Summary of Contents for CompuLab IOT-DIN-IMX8PLUS

Page 1 IOT-DIN-IMX8PLUS Reference Guide...
Page 2 To the extent permitted by law, no liability (including a liability to any person because of negligence) will be accepted by CompuLab, its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or inaccuracies in this document.
Page 3: Table Of Contents
About This Document ...................... 6 Related Documents ......................6 OVERVIEW ........................7 Highlights ......................... 7 Specifications ........................8 IOT-DIN-IMX8PLUS Part Number ................9 CORE SYSTEM COMPONENTS .................. 10 NXP i.MX8M Plus SoC ....................10 System Memory ......................10 3.2.1 DRAM ........................10 3.2.2...
Page 4 SIM card socket ......................20 Indicator LEDs ....................... 20 Antenna Connectors ....................... 20 MECHANICAL DRAWINGS ..................21 OPERATIONAL CHARACTERISTICS ............... 22 Absolute Maximum Ratings ..................22 Recommended Operating Conditions ................22 Typical Power Consumption ..................22 May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 5 • May 2024 First release Please check for a newer revision of this manual at the Compulab website. https://www.compulab.com. Compare the revision notes of the updated manual from the website with those of the printed or electronic version you have.
Page 6: Introduction
This document is part of a set of documents providing information necessary to operate and program Compulab IOT-DIN-IMX8PLUS. Related Documents For additional information not covered in this manual, please refer to the documents listed in Table 2. Table 2 Related Documents Document Location IOT-DIN-IMX8PLUS resources https://www.compulab.com/products/iot-gateways/iot-din-imx8plus- industrial-iot-gateway/#devres May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 7: Overview
Overview OVERVIEW Highlights IOT-DIN-IMX8PLUS is an industrial IoT gateway with integrated DIN rail latch mechanism and modular I/O Expansion modules. • CPU: NXP i.MX8M Plus, quad-core Cortex-A53, 1.8GHz • DRAM : Up to 8GB RAM ; Storage: Up to 128GB eMMC •...
Page 8: Specifications
Overview Specifications The "Option" column specifies the IOT-DIN-IMX8PLUS configuration option required to have the feature. "+" means that the feature is always available. Table 3 Features and Configuration options. Feature Description Option CPU Core and Graphics NXP i.MX8M Plus QuadLite, quad-core ARM Cortex-A53, 1.8GHz C1800Q NXP i.MX8M Plus Quad, quad-core ARM Cortex-A53, 1.8GHz...
Page 9: Iot-Din-Imx8Plus Part Number
FCC, CE, UKCA EN 55032/5, EN 61000-6-2, EN 61000-6-3 Safety EN/UL/IEC 62368-1 IOT-DIN-IMX8PLUS Part Number To decode the IOT-DIN-IMX8PLUS part number please refer to the ‘Ordering’ section of the IOT- DIN-IMX8PLUS product page: https://www.compulab.com/products/iot-gateways/iot-din-imx8plus- industrial-iot-gateway/#ordering. May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 10: Core System Components
IOT-DIN-IMX8PLUS is available with up to 8GB of on-board LPDDR4 memory. 3.2.2 Primary Storage IOT-DIN-IMX8PLUS features up to 128GB of soldered on-board eMMC memory for storing the bootloader and operating system (Kernel and root filesystem). The remaining eMMC space is used to store general-purpose (user) data.
Page 11: Cellular And Gps
IOT-DIN-IMX8PLUS cellular interface is implemented with a mini-PCIe cellular modem module and a nano-SIM socket. To set up IOT-DIN-IMX8PLUS for cellular functionality, install an active SIM card into nano-SIM socket. The cellular module should be installed into the mini-PCIe socket.
Page 12: Can Bus
Core System Components 3.7.1 CAN Bus IOT-DIN-IMX8PLUS features a CAN 2.0B port implemented with i.MX8M Plus CAN controller. Key characteristics: • Galvanic isolation from the main unit Note: IOT-DIN-IMX8PLUS does NOT provide built-in termination on the CAN bus port. External termination should be added depending on the bus topology.
Page 13 Core System Components Figure 2 Digital output – typical wiring example Figure 3 Digital input – typical wiring example May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 14: I/O Expansion Modules
I/O EXPANSION MODULES I/O Expansion Modules Interconnection IOT-DIN-IMX8PLUS supports up to eight I/O Expansion Modules that can be stacked with the main gateway in order to extend the feature set of the system. A gateway assembly includes one gateway (the left most unit) and multiple I/O Expansion modules.
Page 15: System Logic
IOT-DIN-IMX8PLUS RTC is implemented with the AM1805 real-time clock (RTC) chip. The RTC is connected to the i.MX8M Plus SoC using I2C interface at address 0xD2/D3. IOT-DIN-IMX8PLUS back-up battery keeps the RTC running to maintain clock and time information whenever the main power supply is not present.
Page 16: Interfaces And Connectors
System reset push-button Console connector, micro-USB type Antenna A, SMA RP * Industrial I/O terminal block, 16 pin, 16-26 AWG Antenna B, SMA RP * DC power input connector *: Present only in configuration with cellular modem May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 17: Bottom Panel
4-pin dual-raw plug with screw terminal connections Locking: screw flange Pitch: 3.5 mm Wire cross-section: AWG 16 – AWG 26 Connector P/N: JL15EDGVM-35004G0[1|2] Mating connector P/N: JiNL JL15EDGKM-35004G01 NOTE: Compulab supplies the mating connector with the gateway unit May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 18: Remote Power Cntl Input
6.2.2 Typical Connection Schematic Figure 4 power connector typical connection USB Host Connector IOT-DIN-IMX8PLUS USB3.0 host port is available through standard type-A USB3 connector. USB3.0 port is implemented directly with the native i.MX8M Plus port. May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 19: Industrial I/O Connector
Interfaces and Connectors Industrial I/O Connector IOT-DIN-IMX8PLUS industrial I/O signals are routed to terminal block. Connector pin-out is shown below. For additional details please refer to section 3.7. Table 11 Industrial I/O add-on connector pin-out Signal Name Description Isolation Power Domain...
Page 20: Rj45 Ethernet Connectors
Interfaces and Connectors RJ45 Ethernet Connectors IOT-DIN-IMX8PLUS features two Ethernet ports ETH0 and ETH1, routed to two RJ45 connectors. For more info, refer to section 3.4. SIM card socket IOT-DIN-IMX8PLUS nano-SIM card socket is located on the bottom panel. For SIM card installation instructions please refer to the IOT-DIN-IMX8PLUS User’s Manual.
Page 21: Mechanical Drawings
Mechanical Drawings MECHANICAL DRAWINGS IOT-DIN-IMX8PLUS 3D model is available for download at: https://www.compulab.com/products/iot-gateways/iot-din-imx8plus-industrial-iot- gateway/#devres May 2024 IOT-DIN-IMX8PLUS Reference Guide...
Page 22: Operational Characteristics
NOTE: Stress beyond Absolute Maximum Ratings may cause permanent damage to the device Recommended Operating Conditions Table 18 Recommended Operating Conditions Parameter Typ. Unit Main power supply voltage 12-24 28.8 Typical Power Consumption *** To be included in future revisions of this document May 2024 IOT-DIN-IMX8PLUS Reference Guide...
