Summary of Contents for Plymovent AeroGuard
- Page 1 The Air Monitor...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Product Information � � � � � � � � � � � � � � � � � � 2 1. General Description 2. Software and Personal Data 3. Maintenance 4. Technical Specifications 5. Sensors 6. Default and Custom Settings 7. -
Page 4: Product Information
The AeroGuard’s main purpose is to measure, track, and warn against human exposure to fine dust particles. Additionally, the AeroGuard measures volatile organic compounds, carbon diox- ide, noise, humidity, atmospheric pressure and temperature. The AeroGuard can be used to trigger two relay outputs based on measured values. Placement The AeroGuard is not suitable for outside use. -
Page 5: Maintenance
AeroGuard connected to the internet. The AeroGuard will install firmware updates automatically in the background, issuing a restart indicated during which (less than a minute) the AeroGuard is not usable nor is the LED-ring representing the current air quality. Relays being in use during a firmware update reboot may be temporarily inactive. -
Page 6: Technical Specifications
4� Technical Specifications Specifications Dimensions 130 x 130 x 215 mm (LxWxH) (5.1 x 5.1 x 8.5 in) Material of housing PC/ABS Weight 0.9 kg (2 lbs) Replaceable Dust Sensor Includes laser: • 660 nm wavelength • DIN EN 60825-1 Class 1 Power consumption Max. 10.5 W (5 V DC, 2.1 A) Altitude 2000 m Overvoltage category... -
Page 7: Sensors
Atmospheric pressure Sound levels (L 6� Default and Custom Settings Use the AeroGuard Android or iOS App, or the www.MyPlym- ovent.com web portal to interact with your AeroGuard modules. Both platforms can be used to change basic settings and gain insights in your collected data. -
Page 8: Troubleshooting
LED-Ring shows Blue/Pink/ Complete configuration Turquoise indicated in the App/Portal Other / Reset Perform a factory reset by pressing the top button of the AeroGuard for 30 seconds. The AeroGuard blinks in red and white while resetting. -
Page 9: Safety Instructions
DISCLAIMER: The AeroGuard is an advisory device and the data that the AeroGuard provides is for informational purposes only. It does not provide health advice and Plymovent does not claim any responsibility for health and safety actions that are based... -
Page 10: Specifications & Modifications
AeroGuard. “Intended use” as explained in EN-ISO 12100-1 is the use for which the technical product is suited as specified by the man- ufacturer, inclusive of their directions in the sales brochure. In case of doubt it is the use which can be deduced from the construction, the model and the function of the technical product which is considered normal use. -
Page 11: Regulatory Information
REGULATORY INFORMATION 1� EU Declaration of Conformity We, Plymovent, Koraalstraat 9, 1812 RK Alkmaar, the Neth- erlands, herewith declare, on our own responsibility, that the product(s): - Model: AeroGuard which this declaration refers to, is/are in accordance with the conditions of the following directive(s): - 2014/53/EU Radio Equipment - 2015/863 RoHS Directive and is/are in conformity with the following harmonized stan-... -
Page 12: Declaration Of Conformity
2� UK Declaration of Conformity We, Plymovent, Koraalstraat 9, 1812 RK Alkmaar, the Neth- erlands, herewith declare, on our own responsibility, that the product(s): - Model: AeroGuard which this declaration refers to, is/are in accordance with the conditions of the following directive(s): - The Radio Equipment Regulations 2017 - 2015/863 RoHS Directive and is/are in conformity with the following harmonized stan-... - Page 13 Les changements ou modifications non expressément approuvés par la partie responsable de la conformité pourraient annuler l’autorisation de l’utilisateur d’utiliser l’équipement. This Device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two conditions: 1) this device may not cause interference, and 2) this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 14: Regulatory Information Usa
4� Regulatory Information USA FCC Compliance Statement Compliance Statement (Part 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. -
Page 15: Regulatory Information Thailand
5� Regulatory Information Thailand ข ้ อม ู ลกฎระเบ ี ยบประเทศไทย เคร ื ่ องโทรคมนาคมและอ ุ ปกรณ ์ น ี ้ ม ี ความสอดคล ้ องตามมาตรฐานหร ื อข ้ อก ํ าหนด ทางเทคน ิ คของกสทช เคร ื ่ องว ิ ทย ุ คมนาคมน ี ้ ม ี ระด ั บการแผ ่ คล ื ่ นแม ่ เหล ็ กไฟฟ ้ าสอดคล ้ องตามมาตรฐาน ความปลอดภ... - Page 16 305049/B...
