- Page 1 Digital Camera/Body/Lens Kit/Double Zoom Lens Kit DC-GX9P Model No. DC-GX9PP DC-GX9EB DC-GX9EC DC-GX9EE DC-GX9EF DC-GX9EG DC-GX9GC DC-GX9GD DC-GX9GH DC-GX9GK DC-GX9GN DC-GX9GT DC-GX9KP DC-GX9KEB DC-GX9KEC DC-GX9KEE DC-GX9KEF DC-GX9KEG DC-GX9KGC DC-GX9KGD DC-GX9KGH © Panasonic Corporation 2018 Unauthorized copy- ing and distribution is a violation of law.
- Page 2 DC-GX9KGK DC-GX9MEF DC-GX9MEG DC-GX9KGN DC-GX9NEB DC-GX9WEB DC-GX9NEC DC-GX9WEF DC-GX9NEF DC-GX9WEG DC-GX9NEG DC-GX9MP DC-GX9HEF DC-GX9MPP DC-GX9HEG DC-GX9MEB DC-GX9CGC DC-GX9MEC Colour [DC-GX9] [DC-GX9N] (K)...Black Type (K)...Black Type (S)...Silver Type (S)...Silver Type (except EC) [DC-GX9K] [DC-GX9H] (K)...Black Type (K)...Black Type (S)...Silver Type (S)...Silver Type [DC-GX9W] [DC-GX9C] (K)...Black Type...
-
Page 3: Table Of Contents
TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions----------------------------------------------- 4 13 Wiring Connection Diagram--------------------------------- 76 1.1. General Guidelines---------------------------------------- 4 13.1. Interconnection Diagram ------------------------------- 76 1.2. Leakage Current Cold Check--------------------------- 4 14 Schematic Diagram -------------------------------------------- 77 1.3. Leakage Current Hot Check (See Figure. 1) ------- 4 15 Printed Circuit Board ------------------------------------------ 77 1.4. -
Page 4: Safety Precautions
1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check (See Figure. 1) 1. IMPORTANT SAFETY NOTICE There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check. - Page 5 1.4. How to Discharge the E.Capacitor on Flash P.C.B. CAUTION: • Be sure to discharge the E.Capacitor on Flash P.C.B. before disassembling. • Be careful of the high voltage circuit on Flash P.C.B. when servicing. [Discharging Procedure] 1. Remove the Top Case Unit. 2.
-
Page 6: Warning
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD). -
Page 7: How To Replace The Lithium Battery
2.3. How to Replace the Lithium Battery 2.3.1. Replacement Procedure 1. Remove the Top P.C.B.. (Refer to Disassembly Procedures.) 2. Unsolder the each soldering point of electric lead terminal for Lithium battery (Ref. No. “B7001” at component side of Top P.C.B.) and remove the Lithium battery together with electric lead terminal. -
Page 8: Service Navigation
3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2. - Page 9 3.3.1.3. About Main P.C.B. (Ref.1) & Flash-ROM (IP6001) Before exchanging the “Main P.C.B.”, confirm that the symptom and/or phenomenon is not due to the setting of functions. Important: When replacing the Main P.C.B. that cannot be repaired by exchanging the IC, carry out any of followings. In the case of exchanging the Flash-ROM (IP6001) is same way too.
- Page 10 3.3.2. Lens Unit (Interchangeable Lens: H-FS12032) 3.3.2.1. About Lens Main Unit (Ref. 203) 1. Lens Main Unit (Ref. 203) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, if there are any needs of the “Lens Main Unit” (Ref. 203), carefully confirm its performance in advance. 2.
- Page 11 3.3.3. Lens Unit (Interchangeable Lens: H-FS35100) 3.3.3.1. About Lens Main Unit (Ref. 409) 1. Lens Main Unit (Ref. 409) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, if there are any needs of the “Lens Main Unit” (Ref. 409), carefully confirm its performance in advance. 2.
- Page 12 3.3.4. Lens Unit (Interchangeable Lens: H-FS12060) 3.3.4.1. About Lens Main Unit (Ref. 506) 1. Lens Main Unit (Ref. 506) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, if there are any needs of the “Lens Main Unit” (Ref. 506), carefully confirm its performance in advance. 2.
- Page 13 3.3.5. Lens Unit (Interchangeable Lens: H-FS1442A) 3.3.5.1. About Lens Main Unit (Ref. 608) 1. Lens Main Unit (Ref. 608) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, if there are any needs of the “Lens Main Unit” (Ref. 608), carefully confirm its performance in advance. 2.
- Page 14 3.3.6. Lens Unit (Interchangeable Lens: H-FS14140) 3.3.6.1. About Lens Main Unit (Ref. 709) 1. Lens Main Unit (Ref. 709) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, if there are any needs of the “Lens Main Unit” (Ref. 709), carefully confirm its performance in advance. 2.
- Page 15 3.3.7. Lens Unit (Interchangeable Lens: H-H020A) 3.3.7.1. About Lens Main Unit (Ref. 815) 1. Lens Main Unit (Ref. 815) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, if there are any needs of the “Lens Main Unit” (Ref. 815), carefully confirm its performance in advance. 2.
-
Page 16: Service Notes
3.4. Service Notes 3.4.1. About Wi-Fi / Bluetooth Function The page number in this chapter does not show the page number of this service manual. 3.4.2. Important Notice of Servicing This camera unit has the personal information of wireless LAN connection the customer has registered. For the protection of private information, please erase the personal information after the completion of repair by “Initial Settings”. -
Page 17: General Description About Lead Free Solder (Pbf)
3.5. General Description About Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder. -
Page 18: How To Define The Model Suffix (Ntsc Or Pal Model)
3.6. How to Define the Model Suffix (NTSC or PAL Model) There are nine kinds of DC-GX7MK3/GX9 (Camera body unit), regardless of the colours. • a) DC-GX7MK3 (Japan domestic model) • b) DC-GX9P/PP • c) DC-GX9EB/EC/EF/EG • d) DC-GX9EE • e) DC-GX9GN •... - Page 19 3.6.2. Initial Settings: After replacing the Main P.C.B. and/or Flash-ROM, make sure to perform the initial settings after achieving the adjustment by order- ing the following procedure in accordance with model suffix of the unit. 1. Important Notice: Before proceeding Initial settings, make sure to read the following CAUTION. 2.
- Page 20 • Step 4. Display the Initial Settings: While pressing [ MENU/SET ] button and “[ RIGHT ] of Cursor buttons” simultaneously, turn the power off. The “Initial Settings” menu is displayed. There are two kinds of “Initial Settings” menu form as follows: [ CASE 1.
- Page 21 • Step 5. Cancel “Strict” mode: Press the [ DISP. ] button to cancel “Strict” mode. (Confirm the “Strict” is disappeared.) • Step 6. Choose the Model Suffix in “Initial Settings”: (Refer to “CAUTION”) [Caution: After replacing the Main P.C.B. and/or Flash-ROM] The model suffix can been chosen, JUST ONE TIME.
- Page 22 • Step 8. Confirmation: Confirm the display of “PLEASE SET THE CLOCK” in concerned language when the unit is turned on again. When the unit is connected to PC with USB cable, it is detected as removable media. (When the “GK” or “GT” model suffix is selected, the display shows “PLEASE SET THE CLOCK” in Chinese.) As for your reference, major default setting condition is as shown in the following table.
-
Page 23: Specifications
4 Specifications 4.1. Camera Body The following specification is based on DC-GX9K/DC-GX9M/DC-GX9N/DC-GX9H/DC-GX9W/DC-GX9. Some specifications may differ depending on model suffix. The page number in this chapter does not show the page number of this service manual. -
Page 27: Lens
4.2. Lens... -
Page 30: Location Of Controls And Components
5 Location of Controls and Components The following description is for DC-GX9K/DC-GX9M/DC-GX9N/DC-GX9H/DC-GX9W/DC-GX9. Some descriptions may differ depending on model suffix. The page number in this chapter does not show the page number of this service manual. 5.1. Camera Body )XQFWLRQ EXWWRQV >)Q@ WR >)Q@ DUH WRXFK LFRQV 7KH\ FDQ EH GLVSOD\HG E\ WRXFKLQJ WKH >... - Page 31 6KXWWHU EXWWRQ >0(186(7@ EXWWRQ ‡ &RQILUPDWLRQ RI VHWWLQJ FRQWHQWV HWF )URQW GLDO LV SHUIRUPHG 6KRXOGHU VWUDS H\HOHW >',63@ EXWWRQ ([SRVXUH FRPSHQVDWLRQ GLDO ‡ 8VH WKLV WR FKDQJH GLVSOD\ 0RGH GLDO 5HDU GLDO &DPHUD >212))@ VZLWFK ...
-
Page 32: Lens
5.2. Lens +)6 +)6 +)6 +)6$ +)6 /HQV VXUIDFH 7HOH =RRP ULQJ :LGH &RQWDFW SRLQW /HQV ILWWLQJ PDUN )RFXV ULQJ >2,6@ VZLWFK /HQV PRXQW UXEEHU 5HPRYLQJ WKH +RW 6KRH &RYHU 7KH FDPHUD FRPHV ZLWK D KRW VKRH FRYHU DWWDFKHG WR... -
Page 33: Service Mode
6 Service Mode 6.1. Error Code Memory Function 1. General Description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly. - Page 34 Error Code List The error code consists of 8 bit data and it shows the following information.
- Page 35 Important Notice about “Error Code List” About “*” indication: The third digit from the left is different as follows. - In case of 0 (example: 2B001000) When the third digit from the left shows “0”, this error occurred under the condition of Initial Settings has been completed. It means that this error is occurred basically at user side.
-
Page 36: Troubleshooting Guide
7 Troubleshooting Guide 7.1. Checking Method of Body and Interchangeable Lens 1. Initial (Default) Status Of The Lens Unit The Lens unit which is supplied as a standard accessory for this camera unit (H-FS12032, H-FS35100, H-FS12060, H- FS1442A, H-FS14140, H-H020A) shows the following status when the Lens is detached from the Camera unit. NOTE: Although the lens unit is attached it shows the same condition when the Camera turns off. - Page 37 3. Reference information...
-
Page 40: Wi-Fi Circuit (Front Plate Unit)
7.2. Wi-Fi Circuit (FRONT PLATE UNIT) 7.2.1. How to Remove Wi-Fi Password Protection To prevent incorrect operation or use of the Wi-Fi function by a third party and to protect saved personal information, this unit pro- tects the Wi-Fi function with a password. It is unable to service with password locked condition. -
Page 41: Service Fixture & Tools
8 Service Fixture & Tools 8.1. Service Fixture and Tools The following service fixture and tools are used for checking and servicing this unit. -
Page 43: Clean Box
8.2. Clean Box • The repair quality is considered, and it is recommended working in the environment of specified clean level less than class 10,000 (Federal Standard 209D). [NOTE] • Work in the environment of specified clean level less than class 10,000 (Federal Standard 209D) when inside cleaning of a lens. Please refer to the following service manuals. -
Page 44: Service Position
8.4. Service Position This service position is used for checking and replacing parts. Use the following extension cables for servicing. Table S1 Extension Cable List Parts No. Connection From RFKZ0466 FP9005(MAIN P.C.B.) ←→ FP8101(BATTERY P.C.B.) 27pin / 0.3 FFC RFKZ0466 FP8102(BATTERY P.C.B.) ←→... -
Page 45: Disassembly And Assembly Instructions
9 Disassembly and Assembly Instructions 9.1. Camera Body Part Disassembly Flow Chart 9.1.1. This is a disassembling chart. When assembling, perform this chart conversely. P.C.B. Location 9.1.2. - Page 46 Disassembly Procedure 9.1.3. Item Fig. Removal Mount, (Fig.D15) Screw (P) x 2 Mount Spring, Screw (Q) x 2 Lens Ring, Item Fig. Removal Convex x 2 Mount Base Unit Rear Case Unit (Fig.D1) Screw (A) x 1 Mount Screw (B) x 2 Mount Spring Screw (C) x 2 Screw (R) x 5...
- Page 47 Item Fig. Removal 12 LVF Unit (Fig.D27) Screw (c) x 1 Locking tab x 2 Convex x 2 LVF Top Plate Screw (d) x 2 (Fig.D28) Locking tab x 2 Eye Cup Unit Screw (e) x 2 Convex x 2 LVF Unit 13 LVF Module (Fig.D29)
- Page 48 (Fig.D2) (Fig.D3)
- Page 49 (Fig.D5) 9.1.3.2. Removal of the Top Case Unit (Fig.D6) (Fig.D4)
- Page 50 (Fig.D7) (Fig.D8)
- Page 51 (Fig.D10) (Fig.D9)
- Page 52 9.1.3.3. Removal of the Main P.C.B. and Sub P.C.B. (Fig.D11) (Fig.D12)
- Page 53 9.1.3.4. Removal of the Image Sensor Unit and Shutter Unit (Fig.D14) (Fig.D13)
- Page 54 9.1.3.5. Removal of the Mount, Mount Spring, Lens Ring and Mount Base Unit (Fig.D16) (Fig.D15)
- Page 55 (Fig.D19) 9.1.3.7. Removal of the Front Plate Unit (Fig.D17) 9.1.3.6. Removal of the Battery Unit (Fig.D20) (Fig.D18)
- Page 56 9.1.3.8. Removal of the Battery Door Unit 9.1.3.10. Removal of the AF LED P.C.B. and Battery P.C.B. (Fig.D21) 9.1.3.9. Removal of the Jack Cover (Fig.D23) (Fig.D22)
- Page 57 9.1.3.11. Removal of the Top P.C.B. (Fig.D25) (Fig.D24)
- Page 58 9.1.3.12. Removal of the LVF Unit (Fig.D26) (Fig.D27)
- Page 59 9.1.3.13. Removal of the LVF Module (Fig.D28) (Fig.D29)
- Page 60 9.1.3.14. Removal of the LCD Unit (Fig.D30) (Fig.D31)
-
Page 61: Disassembly And Assembly Procedure For The Lens
9.1.3.15. Removal of the Rear Operation NOTE: (When Installing) Make sure to confirm the following points when installing: FPC and Speaker • The Screw is tightened enough. • Installing conditions are fine. (No distortion, no abnormal- space.) • No dust and/or dirt on image sensor surface. (live mos) •... -
Page 62: Measurements And Adjustments
10 Measurements and Adjustments 10.1. Matrix Chart for Replaced Part and Necessary Adjustment The relation between Replaced part and Necessary Adjustment is shown in the following table. When concerned part is replaced, be sure to achieve the necessary adjustment(s). As for Adjustment condition/procedure, consult the “Adjustment Manual” which is available in Adjustment software. NOTE: After adjustments have been terminated, make sure to achieve “Initial Settings”. - Page 63 *2 NOTE: (About Simplicity flange back adjustment) When remove or turn the flange back adjustment screw, “Simplicity flange back adjustment” is necessary. When remove the flange back adjustment screw, please don’t reuse it. Use new one. [Abstract of “Simplicity flange back adjustment”] Set the camera in front of the chart and set center of the chart picture on LCD.
- Page 64 *4 NOTE: (When exchange the Main P.C.B. and/or Flash-ROM (IP6001)) After exchanging the “Main P.C.B. and/or Flash-ROM”, first, execute “Initial Settings” to determine the model suffix, and then, cancel the “Initial Settings” and proceed the adjustments. When the adjustment data is rewrite without “Initial Settings” execution, may not be able to choose desire model suffix. During the “Initial Settings”...
-
Page 65: Maintenance
11 Maintenance 11.1. Notice in External Cleaning 11.1.1. About the Body NOTE: Before cleaning the camera, remove the battery and/or disconnect power plug from the outlet. Also, remove the memory card and lens unit. 11.1.1.1. Dust/Dirt on the Outer Casing Part (S) 1. -
Page 66: Block Diagram
12 Block Diagram 12.1. Overall Block Diagram MOUNT BOX UNIT MEMORY MOS IMAGE SENSOR CARD LENS UNIT 4/3” 20 MEGA PIX (Built in AFE) (36MHz) SPEAKER LENS CONTACT SHUTTER SSWF BIS UNIT IC9101 TERMINAL UNIT X6001 SYSTEM IC (24MHz) MICROPHONE AMP ECM(L) SPEAKER AMP STEREO... -
Page 67: System Control Block Diagram
12.2. System Control Block Diagram IC9101 TOP P.C.B. (SYSTEM IC) RL9122 (REC ON L) (REC ON L) FP9003 FP7003 PIOD4 B4 IC5001 S7001 (SHUTTER0) SHUTTER0 (BIS DRIVER) RL9126 CH5006 (PON ON L) PIOA6 (FDIAL LED K) FP9003 FP7003 OUT6B RL9112 (LCD OPEN DET) IC7001 PIOA0... -
Page 68: Video/Audio Process(1) Block Diagram
12.3. Video/Audio Process(1) Block Diagram IP6001 (NAND FLASH ROM/1G-bit) CTL SIG ADDRESS/DATA J5 H6 J6 H7 B2 B3 B5 B6 B7 C3 C4 MOUNT BOX UNIT (SENSOR) IS6001 IS P.C.B. (VENUS ENGINE) R25 R24 R23 T27 T26 T25 T24 T23 P27 P24 P25 P23 N23 FL2001... -
Page 69: Video/Audio Process(2) Block Diagram
12.4. Video/Audio Process(2) Block Diagram IS6001 (VENUS ENGINE) SUB P.C.B. LCD UNIT FP9001 FP9401 FP9301 FP7201 FP7202 DISP D0-15 DISP D0-15 DISP D0-15 DISP D0-15 FP9001 FP9401 FP9301 FP7201 FP7202 (DISP HD) FP9301 FP7201 FP7202 (DISP VD) FP9301 FP7201 FP7202 CD7201 (DISP CLK) FP9301... -
Page 70: Gyro/Wi-Fi Block Diagram
12.5. Gyro/Wi-Fi Block Diagram FRONT PLATE UNIT PW D1.8V IS6001 Wi-Fi BT P.C.B. (VENUS ENGINE) Wi-Fi (W-LAN MODULE) ANTENNA (G WiFi CLK) (WiFi CLK) FP9006 FP8501 SDIO CLK (WiFi CMD) (WiFi CMD) FP9006 FP8501 SDIO CMD (WiFi DAT0) (WiFi DAT0) FP8501 FP9006 SDIO D0... -
Page 71: Flash/Hot Shoe Block Diagram
12.6. Flash/Hot Shoe Block Diagram TOP P.C.B. D7004 HOT SHOE FPC (STX) FP7002 RL7305 (EXT STB TRG) (EXT STB TRG) FP9003 FP7003 16-18 STTXD RL7306 (EXT STB DET) (EXT STB DET) FP9003 FP7003 STRXD RL7307 HOT SHOE IS6001 PW D3.15V Q7001 (VENUS ENGINE) STRTTL... -
Page 72: Lens Block Diagram
12.7. Lens Block Diagram IS6001 SUB P.C.B. (VENUS ENGINE) IC9901 (SHUTTER DRIVER) CD9901 CD9913 (SHUT MT1 B) (SHUT MT1 B) (SHUT MT1 B) FP9901 FP9402 FP9002 MOT 1B 11 OUT1B IN1B CD9902 CD9912 (SHUT MT1 A) (SHUT MT1 A) (SHUT MT1 A) FP9901 FP9002 FP9402... -
Page 73: Power(1) Block Diagram
12.8. Power(1) Block Diagram PW UNREG BATTERY P.C.B. CD1101 PW IS1.2V CD9001 CD1301 CC8101 P8101 PW D1.2V PT8101 (UNREG) CD9004 FP8101 FP9005 CD1201 BAT+ PW D3.15V (THERMO) FP8101 FP9005 BATTERY BAT THERMO 2 CD1401 CATCHER (BAT D) FP8101 FP9005 PW D3.5V BAT DET IC1441 CD9002... -
Page 74: Power(2) Block Diagram
12.9. Power(2) Block Diagram IC1031 (SYNCHRONOUS STEP-DOWN CONVERTER) PW UNREG PT1001 PVCC (PW UNREG SYS) PW D1.0V INTERNAL REGULATOR VREF VBIAS IS6001 IC6506 (VENUS ENGINE) (LOAD SW) BOOT 1 VOUT VIN PW D1.2V OVER CURRENT PW D1.0V A PVCC PROTECTION UGATE CD1031 (PW DRAM1.2V A) -
Page 75: Power(3) Block Diagram
12.10. Power(3) Block Diagram PW EVER 3V BATT THERMO PW UNREG SUB D3.0V JK2001 QR1503 CD2003 (CHARGE/USB TERMINAL) PT2001 USB VBUS IC1511 IC1510 (REGULATOR) (REGULATOR) CD2002 CD2001 IC1501 (BATTERY CHARGER) A3 B3 VDDA VREF PVBUS VDDP1 VDDP2 LX1 SYS1 VOUT VOUT BIAS CHARGE... -
Page 76: Wiring Connection Diagram
13 Wiring Connection Diagram 13.1. Interconnection Diagram /&' 81,7 5($5 ',$/ ',$/ )3& /&' ,) 3&% )2,/ 6,'( 81,7 )3 %/ %/ 3: '59 /&' 3: '59 3: '59 +27 6+2( %/ %/ 3: '59 73 ,17 73 567 67(5(2 73 6&. -
Page 77: Schematic Diagram
14 Schematic Diagram Please click the radio button for “Diagrams II / Parts List” on the menu bar in XML Service Manual. If you want to print, please click the icon button for “Print” on the icon bar and select the item. 15 Printed Circuit Board Please click the radio button for “Diagrams II / Parts List”...
