MPS EV5061-QV-00A Manual

DESCRIPTION
The EV5061-QV-00A is an evaluation board for
MP5061.The MP5061 is a hot-swap protection
device designed to protect circuitry on its output
from transients on its input. It also protects its
input from undesired shorts and transients
coming from its output.
An internal charge pump drives the gate of the
power device, allowing for a power FET with a
very low ON resistance of 7mΩ.
The MP5061's fault protections include current-
limit protection,
damaged-MOSFET detection. Both the current
limit and thermal shutdown have user-settable
auto-retry and latch-off mode. The device also
features under-voltage protection.
The EV5061-QV-00A is a fully assembled and
tested evaluation board.
ELECTRICAL SPECIFICATION
Parameter
Input Voltage
Output Voltage
Output Current
EV5061-QV-00A EVALUATION BOARD
(L x W x H) 8.55cm x 8.55cm x 1.6cm
Board Number
EV5061-QV-00A
EV5061-QV-00A Rev.1.0
12/21/2018 MPS Proprietary Information. Patent Protected. Unauthorized Photocopy and Duplication Prohibited.
thermal shutdown,
Symbol Value
V 4.5-28
IN
V 4.5-28
OUT
T 10
OUT
MPS IC Number
MP5061GQV
© 2018 MPS. All Rights Reserved.
28V, 7mΩ R
Device with Current Monitoring
FEATURES

Integrated 7mΩ Power FET

Adjustable Current Limit (5A to 15A)

36V Input Transient before VOUT Startup

Output Current Measurement

±5% Current Monitor Accuracy

Fast
Protection

PG Detector and FLTB Indication

PG Assert Low at VIN=0

Damaged MOSFET Detection

External Soft-Start
and

Under-Voltage Lockout

Thermal Protection

Small QFN-22 (3mm×5mm) Package
APPLICATIONS

Hot Swappable

PC Card

Disk Drives

Laptops
Units
All MPS parts are lead-free, halogen free, and adhere to the RoHS directive. For
V
MPS green status, please visit MPS website under Quality Assurance. "MPS"
and "The Future of Analog IC Technology" are Registered Trademarks of
V
Monolithic Power Systems, Inc.
A
MonolithicPower.com
EV5061-QV-00A
Hot-Swap Protection
DSon
Response (<200ns)
Efficiency vs. Load Current
99.5
99.0
V =8V
98.5
IN
V
IN
98.0
V =16V
97.5
IN
97.0
0 1 2 3 4 5 6 7 8 9 10
OUTPUT CURRENT(A)
for Short
=12V
1
