Lunar New Year Chinese Lunar New Year Chinese Lunar New Year Lunar New Year Chinese Lunar New Year Chinese Lunar New Year Chinese Lunar New Year Chinese Lunar New Year Chinese Lunar New Year Chinese Lunar New Year If that date is set as “Holiday”, the reserved schedule of After completing holiday setting, the related dates will be...
  • Page 72 Media Center_Recording Folder For HDR-731 recording function, when recording is over or reaches preset recording time period, the recording file will be created and saved in the internal storage space. You can view, save to USB/remote drive/local, or delete recording files in Recording folder.
  • Page 73 Web GUI Interface Media Center_Recording Folder Click “Preview” icon of the selected file to open the Click the folder name to enter the folder. The folder is named based on the creation date. browse window.
  • Page 74 Web GUI Interface Media Center_Recording Folder Multi-select files and click “SAVE TO” to save files to the You can save the video or change to picture-in-picture display mode during file browsing. selected storage space.
  • Page 75 Web GUI Interface Media Center_Recording Folder Click “CONFIRM” to allow saving files. Select the required storage space and then click “SAVE” to save files.
  • Page 76 Web GUI Interface Media Center_Recording Folder Multi-select files and click “Delete” icon to delete files. Click “DELETE”, the selected files will be deleted from that storage space.
  • Page 77 Web GUI Interface Media Center_Snapshot Folder When clicking “Snapshot” function to capture screen, the snapshot file will be saved in the snapshot folder of the internal storage space. You can view, save or delete the files. “Snapshot” folder is the storage space of snapshot files. You can search the file based on date interval.
  • Page 78 Web GUI Interface Media Center_Snapshot Folder Click “Preview” icon to browse that snapshot file. Click the folder name to enter the folder. The folder is named based on the creation date.
  • Page 79 Web GUI Interface Media Center_Snapshot Folder Select files and click “SAVE TO” to save files in the Click on any blank area to close the snapshot browse window. selected storage space.
  • Page 80 Web GUI Interface Media Center_Snapshot Folder Click “CONFIRM” to allow saving file. Select the required storage space and then click “SAVE” to save files.
  • Page 81 Web GUI Interface Media Center_Snapshot Folder Multi-select files and click “Delete” icon to delete files. After clicking “DELETE”, the selected files will be deleted.
  • Page 82 Web GUI Interface Media Center_Image Folder HDR-731 “Image” folder is the storage space to save images of “Template”. You can add, view or delete image files in the folder. “Image” folder is the storage space for the image files of You can search the file based on date interval.
  • Page 83 Web GUI Interface Media Center_Image Folder Click “ADD” to add an image file. Select a file and then click “Delete” icon to delete the file.
  • Page 84 Web GUI Interface Media Center_Image Folder Click “DELETE”, that file will be deleted. Press and hold the Shift-key on the keyboard to select multiple files. Click “SAVE TO” to save files to the selected storage space.
  • Page 85 Web GUI Interface Media Center_Background Folder HDR-731 “Background” folder is the storage space for background graphic files of “Template”. You can add, view or delete background image files in the folder. “Background” folder is the storage space for the You can search the file based on date interval.
  • Page 86 Web GUI Interface Media Center_Background Folder Click “Add” icon to select the required background After selecting files, click “Delete” icon to delete the graphic file. For adding a background, “Fill Screen” or selected files from the folder. “Keep Ratio” can be set beforehand as the display mode.
  • Page 87 Web GUI Interface Media Center_Background Folder Click “DELETE”, that file will be deleted. Press and hold the Shift-key of keyboard to select multiple files. Click “Save To” to save files in the selected storage space.
  • Page 88 Web GUI Interface Device_Add Camera You can define related information of camera and streaming equipment in LAN as the signal sources for recording and live-streaming. “Add Camera” function can scan all BXB IP cameras of the same network and apply them as the video sources. Click “Device”...
  • Page 89 Web GUI Interface Device_Add Camera Click “SELECT” to enter the setting page. Enter the display name of that camera.
  • Page 90 Web GUI Interface Device_Add Camera Select the corresponding camera model name. Enter the ID and password to log in.
  • Page 91 Web GUI Interface Device_Add Camera Click “ADD” to complete camera setting. Click “GET URL” to test the communication and get the related information. If the information cannot be got, please check if ID & password are valid and if the camera status is normal.
  • Page 92 Web GUI Interface Device_Add Streaming Device In addition to use BXB camera as the video source to perform live-streaming, you can also use camera of other brands via “Add Streaming Device”. Click “ADD” to enter the page to add a device. Enter the name of the streaming setting.
  • Page 93 Web GUI Interface Device_Add Streaming Device Enter the URL (IP address) of the streaming device. Enter the ID & password to complete adding the device.

  • Page 94: Device

    Web GUI Interface Device_Add Streaming Device Select a device and click “Delete” icon to delete the After completing adding, the device will be shown in the Streaming List which can be selected as the video source. device.
  • Page 95 Web GUI Interface System Setting_Recording You can configure the recording mode, recording resolution, and recording time length. Click “Record” to enter the setting page. Under “Record Mode”, there are “PGM” or “PGM+4 Inputs” available for selection. If the recording mode “PGM+4 Inputs”...

  • Page 96: System Setting Recording

    If “Loop Recording” is activated, the oldest file will be HDR-731 and the external USB 3.0 device. deleted as a new recording file is created. ※ Please use USB3.0 storage devices to avoid abnormal If “Loop Recording”...
  • Page 97 Web GUI Interface System Setting_Recording “Status” indicates if recording is in progress at this moment. Define the recording resolution. The higher the resolution Status “ON” indicates that recording is in progress and the is, the larger storage space for saving the created related settings cannot be changed at this moment;...
  • Page 98 Web GUI Interface System Setting_Recording Name the created recording file. Configure the recording duration and save the setting. When the recording time reaches the limitation length, the recording file will be created automatically.

  • Page 99: Hls

    You can set PGM streaming to the platforms such as Youtube, Facebook, etc. After HLS streaming mode is set, the streaming can be watched via Chrome and VLC player. Click “Streaming” to enter the setting page. When you activate streaming and click “LIVE” icon on Dashboard, HDR-731 will start live-streaming.
  • Page 100 Web GUI Interface System Setting_Streaming_HLS ”Status” indicates if streaming is in progress at this Select a streaming type. In this example, HLS streaming moment. Status “ON” indicates streaming is in progress is selected. and the related settings cannot be changed at this moment;...
  • Page 101 Web GUI Interface System Setting_Streaming_HLS Click “COPY URL” to copy HLS streaming link address Select streaming output resolution. The higher the resolution is, the higher network bandwidth is needed. and then paste it to the devices that viewers use to watch. Please ensure the bandwidth is enough for streaming.
  • Page 102 Web GUI Interface System Setting_Streaming_HLS Click “SAVE” to complete setting. Return to “Dashboard” and then click “LIVE” icon to activate streaming.
  • Page 103 Web GUI Interface System Setting_Streaming_HLS Status indicates “LIVE” while the streaming is in progress. Open Chrome browser and paste the streaming URL in At this moment, the related settings cannot be changed. the address bar.

  • Page 104: Hls

    Web GUI Interface System Setting_Streaming_HLS Install Native HLS Playback on Chrome to receive HLS streaming signal. Or you can use players like VLC for HLS streaming.
  • Page 105 In streaming mode, select “Youtube” on “Web Platform” for live streaming under normal network communication. When you set to enable streaming and click “LIVE” icon HDR-731 has four sets of streaming settings for editing different streaming information. on Dashboard, the streaming will be activated based on...
  • Page 106 Web GUI Interface System Setting_Streaming_Youtube ”Status” indicates if the streaming is in progress at the Select a streaming mode. In this example, “Web Platform” moment. is selected.
  • Page 107 Web GUI Interface System Setting_Streaming_Youtube Select “Youtube” as the live-streaming platform. Select the streaming video resolution.
  • Page 108 Web GUI Interface System Setting_Streaming_Youtube Click “GET KEY” to enter Youtube live-streaming page. Copy the stream key on the Youtube setting page.
  • Page 109 Web GUI Interface System Setting_Streaming_Youtube Click “SAVE” to complete setting. Return to HDR-731 page and then paste the stream key.
  • Page 110 Web GUI Interface System Setting_Streaming_Youtube Click “LIVE” icon on Dashboard to start live-streaming. When the connection is normal, Youtube live-streaming will start. You can share the stream URL to the audience.
  • Page 111 System Setting_Streaming_Facebook In streaming mode, select “Facebook” on “Web Platform” for live streaming under normal network communication. HDR-731 has four sets of streaming settings for editing When you set to enable streaming and click “LIVE” icon different streaming information. on Dashboard, the streaming will be activated based on...
  • Page 112 Web GUI Interface System Setting_Streaming_Facebook ”Status” indicates if the streaming is in progress at the Select a streaming mode. In this example, “Web Platform” moment. is selected.
  • Page 113 Web GUI Interface System Setting_Streaming_Facebook Select “Facebook” as the live-streaming platform. Select the streaming output resolution.
  • Page 114 Web GUI Interface System Setting_Streaming_Facebook Open the browser and click “Live” on Facebook page to Click “Stream key” and copy the streaming key. go to the setting page.
  • Page 115 Web GUI Interface System Setting_Streaming_Facebook Click “SAVE” to complete setting. Return to HDR-731 page and then paste the stream key.
  • Page 116 Web GUI Interface System Setting_Streaming_Facebook Click “LIVE” icon on Dashboard to start live-streaming. On Facebook setting page, streaming screen will be displayed under normal communication. You can share the Server URL to the audience in advance. Click “Go live” to perform live-streaming.
  • Page 117 Web GUI Interface System Setting_System The access authorization of system is owned by the administrator who can view or modify related system configurations. In “System”, you can set the display language and time setting displayed on WEB UI interface. Click “System” to enter the setting page. Select a language for Web UI interface.

  • Page 118: System

    / streaming. Meanwhile, the to be connected. output screen will be turned off until clicking again to • “WAKE”. Synchronize With Computer Time: synchronizes the Click “REBOOT” to reboot HDR-731. time with HDR-731 via local PC time.
  • Page 119 Click “Output” to enter the setting page. You can set two Set the operation mode and output frame rate for HDMI 1. HDMI output frame rates for HDR-731. When HDR-731 connected with USB mouse or touch screen, the related mode for HDMI 1 image output will be set correspondingly.
  • Page 120 Web GUI Interface System Setting_System_Output 點擊「輸出」進入設定頁面。可設定HDR-731 兩組 Set the frame rate for HDMI 2. HDMI 影像輸出幀率。...
  • Page 121 Web GUI Interface System Setting_System_Input The recording mode of HDR-731 can be set as "PGM + 4 Inputs" to capture the image of PGM and the 4CH video sources. Simultaneously, you can configure the recording audio source for each video channel.
  • Page 122 Web GUI Interface System Setting_System_Input Set the audio input as “Line in” to bind 3.5 Line In as the Set the audio input as “Audio Mixing” to bind HDMI / audio source for the recording. streaming and 3.5 Line In as the audio sources for the recording.
  • Page 123 Web GUI Interface System Setting_System_Network The default method to get IP address for HDR-731 is “DHCP”. If the IP address cannot be got via “DHCP” in the domain, the default fixed IP is “192.168.168.130”. Click “Network” to enter the setting page.
  • Page 124 Web GUI Interface System Setting_System_Network 192.168.3.133 192.168.3.133 The IP address of HDR-731 will be displayed at the right If “DHCP” is disabled, it is necessary to key in the corresponding static IP address manually. lower corner on HDMI 1 output screen.
  • Page 125 Web GUI Interface System Setting_System_Button The front panel of HDR-731 is equipped with three function buttons for setting the corresponding functions freely. You can also make it by the keypad connected via USB. Click “Button” to enter the setting page.
  • Page 126 Web GUI Interface System Setting_System_Remote Setting This function is for remote backup, which supports FTP and NFS protocols. Click “Remote Setting” to enter the page. Click “+” to add a remote backup space.
  • Page 127 Web GUI Interface System Setting_System_Remote Setting Choose “NFS” or “FTP” as the backup protocol. Name the remote backup space.
  • Page 128 Web GUI Interface System Setting_System_Remote Setting After “TEST CONNECTION” is successful, click “SAVE” Enter the related configurations in sequence. to save the settings.
  • Page 129 Web GUI Interface System Setting_System_Storage HDR-731 internal storage space. The space usage status of HDR-731 can be viewed on this page. Click “Storage” to enter the setting page. View the usage status of HDR-731 internal storage space.
  • Page 130 Web GUI Interface System Setting_System_Update You can compare with the version in cloud database to download the latest firmware and then upload the file to HDR-731 manually. Click “Update” to enter the setting page “Version” indicates the current version of HDR-731.

  • Page 131: System

    Web GUI Interface System Setting_System_Update Under normal network communication, click “GET THE NEW Click “RESET TO DEFAULT” to restore the system VERSION” to download the latest firmware. After that, click settings such as network setting, account and password “UPLOAD FILE”, select the firmware file, and then click setting, etc.
  • Page 132 Web GUI Interface System Setting_System_Backup You can backup the system settings as the configuration file to import the data when replacing equipment afterward. Click “Backup” to enter the setting page. Click “UPLOAD” to open the file selection window and then select a backup file.
  • Page 133 Web GUI Interface System Setting_System_Backup Click “RESTORE” to apply that backup file. After applying Click “DOWNLOAD” to download the current backup file it, HDR-731 will reboot. to the selected storage space.
  • Page 134 Web GUI Interface System Setting_Account The default administrator account is “admin”; password “00000”. “User” or “Viewer” account can be added sequentially for different users in different LANs to log in. Click “Account” to enter the setting file. Click icon “+” to add a new account.
  • Page 135 Web GUI Interface System Setting_Account Select the permission of that account: . “User” or “Viewer”. Enter the username of that account.
  • Page 136 Web GUI Interface System Setting_Account After entering account and password, click “SAVE” to There will be a message indication after completing complete adding new account. adding new account and the account information will be added in the list.
  • Page 137 Web GUI Interface System Setting_Account If the account authorization is “Viewer”, only “Media Use new added account to log in the Web UI interface on the browser. If the account authorization is “User”, Center” page can be entered to browse and download operating function is allowed, but pages such as “System recording / snapshot files.

  • Page 138: Panel Operation

    Panel Operation Definition of Front Panel Button The front panel of HDR-731 is equipped with three operation buttons to bind the related functions that configured via the Web UI interface, which is quickly to perform functions by just pressing the button.
  • Page 139 Panel Operation Definition of Front Panel Button_Panel 1 Record The default function of Panel 1 button is recording. You can quickly start / finish recording through operation. After finishing recording, short press “Panel 1” again. Short press “Panel 1” to start recording. The red light would be on.
  • Page 140 Panel Operation Definition of Front Panel Button_Panel 2 Live The default function of Panel 2 button is live-streaming. You can quickly start / finish live- streaming through operation. Short press “Panel 2” button to start live-streaming. The After finishing streaming, short press “Panel 2” again, the blue light will be on.
  • Page 141 Definition of Front Panel Button_Panel 3 Layout The default function of Panel 3 button is switching layouts. You can switch main layouts from scenes 1 to 9 sequentially through operation. Short press “Panel 3” button to switch layouts The HDR-731 will switch scenes sequentially. sequentially.
  • Page 142 Operate Panel 3 button to restore factory default setting. In the meantime, all the related settings and files in the internal storage space will be cleared. Press and hold “Panel 3” button as turning off HDR-731, When the three panel buttons flicker, release “Panel 3”...

  • Page 143: Hdmi 1 Director View

    HDMI 1 輸出工作台 HDMI 1 Director View HDR-731 HDMI 1 director view page can be operated with OUTPUT HDMI 1 dashboard page in connection with USB mouse or touch screen. HDMI 1 Out connects the monitor USB connects the mouse or touch screen...
  • Page 144 HDMI 1 輸出工作台 HDMI 1 Director View Set Video Source You can select HDMI 1 to HDMI 4 signals as the video source; the IP camera in LAN for streaming can also be set as the video source. To add a new camera, you can configure it on “Device”...
  • Page 145 HDMI 1 輸出工作台 HDMI 1 Director View Layout Switch Main layouts can be selected for output screen. There are 9 main layouts. To add more, please go to “Template” page for editing (details refer to Page 25). Click the required template in the list to switch layout. After selecting the template, the layout will be applied to screens of HDMI 2, recording and streaming PGM.
  • Page 146 HDMI 1 輸出工作台 HDMI 1 Director View Camera Control BXB's HDC-713, HDC-715 and HDC-716 cameras are supported. You can control camera screen and set/call the preset point screen of camera. It is suggested, when switching to camera control page, select camera signal as video source simultaneously to watch the real-time image. New added cameras must be set on “Device”...
  • Page 147 HDMI 1 輸出工作台 HDMI 1 Director View Camera Control Click the number of “Preset Point” and then click “SET” to After entering the number of “Preset Point” to be called, click “Go” to go to that preset point image. save the preset point image.
  • Page 148 HDMI 1 Director View Audio Adjustment HDR-731 has eight audio inputs and two audio outputs respectively. You can configure the audio of recording, streaming and HDMI output on Dashboard. Click and drag the bar to adjust the audio volume of the Click the icon below the audio channel to turn on / off the corresponding audio channel.
  • Page 149 / off based on the corresponding layout selection. By will be compulsorily turned off and the eight input audio switching layout, HDR-731 will automatically adjust the channels cannot be turned on and their volume cannot be ON / OFF of the audio channel.
  • Page 150 HDMI 1 輸出工作台 HDMI 1 Director View Recording The default recording mode is “PGM Output Recording” of single-channel recording. Streaming can be performed simultaneously during recording. The recording mode and resolution can be set on page “Recording” (please refer to 93).
  • Page 151 HDMI 1 Director View Recording Click “Record” icon again to exit recording. At the same time, HDR-731 will save the recorded files in the internal storage space. To browse or download them, please go to “Media Center” of Web UI interface.
  • Page 152 HDMI 1 輸出工作台 HDMI 1 Director View Streaming HDR-731 supports live-streaming platform, HLS, RTMP and RTSP streaming. Before streaming, it is necessary to configure settings on “Streaming” page (refer to Page 97). After starting streaming, the system will perform live-streaming based on your setting.
  • Page 153 HDMI 1 輸出工作台 HDMI 1 Director View Streaming Click icon “LIVE” again to terminate the live-streaming.
  • Page 154 HDMI 1 Director View Snapshot HDR-731 can instantly capture the PGM output screen and save it in the internal storage space. Click the “Snapshot” icon shown on the real-time screen to capture the PGM output screen. The image file will be saved in the internal storage space.

  • Page 155: Appendix

    Appendix Example of Holiday Configuration File Setting You can import json or csv files to apply the holiday information. Open the Notepad program of PC and follow the instruction below to edit holiday information. {"date":"YYYY-MM-DD","name":“holiday name","desc":""},{"date":"YYYY-MM-DD","name":“holiday name","desc":""}] After editing, you just save the file as json format.

  • Page 156: Connect Usb Keypad

    Appendix Connect USB Keypad Connect USB keypad with the HDR-731 to quickly perform the related functions. Enter HDMI 1 output port connects with monitor; USB port with keypad. By pressing the key of the keypad, you can perform the corresponding...

  • Page 157: Rs-232 / Rs-485 Control Protocol

    Appendix RS-232 / RS-485 Control Protocol Environmental control equipment can connect with HDR-731’s RS-232 or RS-485 port. RS-232 RS-485 Control protocol RS-232 / RS-485 Baud rate 9600 Data length Parity None Stop bit Flow control None...
  • Page 158 Appendix Example of Protocol Setting You can control the HDR-731 via RS-232 protocol. Example: via RS-232 protocol of PC, you can send the Example: via RS-232 protocol of PC, you can send the command of “Start Recording” to HDR-731. command of “Switch to Layout 1” to HDR-731...
  • Page 159 Appendix HEX Command Set Description Command Type Data Length Data Reset to factory default b9703838 Get device info b9703838 02 00 Display layout 1 b9703838 03 01 01 Display layout 2 b9703838 03 01 02 Display layout 3 b9703838 03 01 03 Display layout 4 b9703838 03 01 04...
  • Page 160 Description Command Type Data Length Data Set HDMI1 output volume b9703838 0A 01 01 Set HDMI2 output volume b9703838 0A 01 02 Set HDMI3 output volume b9703838 0A 00 01 Set HDMI4 output volume b9703838 0A 00 02 Set Follow PGM mode b9703838 0B 01 00 00 00 Set audio mixing mode...
  • Page 161 Appendix HEX Command Chart System Ready: HDR-731 is turned on to receive the protocol data and executes the correspond command successfully. Action HEX command Command b9 70 38 38 45 01 00 Reset to factory default: clear the original settings...
  • Page 162 Appendix HEX Command Chart Switch layout: key in the correspond command to switch the layout. Action HEX command Command b9 70 38 38 51 03 03 01 Response b9 70 38 38 53 03 03 01 Layout number 01~09: layout 1-layout 9 Remark State code: 00 valid;...
  • Page 163 Appendix HEX Command Chart Recording: start / stop recording Action HEX command Command b9 70 38 38 51 03 05 01 Response b9 70 38 38 53 03 05 01 command: 00 stop recording; 01 start recording Remark State code: 00 valid; 02 error code; 03 no layout; 07 system busy; 0C execution error Get recording state: get the present recording state Action...
  • Page 164 Appendix HEX Command Chart Streaming: start / stop streaming Action HEX command Command b9 70 38 38 51 03 06 01 Response b9 70 38 38 53 03 06 01 Command: 00 stop streaming; 01 start streaming Remark State code: 00 valid; 02 error code; 04 switch forbidden while recording; 07 system busy; 0C execution error Get streaming state: get the present streaming state Action...
  • Page 165 Appendix HEX Command Chart Snapshot: perform snapshot function Action HEX command Command b9 70 38 38 51 03 07 01 Response b9 70 38 38 53 03 07 01 Snapshot channel: 00 PGM; 01~04 = CH1~CH4 Remark State code: 00 valid; 02 error code; 0C execution error Audio output: control the volume of HDMI 1, HDMI 2, and line out audio Action...
  • Page 166 Appendix HEX Command Chart Notice of changing audio output: when changing the audio output is modified by Web UI dashboard, the system will give a notification. Action HEX command Command b9 70 38 38 45 04 0A Output channel: 01 HDMI 1; 02 HDMI 2 & 3.5 Line Out Remark Volume: 00~64 corresponding volume 00~100 Mute: 01 mute on;...

  • Page 167: Hex Command Chart

    Appendix HEX Command Chart Notice of change audio mixing mode: when changing the audio output is operated by Web UI dashboard, the system will give a notification. Action HEX command Command b9 70 38 38 45 04 0B Audio mixing mode: 00 Follow PGM; 01 all-mixing Remark All mute: 00 mute off;...
  • Page 168 Appendix HEX Command Chart Get the audio input state : check the volume setting of 8CH audio inputs Action HEX command Command b9 70 38 38 51 03 0C 00 Response b9 70 38 38 53 06 0C 00 00 Output channel: 01~04 Input 1~Input 4;...
  • Page 169 Display mode: 00 Mouse mode; 01 Touch mode; 02 Quad-view; 03 PGM; 04~07 = Source 1~Source 4 Remark State code: 00 valid; 02 error code; 0C execution error Notice of hard disk state: notification of HDR-731 storage space Action HEX command Command b9 70 38 38 45 02 OD Hard disk status: 00 Sufficient;...
  • Page 170 Appendix HEX Command Chart Get hard disk status: check the condition of HDR-731 storage space Action HEX command Command b9 70 38 38 51 02 0D 00 Response b9 70 38 38 53 04 0D 00 00 Hard disk status: 00 Sufficient; 01 the available storage space is lower than 20%; 02 insufficient; 03 unable to detect the...

  • Page 171: Connect Environmental Control Equipment

    附件 Appendix Connect Environmental Control Equipment HDR-731 Web API uses “RESET” principle. Via Web API communication, you can get HDR-731 data and change settings.

  • Page 172: Example Of Web Api Communication

    附件 Appendix Example of Web API Communication Use Postman program of PC to communicate with the HDR-731 Example: Run Postman to check login information Example: Run Postman to get the template ID. POST http:/ /HDR-731 IP/api/login GET 172.18.51.124/api/templates/display Status response: HTTP status code "200 OK" represents “Success”...
  • Page 173 附件 Appendix Web API Chart Action Log in Method POST {HDR-731 address}/api/login uname: 'admin', Request passwd: '00000' Response ● 400 Bad Request “error code” Status code ● 401 Unauthorized “incorrect account name or password” Remark Action Ask login status Method...
  • Page 174 附件 Appendix Web API Chart Action Get account information Method {HDR-731 address}/api/accounts Request uname: 'admin' Response alias:'admin' permission: Status code permission “Account permission”: 1 Admin; 2 User; 3 Viewer Remark Action Log out Method {HDR-731 address}/api/logout Request Response Status code...
  • Page 175 附件 Appendix Web API Chart Action Get sleep mode status Method {HDR-731 address}/api/system/sleep Request Response true false Status code Remark true: sleep mode ON; false: sleep mode OFF Action Activate sleep mode Method {HDR-731 address}/api/system/on Request Response Status code Remark...

  • Page 176: Web Api Chart

    附件 Appendix Web API Chart Action Get video input source information Method {HDR-731 address}/api/screens Request "audio": 0, "fps": 60.0, "height": 1080, "id": 1, Response "input": 1, "media": 2, "signal": true, "width": 1920 },..Status code Able to get each input (4CH) status Audio source: 0 original source;...
  • Page 177 附件 Appendix Web API Chart Action Get specific input information Method {HDR-731 address}/api/screens/{screens ID} Request "audio": 0, "fps": 60.0, "height": 1080, "id": 1, Response "input": 1, "media": 2, "signal": true, "width": 1920 Status code {screens ID} : 1 Input 1; 2 Input 2; 3 Input 3; 4 Input 4 Audio source: 0 original source;...
  • Page 178 附件 Appendix Web API Chart Action Modify specific input source Method PATCH {HDR-731 address}/api/screens/{screens ID} Request "input": 2 Response Status code {screens ID} : 1 Input 1; 2 Input 2; 3 Input 3; 4 Input 4 Remark 1 HDMI In 1; 2 HDMI In 2; 3 HDMI In 3; 4 HDMI Input 4; 5 Streaming device 1…...
  • Page 179 附件 Appendix Web API Chart Action Get HDMI out information Method {HDR-731 address}/api/outputs Request "fps": 60, "id": 1, Response "mode": 0, "mute": false, "volume": },… Status code Get information of HDMI out 1 and HDMI out 2 fps: frame rate 1 HDMI Out 1;...
  • Page 180 附件 Appendix Web API Chart Action Modify specific HDMI output source Method PATCH {HDR-731 address}/api/outputs/{ID} "fps": 60, "mode": 0, Request "mute": false, "volume": 100 Response Status code 1 HDMI Out 1; 2 HDMI Out 2 fps: frame rate Remark Operation mode: 0.
  • Page 181 附件 Appendix Web API Chart Action Get marked template information Method {HDR-731 address}/api/templates/favorites Request "id": 1, "name": "Default_Full" Response "id": 2, "name": "Default_PBP" },… Status code Remark ID: template ID Action Get unmarked template information Method {HDR-731 address}/api/templates Request "id": 15, "name":...
  • Page 182 附件 Appendix Web API Chart Action Get current template information Method {HDR-731 address}/api/templates/display Request Response "id": Status code Remark ID: template ID Action Layout switch Method {HDR-731 address}/api/templates/display "id": Request Response Status code Remark ID: template ID...
  • Page 183 附件 Appendix Web API Chart Action View specific template information Method {HDR-731 address}/template/{ID}/view Request Response Template preview Status code Remark {ID} : template ID Action Get recording information Method {HDR-731 address}/api/records Request "duration": 5, "elapsed": 0, "enable": true, "encoder": 1, Response "filename": "PGM_Record",...
  • Page 184 附件 Appendix Web API Chart Action Get the information of specific recording input Method {HDR-731 address}/api/records/{ID} Request "duration": 5, "elapsed": 0, "enable": true, "encoder": 1, Response "filename": "PGM_Record", "id": 1, "name": "PGM Record", "running": false, "storage": "sata" Status code Remark...
  • Page 185 附件 Appendix Web API Chart Action Stop recording Method {HDR-731 address}/api/records/0/off Request Response Status code Remark Action Get streaming information Method {HDR-731 address}/api/streaming Request "enable": true, "id": 2, Response "name": "Streaming 1", "running": false, "type": },… Status code Only PGM streaming supported right now...
  • Page 186 附件 Appendix Web API Chart Action Start streaming Method {HDR-731 address}/api/streaming/0/on Request Response Status code Remark Only PGM streaming supported right now Action Stop streaming Method {HDR-731 address}/api/streaming/0/off Request Response Status code Remark...
  • Page 187 附件 Appendix Web API Chart Action Snapshot Method {HDR-731 address}/api/screens/{ID}/snapshot Request Response Status code Remark ID: 0 PGM; 1 Input 1; 2 Input 2; 3 Input 3; 4 Input 4 Action Preview PGM snapshot Method {HDR-731 address}/api/inputs/0/snapshot Request Preview PGM snapshot...
  • Page 188 附件 Appendix Web API Chart Action Get mixer information Method {HDR-731 address}/api/mixer Request "indicator": false, Response "mode": 0, "silence": false Status code Remark Mode: 0 Follow PGM; 1 mix all Action Modify mixing mode Method PATCH {HDR-731 address}/api/mixer "indicator": false, "mode": 1,...
  • Page 189 附件 Appendix Web API Chart Action Get specific audio in information Method {HDR-731 address}/api/mixer{ID} Request "delay": 0, "enable": true, "mute": false, Response "toMixer": true, "toRecord": true, "volume": Status code 0~100 “0 db ~ 100 db” Remark volume : Action Modify specific audio in information...
  • Page 190 附件 Appendix Web API Chart Action Modify recording setting Method {HDR-731 address}/api/records/1 "duration": 5, "enable": true, "encoder": 1, Request "filename": "PGM", "name": "PGM_RECORD", "storage": "sata" Response Status code duration Video length: 5 mins; 30 mins; 1 hour; 2 hours ；3 High；4...
  • Page 191 Website/ www.bxbsystem.com © Copyright 2022 BXB Electronics Co., Ltd. Reproduced or transmitted in any form or by any means without the prior written permission of BXB is prohibited. We make no representations or warranties, either expressed or implied, with respect to the contents of this manual, its merchantability or fitness for any particular purpose.
