- Page 1 Smart Plant™ Remote Monitoring Systems INSTALLATION GUIDE WX IoT Differential Pressure Sensor IAC | 5200 Metcalf Avenue, Overland Park, KS 66202 USA iac-intl.com | USA & Canada: 800-334-7431 | Main Office: 913-384-5511...
- Page 2 • Revision History Release 1 – 2022-11-15 IAC Form #: IAC-IG-002 In case of emergency call 911. For IAC afterhours troubleshooting and service assistance contact: IAC 24/7 Customer Support Hotline Phone: 913-834-5511, Option # 4...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Contents • Revision History ........................1-1 TABLE OF CONTENTS ........................1-2 INTRODUCTION ........................1-3 PURPOSE ..........................1-3 INTENDED AUDIENCE ......................1-3 HOW TO USE THIS GUIDE ....................1-3 LOCATION ..........................2-4 MOUNTING ..........................2-4 CONNECTIONS - TUBING ......................4-5 STARTUP AND OPERATION.......................5-5 CONFIGURATION BUTTON .......................6-6 INSTANT READING ......................6-6 DP SENSOR ZERO CALIBRATION ..................6-6 RESET BUTTON ........................7-6 REPLACEMENT BATTERY ......................8-7... -
Page 4: Introduction
1 INTRODUCTION 1.1 PURPOSE The WX sensor node is a battery powered wireless device that transmits readings to a cloud monitoring platform through a central gateway device over a secure internet connection. All readings from the device are identified with the device ID listed on the equipment label as shown below. -
Page 5: Location
2 LOCATION Installation of this product should be performed by an appropriately licensed Electrician. The device should be mounted away from sources of excessive heat or electrical interference. The device should be oriented so that the pressure ports (if present) are facing vertically down to prevent moisture entrapment within the pressure sensor. -
Page 6: Connections - Tubing
4 CONNECTIONS - TUBING Pneumatic fittings for Differential Pressure high (DP HI) and low (DP LO) accept 0.170” ID flexible tubing and should be connected as shown on the equipment top label. 5 STARTUP AND OPERATION Apply power to the sensor node by inserting the supplied battery into the battery holder. Take care to match the polarity shown on the battery holder. -
Page 7: Configuration Button
6 CONFIGURATION BUTTON The configuration button is located on the bottom center of the internal circuit board as shown below and provides two independent functions: Config Button 6.1 INSTANT READING A short press of the configuration button will initiate the WX to take a pressure measurement and immediately transmit the reading to the network. -
Page 8: Replacement Battery
8 REPLACEMENT BATTERY IMORTANT – The battery in the WX sensor is a high-power Lithium Primary battery and is NOT RECHARGEABLE. The battery must be replaced with a high pulse capacity lithium battery to ensure stable operation during radio transmission. The replacement battery is: Manufacturer: SAFT Model: LSH-20 Description: D-Size 3.6 V, 13.0 Ah Primary lithium-thionyl chloride (Li-SOCl2), high... - Page 9 WX IoT Differential Pressure Sensor Installation Guide Smart Plant™ Remote Monitoring Systems Literature # IAC-IG-002 Release 1: 2022-11-15 IAC | 5200 Metcalf Avenue, Overland Park, KS 66202 USA iac-intl.com | USA & Canada: 800-334-7431 | Main Office: 913-384-5511...
