2K Quad HD

Body Worn Camera

RVS-BC87810

Instruction Manual

Table of Contents

Need help?

Do you have a question about the RVS-BC87810 and is the answer not in the manual?

Questions and answers

Summary of Contents for Safe Fleet RVS-BC87810

Page 2 Warnings 1.Built-in Battery , please do not punch the battery or throw the product into fire. 2.Do not replace the battery by user themselves. 3.Do not disassemble, repair or make any modifications to the product by users themselves. 4.Please store this product safely and correctly, use this product under specified environment temperature.
Page 3: Product Overview
Thanks for choosing our product! Multiple functions in this body worn camera suits for different workers in various industrial field. For professional law enforcement, it brings policeman justice; For consumers in other fields, it can be used as an utility life recorder, meeting recorder or car DVR, etc. We hope you enjoy all the benefits of features! Product Overview Body Worn Camera often utilized by law enforcement to record their interactions...
Page 4 Product Features 二、产品参数 Item Parameter Item Parameter Up to 10 Meters with Night Vision Dimension 96 mm *62 mm *31mm Visible Face Detection Weight 165g Support G-Sensor Motion Support Sensor 5MP CMOS Detection Recording Wide Angle 140 degrees Chipset Ambarella H22 Angle 2 inch TFT-LCD High- IR Light...
Page 5: Quick Operation
Quick Operation Long press to power on/off , short press it to turn screen on/off. Short press to start voice recording, and short press again to stop recording. Short press to take a photo. Short press to start video recording, and short press again to stop recording. Short press to turn on infrared light, and short press again to turn it off.
Page 6 DC port USB port Up browse key OK confirm / Auxiliary location light key Menu/Down browse key USB port Reset key OUT port...
Page 7 Mark for important files (Important file can't be delete by buttons) Audio recording key/ One-click audio recording key/ One-click to change resolution Photo shooting key/ Flashing key Video recording key One-click video recording key Power on & off/ Menu return key/ Turn on &...
Page 8: Display Screen Description
Multifunction charging base port Display Screen Description Remaining Remaining video duration battery life Pixel Video Resolution Camera ID, User ID Current time Remaining memory...
Page 9: Basic Operation Description
Basic Operation Description Boot Press for 2 seconds, the camera will beep on with a green LED, and the camera turn to standby mode with the screen lighted on. Audio Recording Short press , the camera will shake, then the LED flash to yellow and the camera start audio recording.
Page 10: Laser Pointer
1) In standby mode, short press “OK” button to select file types, then choose a file that you want to delete, and then long press “M” button to get two options “Delete this file” or “Delete all files”, press “OK” button to confirm deletion. 2) User also can clear the memory by selecting “format”...
Page 11 Boot Press for 2 seconds, the camera will beep on with a green LED, and the camera turn to standby mode with the screen lighted on. Audio Recording Short press , the camera will shake, then the LED flash to yellow and the camera start audio recording.
Page 12 The quality of the image for video and Quality Fine, Normal photo files. Fomat Video encoding format, higher Video H.264, H.265 encoding format save more memory space. Encode When on, any video you record will include some of the time that elapsed before you press the Record button (stored in the Off, On Pre-record...
Page 13 When GPS is on, position of video will be recorded and can be reviewed by GPS Off, On player. (GPS satellite signal only works in outside) Adopt local time in real time zone Time Zone -12 to +12 When on, indicator LED will tell the status of the camera;...
Page 14 The amount of the time the camera can be Off, 1 min, 3 min, Auto Power idle before powering off. 5 min, 10 min The volume of camera speaker. This affects the loudness of video playback, audio playback, the key tone, record warning, and Volume 0-12 any other sounds played by camera.
Page 15: Indicator Light
USB MODE--Access File Data To cater for a variety of uses, This body worn camera can be set to password protection mode, or password-free mode in menu. (Password: ON, OFF) In both modes, videos can be managed without driver software. Driver software is needed only if user's computer doesn't recognize the camera or when user want to change password.
Page 16: Key Function Description
Key Function Description Reset Key Reset it when the camera freezes by some errors. Combination Key One key play key In standby mode, press this key to playback the last audio or video file. Page up key Go to menu, press this key can select object to up and left. Focus adjustment function Long press this key can adjust 8X focus change under standby or video recording mode.
Page 17 Video classification key Traffic control, criminal investigation and public security can be selected when long press this key for 4 seconds. Short press to select the mode, and short press to confirm. Combination Key Audio recording key Press this key to start audio recording, press it again to stop it. One key audio recording key When the camera is under turn off status, 4 seconds long press this key to start audio recording, press it again to stop it.
Page 18 press it again to stop it. One key video recording key Under turn off status, long press for 4 seconds to start video recording, and press it again to stop it. Combination Key Menu key Press this key into system setting interface. Page down key Also press this key to select file from up and left when browse the files.
Page 19 Power ON & OFF / Turn ON & OFF Screen Key/Return Key Long press this key to turn on/off camera. In home page, short press it to lock the screen, short press it again to unlock. In sub-page, short press it to return previous page.
Page 20 Battery Life: Battery life vary from different settings and environments. In our test, the camera last 10-11 hours in following setting: 28 degrees Celsius indoors, 720P resolution, GPS off, IR off ; and last about 8-9 hours in 28 degrees Celsius indoors, 1296P resolution, GPS off, IR off.
Page 21 Camera Management System IMPORTANT NOTICE: Driver and Management System may not be needed for some users, because the data in camera can be managed directly at USB MODE, and camera menu already included all settings on software. They’re needed only if user's computer doesn't recognize the camera or when user want to change password.
Page 22 Installation Please download software from CD Before installing the software, you'd better close the firewall first. Double click the software to install, then always go next step until finish them all. 1. Choose the language. 2. Click 'Next'. 3. Click 'Install'.
Page 23 7. Click 'Install' 8. After installation, desktop shortcuts will be shown as below: 'Ambarella USB' is the driver, you don't need to open it. 'Body_Camera_Managemnt' is the management software. Notes: If the PC with firewall and trying to forbid the installation, please choose 'allow this operation' or 'always allow install this driver software' .
Page 24: Parameter Setting
There are Administrator and User roles for login. User can read the camera information, calibrate time and enter to camera disk. Administrator has the highest authority to manage the cameras and revise password. Login steps: Enter password on software – click 'connect device' – click 'login’...
Page 25: Password Setting
Password Setting User can revise common user login password only; Admin can revise all passwords; Please do remember to click “Setting” after any revise to save all changes. Enter to U-disk mode Click 'enter to U-disk', the connection of management software with camera will be cut off, then camera will enter U-disk , data transfer or deletion will be allowed in this mode.
Page 27: Troubleshooting
Troubleshooting 1. Q: The image is freezing or abnormal, button doesn’t work. A: Use a pin or pen to press reset button ( under the HDMI rubber port) to have camera resetting when camera works abnormally. Note: DO NOT PRESS this button except maloperation. 2.
Page 28 After that, find the removable USB flash drive in your computer, then you can copy or delete the videos. 5. Q: Can I set password for the camera? A: Yes, the camera default without password. If needed, please turn password on in menu, default password is 000000 (press six times “OK” button) If you want to change password, please download the software in CD.
Page 29 Before recording videos, please turn on GPS in camera menu, thus, the recorded video can be played on GPS player with tracking information. For more information, please refer “Usage of GPS Player”. Note: GPS is satellite signal, it works only in outside, some place maybe with bad signal, please test in open field with good signal.
