SERVICE MANUAL
DRY WELLS
MODEL:
Dual Line
I-Line
Mini Flex Line
PART NUMBER:
18018765
18018767
18018707
Dry Well ( 18018707 Shown  )

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Dual Line and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Franke Dual Line

  • Page 1 SERVICE MANUAL DRY WELLS MODEL: Dual Line I-Line Mini Flex Line PART NUMBER: 18018765 18018767 18018707 Dry Well ( 18018707 Shown  )
  • Page 2: Important Safety Information

    D A N GER D A N GER - NEVER make ANY modifications to the unit that are not authorized by documentation provided by Franke . Energized electrical circuits present a life-threatening hazard of electric shock, explosion, or arc flash.
  • Page 3: Table Of Contents

    Unlocking the Controller ....................11 Troubleshooting ..................... 12 Testing the Temperature Sensors ..................12 Common Service Parts ..................14 Exterior (Dual Line) ......................14 Exterior (I-Line) ......................15 Exterior (Mini Flex Line) ....................16 Control Module (Dual & I-Line) ..................17 Control Module (Mini Flex Line) ..................18 Dry Well (Dual &...
  • Page 4: Removal & Installation Of Parts

    REMOVAL & INSTALLATION OF PARTS Power ON/OFF Switch & Controllers D A N GE R D A N GE R RISK OF ELECTRIC SHOCK ALWAYS disconnect and discharge electrical circuits before performing circuit work. Verify circuit is discharged using an appropriately rated voltage detecting device.
  • Page 5 REMOVAL & INSTALLATION OF PARTS CONTROLLER EVCO TERMINAL WIRE COLOR Terminal 1 Empty Terminal 2 Empty Terminal 3 Empty Terminal 4 To Power ON/OFF Switch Terminal 5 Empty 9 10 11 12 Terminal 6 To Power ON/OFF Switch Terminal 8 To Relay Terminal 9 Empty...
  • Page 6: Solid State Relays

    REMOVAL & INSTALLATION OF PARTS Solid State Relays D A N GE R D A N GE R RISK OF ELECTRIC SHOCK ALWAYS disconnect and discharge electrical circuits before performing circuit work. Verify circuit is discharged using an appropriately rated voltage detecting device.
  • Page 7: Heater Access Panels

    REMOVAL & INSTALLATION OF PARTS Heater Access Panels D AN GER D AN GER RISK OF ELECTRIC SHOCK ALWAYS disconnect and discharge electrical circuits before performing circuit work. Verify circuit is discharged using an appropriately rated voltage detecting device. CA UT ION CA UT ION SHARP SURFACES HAZARD ALWAYS wear appropriate personal protective equipment...
  • Page 8: High Limit Switches

    REMOVAL & INSTALLATION OF PARTS High Limit Switches D A N GE R D A N GE R RISK OF ELECTRIC SHOCK ALWAYS disconnect and discharge electrical circuits before performing circuit work. Verify circuit is discharged using an appropriately rated voltage detecting device.
  • Page 9: Temperature Sensors

    REMOVAL & INSTALLATION OF PARTS Temperature Sensors D AN GER D AN GER RISK OF ELECTRIC SHOCK ALWAYS disconnect and discharge electrical circuits before performing circuit work. Verify circuit is discharged using an appropriately rated voltage detecting device. CA UT ION CA UT ION SHARP SURFACES HAZARD ALWAYS wear appropriate personal protective equipment...
  • Page 10: Heating Elements

    REMOVAL & INSTALLATION OF PARTS Heating Elements D A N GE R D A N GE R RISK OF ELECTRIC SHOCK ALWAYS disconnect and discharge electrical circuits before performing circuit work. Verify circuit is discharged using an appropriately rated voltage detecting device.
  • Page 11: Procedures & Adjustments

    PROCEDURES & ADJUSTMENTS Temperature Setpoint Adjustment Document URL: Refer to the Dry Wells Operation Manual for the https://tinyurl.com/ temperature setpoint adjustment. vyerzm5 Periodic Maintenance Document URL: Refer to the Dry Wells Operation Manual for https://tinyurl.com/ periodic maintenance procedures. vyerzm5 NOTICE NOTICE IMPORTANT SERVICE INFORMATION By default, the controller is locked from the factory.
  • Page 12: Troubleshooting

    PROCEDURES & ADUJUSTMENTS Testing the Temperature Sensors It is important to confirm whether the coil and air 3. Remove temperature sensor from unit (refer to Temperature Sensors, page 9), and submerge temperature sensors are operating within specified parameters. sensor into cup of water. Use the following test to determine if sensor 4.
  • Page 13 Temperature sensor is correctly (refer to Temperature Sensors , page not installed correctly. If following these steps does not fix the problem, contact Franke at (800) 537-2653 and press 2 for Technical Support. 19014983 - Rev. C - April 29, 2020...
  • Page 14: Common Service Parts

    Fig. 16 ITEM PART # DESCRIPTION 27808075 Hot Well Aluminum Kit 30-210012623 Front Shelf, Dual Line 18018051 Side Shelf Extension, Dual Line 30-210009091 Side Hanger 19003592 Caster, 3-1/2" Dia., Swivel Plate Table 3 19014983 - Rev. C - April 29, 2020...
  • Page 15: Exterior (I-Line)

    COMMON SERVICE PARTS Exterior (I-Line) DETAIL C Fig. 17 ITEM PART # DESCRIPTION 18018054 Side Shelf Extension, I-Line, LH 27808075 Hot Well Aluminum Kit 30-210015009 Back Shelf, I-Line 30-210015006 Front Shelf, I-Line 30-210009091 Side Hanger 19003592 Caster, 3-1/2" Dia., Swivel Plate Table 4 19014983 - Rev.
  • Page 16: Exterior (Mini Flex Line)

    COMMON SERVICE PARTS Exterior (Mini Flex Line) DETAIL D Fig. 18 ITEM PART # DESCRIPTION 30-210014909 Back Shelf, Mini Flex Line Hot Well Aluminum Kit, Mini Flex Line 30-210014910 Front Shelf, Mini Flex Line 19003592 Caster, 3-1/2" Dia., Swivel Plate 30-210009091 Side Hanger Table 5 * Contact Technical Support for assistance...
  • Page 17: Control Module (Dual & I-Line)

    COMMON SERVICE PARTS Control Module (Dual & I-Line) Fig. 19 ITEM PART # DESCRIPTION 19013980 Relay, Solid State, Panel Mount, 24 A, 24-280 VAC 19008887 Electrical Cord w/ NEMA L14-20P 30-210005487 Face Plate, Control Panel Controller, EVCO , f/ Dry Wells 18016470 385.152 Rocker Switch, Illuminated...
  • Page 18: Control Module (Mini Flex Line)

    COMMON SERVICE PARTS Control Module (Mini Flex Line) Fig. 20 ITEM PART # DESCRIPTION 19013980 Relay, Solid State, Panel Mount, 24 A, 24-280 VAC 19008887 Electrical Cord w/ NEMA L14-20P 30-210009614 Face Plate, Control Panel Controller, EVCO , f/ Dry Wells 18016470 385.152 Rocker Switch, Illuminated...
  • Page 19: Dry Well (Dual & I-Line)

    COMMON SERVICE PARTS Dry Well (Dual & I-Line) Fig. 21 ITEM PART # DESCRIPTION 30-210006030 Insulation Cover, LH 30-210006710 Insulation Bracket 30-210005380 Element Bracket 19013225 Switch, High Limit 19013343 Non-Rotating Bolt Sensor, PT1000 19013222 Heater, Rod 30-210006027 Insulation Cover, RH Table 8 19014983 - Rev.
  • Page 20: Dry Well (Mini Flex Line)

    COMMON SERVICE PARTS Dry Well (Mini Flex Line) Fig. 22 ITEM PART # DESCRIPTION 30-210009620 Insulation Cover, Mini Flex Line, LH 30-210006710 Insulation Bracket 30-210005380 Element Bracket 19013225 Switch, High Limit 19013343 Non-Rotating Bolt Sensor, PT1000 19013222 Heater, Rod 30-210009622 Insulation Cover, Mini Flex Line, RH Table 9 19014983 - Rev.
  • Page 21: Specifications

    Can select °F or °C? Can adjust temperature from display? Can Initiate Defrost from display? Display During Defrost Cycle ELECTRICAL PARAMETER DUAL LINE/I-LINE MINI FLEX LINE Supply Power 208 V/60 Hz/1 Ph 208 V/60 Hz/1 Ph Load Center Amperage 15.9 A 11.2 A...
  • Page 22: Electrical Diagrams

    ELECTRICAL DIAGRAMS TITLE DRAWING # REV. VERS. DATE Electrical Diagram, Dual/I-Line Dry Wells 19013458 11/5/2019 Fig. 23 19014983 - Rev. C - April 29, 2020...
  • Page 23 ELECTRICAL DIAGRAMS TITLE DRAWING # REV. VERS. DATE Electrical Diagram, Mini Flex Line Dry Well 19014001 10/21/2019 Fig. 24 19014983 - Rev. C - April 29, 2020...
  • Page 24: Warranty

    - All Components - 1 Year Parts and Labor (year 1) Exclusions: Certain Franke parts that are expendable by nature and need to be replaced frequently may not be covered. Franke is not liable under these warranties for repairs or damages due to improper operation, maintenance or cleaning, attempted repairs or installation by unauthorized persons, alterations, water quality, abuse, fire, flood or acts of God.
  • Page 25: Notes

    NOTES 19014983 - Rev. C - April 29, 2020...
  • Page 26 NOTES 19014983 - Rev. C - April 29, 2020...
  • Page 27 NOTES 19014983 - Rev. C - April 29, 2020...
  • Page 28 © 2020 Franke Foodservice Systems, Inc. This media is the confidential and proprietary property of Franke Foodservice Systems, Inc. and shall not be reproduced in any form of media without the express written permission of Franke. Due to continuous product development, Franke reserves the right to make changes in design and specifications without prior notice.
