welcoming
OPTION 1
(Semi-Recessed Sink)
36-IN VANITY WITH TOP
ITEM #4767874; 4767875; 4767872; 4767873; 4767870; 4767871; 4767868; 4767869; 4767866;
4767867; 4767864; 4767865; 4767862; 4767863; 4767860; 4767861; 4767858; 4767859;
4767856; 4767857; 1028411; 864252; 864250; 3839324; 864251; 3839323;
4767854; 4767855; 4767852; 4767853; 1028412; 864253; 3839322; 864255; 3839321
MODEL #1227VA-36-326-926; 1227VA-36-326-926-SR; 1227VA-36-326-925; 1227VA-36-326-925-SR;
1227VA-36-326-901; 1227VA-36-326-901-SR; 1227VA-36-326-900; 1227VA-36-326-900-SR;
1227VA-36-287-926; 1227VA-36-287-926-SR; 1227VA-36-287-925; 1227VA-36-287-925-SR;
1227VA-36-287-901; 1227VA-36-287-901-SR; 1227VA-36-287-900; 1227VA-36-287-900-SR;
1227VA-36-242-926; 1227VA-36-242-926-SR; 1227VA-36-242-925; 1227VA-36-242-925-SR;
1227VA-36-242-905; 1227VA-36-242-903; 1227VA-36-242-901; 1227VA-36-242-901-SR;
1227VA-36-242-900; 1227VA-36-242-900-SR; 1227VA-36-201-926; 1227VA-36-201-926-SR;
1227VA-36-201-925; 1227VA-36-201-925-SR; 1227VA-36-201-905; 1227VA-36-201-901;
1227VA-36-201-901-SR; 1227VA-36-201-900; 1227VA-36-201-900-SR
ATTACH YOUR RECEIPT HERE
Serial Number__________________ Purchase Date__________________
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday.
•
sophisticated
OR
1
•
inspiring
OPTION 2
(Undermount Sink)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LOWES 1227VA-36-326-926
Summary of Contents for LOWES 1227VA-36-326-926
- Page 1 4767867; 4767864; 4767865; 4767862; 4767863; 4767860; 4767861; 4767858; 4767859; 4767856; 4767857; 1028411; 864252; 864250; 3839324; 864251; 3839323; 4767854; 4767855; 4767852; 4767853; 1028412; 864253; 3839322; 864255; 3839321 MODEL #1227VA-36-326-926; 1227VA-36-326-926-SR; 1227VA-36-326-925; 1227VA-36-326-925-SR; 1227VA-36-326-901; 1227VA-36-326-901-SR; 1227VA-36-326-900; 1227VA-36-326-900-SR; 1227VA-36-287-926; 1227VA-36-287-926-SR; 1227VA-36-287-925; 1227VA-36-287-925-SR; 1227VA-36-287-901; 1227VA-36-287-901-SR; 1227VA-36-287-900; 1227VA-36-287-900-SR;...
- Page 2 MODEL NUMBER DESCRIPTION 1227VA-36-326-926 CNTRBRY 36-IN VTY SEA GRN ECLT TOP 1227VA-36-326-926-SR CNTRBRY 36-IN VTY SEA GRN ECLT SR 1227VA-36-326-925 CNTRBRY 36-IN VTY SEA GRN EC TOP 1227VA-36-326-925-SR CNTRBRY 36-IN VTY SEA GRN EC SR 1227VA-36-326-901 CNTRBRY 36-IN VTY SEA GRN WH TOP...
-
Page 3: Table Of Contents
TABLE OF CONTENTS FOR OPTION 1 (Semi-Recessed Sink) Package Contents...........................4 Hardware Contents..........................4 Safety Information..........................4 Preparation............................5 Assembly or Installation Instructions ....................5 Care and Maintenance........................10 Warranty............................10 Replacement Parts List........................11 TABLE OF CONTENTS FOR OPTION 2 (Undermount Sink) Package Contents.........................15 Hardware Contents........................15 Safety Information..........................15 Preparation............................16 Assembly or Installation Instructions .....................16 Care and Maintenance........................21... -
Page 4: Package Contents
PACKAGE CONTENTS (Semi-Recessed Sink) PART DESCRIPTION QUANTITY CARTON Vanity Box 2 of 3 Box 1 of 3 Backsplash Sink Box 3 of 3 Top Drawer (preassembled to vanity(A)) Box 2 of 3 Bottom Drawer (preassembled to vanity(A)) Sink Template Box 1 of 3 HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Touch Up Pen... -
Page 5: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 45 minutes (24 hours for silicone caulk to dry). Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone caulk, power drill with drill bit, measuring tape, level INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) - Page 6 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 3. Using hardware appropriate for your wall type (not included), secure Vanity Cabinet (A) to two wall studs anywhere through the Vanity Mounting Plates. Be careful not to disturb any electrical or water lines that may be concealed in the wall.
- Page 7 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) Note: A t this stage it may be easier to install the faucet and drain kit (not included) to top (B) per the manufacturer’s instructions, before moving on to Step 5. 5. Apply stain free silicone caulk (not included) to the top edge of vanity (A).
- Page 8 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 7. Apply a thin bead of silicone caulk (not included) onto the stone top close to the edge of the sink cut out as pictured. 8. With the help of another adult, Gently lower the sink onto the stone top using even pressure to set the sink properly.
- Page 9 INSTALLATION INSTRUCTIONS (Semi-Recessed Sink) 9. To re-install top drawer (E) and bottom drawer (F). Fully extend lower drawer glide tracks. With the help of another adult, hold the extended glide in one hand and the drawer in the other. Gently place the back of the drawer box into the metal hook located on the back of the drawer track.
-
Page 10: Care And Maintenance
CARE AND MAINTENANCE • Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the vanity with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 11: Replacement Parts List
REPLACEMENT PARTS LIST FOR 1227VA-36-201-SR (Semi-Recessed Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 3550VT-36-900 Complete Set 36" Engineered White Top 3550VT-36-901 Complete Set 36"... - Page 12 REPLACEMENT PARTS LIST FOR 1227VA-36-242-SR (Semi-Recessed Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 3550VT-36-900 Complete Set 36" Engineered White Top 3550VT-36-901 Complete Set 36"...
- Page 13 REPLACEMENT PARTS LIST FOR 1227VA-36-287-SR (Semi-Recessed Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 3550VT-36-900 Complete Set 36" Engineered White Top 3550VT-36-901 Complete Set 36"...
- Page 14 REPLACEMENT PARTS LIST FOR 1227VA-36-326-SR (Semi-Recessed Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 3550VT-36-900 Complete Set 36" Engineered White Top 3550VT-36-901 Complete Set 36"...
-
Page 15: Package Contents
PACKAGE CONTENTS (Undermount Sink) PART DESCRIPTION QUANTITY CARTON Vanity Box 2 of 3 Box 1 of 3 Backsplash Sink Box 3 of 3 Top Drawer (preassembled to vanity(A)) Box 2 of 3 Bottom Drawer (preassembled to vanity(A)) HARDWARE CONTENTS (NOT SHOWN ACTUAL SIZE) Touch Up Pen Allen Wrench Bolt... -
Page 16: Preparation
PREPARATION Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and hardware contents list. If any part is missing or damaged, do not attempt to assemble the product. Estimated Installation Time: 45 minutes (24 hours for silicone caulk to dry). Tools Required for Installation (not included): Phillips screwdriver, utility knife or scissors, silicone caulk, power drill with drill bit, measuring tape, level INSTALLATION INSTRUCTIONS (Undermount Sink) - Page 17 INSTALLATION INSTRUCTIONS (Undermount Sink) 3. Using hardware appropriate for your wall type (not included), secure Vanity Cabinet (A) to two wall studs anywhere through the Vanity Mounting Plates. Be careful not to disturb any electrical or water lines that may be concealed in the wall.
- Page 18 INSTALLATION INSTRUCTIONS (Undermount Sink) 5. Apply silicone caulk (not included) to the top edge of sink (D). With the help of another adult, lower the sink onto the back side of the stone top. Make sure the sink over-flow hole is facing the front of stone top.
- Page 19 INSTALLATION INSTRUCTIONS (Undermount Sink) 7. Lower the sink brackets (LL) over the bolts (KK) and allow to rest on the sink lip. Adjust location of bracket to firmly grasp sink lip. Lower lock washers (NN) over bolts (KK) and secure with nuts (MM). Hand tighten nuts (MM) with included wrench (OO).
- Page 20 INSTALLATION INSTRUCTIONS (Undermount Sink) 9. To re-install top drawer (E) and bottom drawer (F). Fully extend lower drawer glide tracks. With the help of another adult, hold the extended glide in one hand and the drawer in the other. Gently place the back of the drawer box into the metal hook located on the back of the drawer track.
-
Page 21: Care And Maintenance
CARE AND MAINTENANCE • Dust the vanity regularly with a soft, non-lint producing cloth or household dusting product. • You can clean the vanity with a gentle, non-abrasive household cleaner. • Make sure to dry the wood immediately with a soft cloth or towel. •... -
Page 22: Replacement Parts List
REPLACEMENT PARTS LIST FOR 1227VA-36-201 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 2550VT-36-900 Complete Set 36" Engineered White Top 2550VT-36-901 Complete Set 36"... - Page 23 REPLACEMENT PARTS LIST FOR 1227VA-36-242 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 2550VT-36-900 Complete Set 36" Engineered White Top 2550VT-36-901 Complete Set 36"...
- Page 24 REPLACEMENT PARTS LIST FOR 1227VA-36-287 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 2550VT-36-900 Complete Set 36" Engineered White Top 2550VT-36-901 Complete Set 36"...
- Page 25 REPLACEMENT PARTS LIST FOR 1227VA-36-326 (Undermount Sink) For replacement parts, call our customer service department at 1-866-439-9800, 8 a.m. - 8 p.m., EST, Monday - Sunday. PART DESCRIPTION PART # Complete Set 36" Carrara Marble Top 2550VT-36-900 Complete Set 36" Engineered White Top 2550VT-36-901 Complete Set 36"...
