• Mitre saw (recommended) or hacksaw
with non-ferrous metal cutting blade
• Spirit level
• Measuring tape
• Drill
• Drill bits for timber: 10 mm
• Drill bits for metal: 3 mm, 5.5 mm
12 mm Pan head
self-drilling screw
19 mm Pan head
self-drilling screw
19 mm Flat head screw
25 mm Flat head screw
Tools and Materials Needed
Fasteners Supplied
38 mm Pan head screw
See our helpful installation videos on our website:
peakbalustrade.com.au • peakbalustrade.com.nz
Installation Guide
• Philips #1, #2, #3 driver bits
• Socket or nutsetter:
8 mm, 17 mm
• Adjustable spanner
• Clamps
• Painter's masking tape
• Dish soap (for glass panels)
• Non-corrosive exterior
silicone caulking
• Anchoring fasteners
(see pages 3-4)
50 mm Coach screw
with washer
80 mm Coach screw
with washer
45 mm Connector bolt
and nut
35 mm Hinge
bolt assembly
Advertisement
Summary of Contents for Peak Balustrade ALUMINIUM
- Page 1 Installation Guide Tools and Materials Needed • Mitre saw (recommended) or hacksaw • Philips #1, #2, #3 driver bits • Non-corrosive exterior silicone caulking with non-ferrous metal cutting blade • Socket or nutsetter: 8 mm, 17 mm • Anchoring fasteners •...
- Page 2 Dear Customer, We’d like to take a moment to say “thank you and congratulations” for choosing our products. At Peak® your satisfaction is very important to us. That is why we work very hard to provide you with products of exceptional...
- Page 3 Measure and mark the position of Peak® Aluminium Balustrade system and its fasteners must be independently verified for each installation. To all brackets on the wall.
- Page 4 BALUSTER INSTALLATION A: Remove the second post to install the This symbol indicates important information. last few balusters and spacers. B: Cut the last spacers flush with the ends For wall bracket or horizontal angle bracket installation, please see page 5. of the rails.
- Page 5 GLASS PANEL INSTALLATION A: Insert the rails into the posts. B: Position and fasten the second post in place, ensuring that the post is This symbol indicates important information. plumb (see step 1 for full details). C: Slide the base rail support to the Always use two people to handle glass panels.
- Page 6 SECTIONAL GLASS KIT INSTALLATION Cut the last spacers flush with the This symbol indicates important information. ends of the rails. Always lift a glass panel by its sides. Toughened glass is extremely fragile – do not bump the edges. To ensure equal glass panel Always use protective gear including eyewear and gloves when handling glass panels.
- Page 7 STAIR BALUSTER INSTALLATION Put the balustrade panel and bottom post into position and clamp the posts and rails 10 mm together but do not secure the bottom post This symbol indicates important information. yet. Ensure equal baluster spacing at each post, and that the bottom post is plumb.
- Page 8 GATE INSTALLATION W (1150 mm max.) W minus 190 mm This symbol indicates important information. A: Remove latch side of gate frame. B: With latch side of gate frame removed, cut top and bottom gate rails 190 mm shorter than gate opening W.
