Digital Camera/Lens Kit/Double Zoom Lens Kit/Body
DMC-G7KPP
Model No.
DMC-G7KEB
DMC-G7KEC
DMC-G7KEE
DMC-G7KEF
DMC-G7KEG
DMC-G7KGC
DMC-G7KGD
DMC-G7KGH
DMC-G7KGK
DMC-G7KGT
DMC-G70KEG
DMC-G7WPP
DMC-G7WEB
DMC-G7WEC
DMC-G7WEF
DMC-G7WEG
DMC-G70WEG
DMC-G7EB
DMC-G7EC
DMC-G7EF
DMC-G7EG
DMC-G7GD
© Panasonic Corporation 2015 Unauthorized copy-
ing and distribution is a violation of law.
ORDER NO. DSC1506017CE
B26

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LUMIX DMC-G7KPP and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic LUMIX DMC-G7KPP

Summary of Contents for Panasonic LUMIX DMC-G7KPP

  • Page 1 Digital Camera/Lens Kit/Double Zoom Lens Kit/Body DMC-G7KPP Model No. DMC-G7KEB DMC-G7KEC DMC-G7KEE DMC-G7KEF DMC-G7KEG DMC-G7KGC DMC-G7KGD DMC-G7KGH DMC-G7KGK DMC-G7KGT DMC-G70KEG DMC-G7WPP DMC-G7WEB DMC-G7WEC DMC-G7WEF DMC-G7WEG DMC-G70WEG DMC-G7EB DMC-G7EC DMC-G7EF DMC-G7EG DMC-G7GD © Panasonic Corporation 2015 Unauthorized copy- ing and distribution is a violation of law.

  • Page 2: Table Of Contents

    DMC-G7GK DMC-G7HEC DMC-G7GN DMC-G7HEF DMC-G7GT DMC-G7HEG DMC-G70EG DMC-G7HGH DMC-G7HPP DMC-G70HEG DMC-G7HEB Colour [DMC-G7/G70] [DMC-G7K/G70K] (K)...Black Type (K)...Black Type (S)...Silver Type (except EB/EC/EF) (S)...Silver Type [DMC-G7H/G70H] [DMC-G7W/G70W] (K)...Black Type (K)...Black Type (except EB) (S)...Silver Type (except EB) (S)...Silver Type (only PP/EB) DMC-G7H/G70H series: Interchangeable Lens (H-FS14140) is bundled.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1.3. Leakage Current Hot Check 1. IMPORTANT SAFETY NOTICE (See Figure. 1) There are special components used in this equipment 1. Plug the AC cord directly into the AC outlet. Do not use which are important for safety. These parts are marked by an isolation transformer for this check.

  • Page 4: How To Discharge The E.capacitor On Flash P.c

    1.4. How to Discharge the E.Capacitor on Flash P.C.B. CAUTION: • Be sure to discharge the E.Capacitor on Flash P.C.B. before disassembling. • Be careful of the high voltage circuit on Flash P.C.B. when servicing. [Discharging Procedure] 1. Remove the Capacitor Cover. 2.

  • Page 5: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).

  • Page 6: How To Replace The Lithium Battery

    2.3. How to Replace the Lithium Battery 2.3.1. Replacement Procedure 1. Remove the EXT MIC P.C.B.. (Refer to Disassembly Procedures.) 2. Unsolder the each soldering point of electric lead terminal for Lithium battery (Ref. No. “B4401” at component side of EXT MIC P.C.B.) and remove the Lithium battery together with electric lead terminal.

  • Page 7: Caution For Ac Cord (For Eb/Gc

    A replacement fuse cover can be purchased from your local 2.4.2.3. How to Replace the Fuse Panasonic Dealer. 1. Remove the Fuse Cover with a screwdriver. If the fitted moulded plug is unsuitable for the socket outlet in your home then the fuse should be removed and the plug cut off and disposed of safety.

  • Page 8: Service Navigation

    3 Service Navigation 3.1. Introduction This service manual contains technical information, which allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, the information will be followed by service manual to be controlled with original service manual. 3.2.
  • Page 9 3.3.1.2. About Main P.C.B. Unit (Ref. 1) & Flash-ROM (IC6003) Important: 1. Before exchanging the “Main P.C.B. Unit”, the performances must be carefully checked, by following the “7.Troubleshooting Guide” section of this service manual. 2. Before replacing the “Main P.C.B. Unit and/or Flash-ROM”, proceed the EEPROM data backup from the unit. After replacing the Main P.C.B.
  • Page 10 3.3.2. Lens Unit (Interchangeable Lens: H-FS14140) 3.3.2.1. About Lens Main Unit (Ref. 209) 1. Lens Main Unit (Ref. 209) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “Lens Main Unit” (Ref. 209), carefully confirm its performance in advance. 2.
  • Page 11 3.3.3. Lens Unit (Interchangeable Lens: H-FS1442A) 3.3.3.1. About Lens Main Unit (Ref. 308) 1. Lens Main Unit (Ref. 308) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “Lens Main Unit” (Ref. 308), carefully confirm its performance in advance. 2.
  • Page 12 3.3.4. Lens Unit (Interchangeable Lens: H-FS45150) 3.3.4.1. About Lens Main Unit (Ref. 409) 1. Lens Main Unit (Ref. 409) is not supplied due to difficulty of the transportation issue (Fragile, Dust-free packing), and requires critical lens adjustments. Therefore, any needs of the “Lens Main Unit” (Ref. 409), carefully confirm its performance in advance. 2.

  • Page 13: Service Notes

    3.4. Service Notes 3.4.1. About Wi-Fi Function The page number in this chapter does not show the page number of this service manual.
  • Page 14 3.4.2. Important Notice of Servicing This camera unit has the personal information of wireless LAN connection the customer has registered. For the protection of private information, please erase the personal information after the completion of repair by “Initial Settings”. In addition, please print out the following documents, and pass to the customer with the camera unit. Printing Material [Leaflet for Customer] [For The Customer] Before using your camera please check the Wi-Fi settings.

  • Page 15: General Description About Lead Free Solder (Pbf)

    3.5. General Description About Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin (Sn), silver (Ag) and copper (Cu), and the melting point of the lead free solder is higher approx.30°C (86°F) more than that of the normal solder.

  • Page 16: How To Define The Model Suffix (Ntsc Or Pal Model)

    3.6. How to Define the Model Suffix (NTSC or PAL Model) There are nine kinds of DMC-G7/G70 (Camera body unit), regardless of the colours. • a) DMC-G7 (Japan domestic model) • b) DMC-G7PP • c) DMC-G7EB/EC/EF/EG, G70EG • d) DMC-G7EE •...
  • Page 17 3.6.2. Initial Settings: After replacing the Main P.C.B. Unit and/or Flash-ROM, make sure to perform the initial settings after achieving the adjustment by ordering the following procedure in accordance with model suffix of the unit. 1. Important Notice: Before proceeding Initial settings, make sure to read the following CAUTION. 2.
  • Page 18 • Step 4. Display the Initial Settings: While pressing [ MENU/SET ] button and “[ RIGHT ] of Cursor buttons” simultaneously, turn the power off. The “Initial Settings” menu is displayed. There are two kinds of “Initial Settings” menu form as follows: [ CASE 1.
  • Page 19 • Step 5. Choose the Model Suffix in “Initial Settings”: (Refer to “CAUTION”) [Caution: After replacing the Main P.C.B. Unit and/or Flash-ROM] The model suffix can been chosen, JUST ONE TIME. Once one of the model suffix have been chosen, the model suffix lists will not be displayed, thus, it can not be changed. Therefore, select the area carefully.

  • Page 20: Specifications

    4 Specifications 4.1. Camera Body The following specification is based on DMC-G7EB/G7HEB/G7KEB/G7WEB. Some specifications may differ depending on model suffix.

  • Page 25: Lens

    4.2. Lens...

  • Page 26: Location Of Controls And Components

    5 Location of Controls and Components The following description is for DMC-G7EB/G7HEB/G7KEB/G7WEB. Some descriptions may differ depending on model suffix. The page number in this chapter does not show the page number of this service manual. 5.1. Camera Body...

  • Page 27: Lens

    5.2. Lens...

  • Page 28: Service Mode

    6 Service Mode 6.1. Error Code Memory Function 1. General Description This unit is equipped with history of error code memory function, and can be memorized 16 error codes in sequence from the latest. When the error is occurred more than 16, the oldest error is overwritten in sequence. The error code is not memorized when the power supply is shut down forcibly.
  • Page 29 Error Code List The error code consists of 8 bit data and it shows the following information.
  • Page 30 Important Notice about “Error Code List” About “*” indication: The third digit from the left is different as follows. - In case of 0 (example: 2B001000) When the third digit from the left shows “0”, this error occurred under the condition of Initial Settings has been completed. It means that this error is occurred basically at user side.

  • Page 31: Troubleshooting Guide

    7 Troubleshooting Guide 7.1. Checking Method of Body and Interchangeable Lens...

  • Page 37: Wi-Fi Circuit (Flash P.c.b.)

    7.2. Wi-Fi Circuit (Flash P.C.B.) 7.2.1. How to Remove Wi-Fi Password Protection To prevent incorrect operation or use of the Wi-Fi function by a third party and to protect saved personal information, this unit pro- tects the Wi-Fi function with a password. It is unable to service with password locked condition.

  • Page 38: Service Fixture & Tools

    8 Service Fixture & Tools 8.1. Service Fixture and Tools The following service fixture and tools are used for checking and servicing this unit. About Name Ring Fixture: • RFKZ0507 for H-FS45150 About Adjustment Shaft: • VMS7941 for H-FS1442A...

  • Page 39: Clean Box

    8.2. Clean Box • The repair quality is considered, and it is recommended working in the environment of specified clean level less than class 10,000 (Federal Standard 209D). [NOTE] • Work in the environment of specified clean level less than class 10,000 (Federal Standard 209D) when inside cleaning of a lens. Please refer to the following service manuals.

  • Page 40: Service Position

    8.4. Service Position This service position is used for checking and replacing parts. Use the following extension cables for servicing. Table S1 Extension Cable List Parts No. Connection From RFKZ0564 FP9003(MAIN)←→REAR PLATE UNIT 23pin / 0.3 FFC RFKZ0477 FP9301(MAIN)←→LCD HINGE UNIT-FP7201(LCD IF P.C.B.) 45pin / 0.3 FFC CAUTION.

  • Page 41: Disassembly And Assembly Instructions

    9 Disassembly and Assembly Instructions 9.1. Camera Body Part Disassembly Flow Chart 9.1.1. This is a disassembling chart. When assembling, perform this chart conversely. P.C.B. Location 9.1.2.
  • Page 42 Disassembly Procedure 9.1.3. Item Fig. Removal Hinge SW FPC Unit, (Fig. D15) Screw (O) x 2 LCD Unit 1 Screw (P) x 1 Item Fig. Removal FPC Tape Rear Case Unit (Fig. D1) Screw (A) x 4 (Fig. D16) Rear Arm Cover Screw (B) x 4 Screw (Q) x 2 (Fig.
  • Page 43 9.1.3.1. Removal of the Rear Case Unit (Fig. D2) (Fig. D1)
  • Page 44 9.1.3.2. Removal of the Main P.C.B. Unit 9.1.3.3. Removal of the Top Unit and Flash P.C.B. (Fig. D4) (Fig. D3)
  • Page 45 (Fig. D6) (Fig. D5)
  • Page 46 (Fig. D8) 9.1.3.4. Removal of the Battery Frame Unit (Fig. D7) (Fig. D9)
  • Page 47 (Fig. D12) 9.1.3.6. Removal of the Battery Plate (Fig. D10) 9.1.3.5. Removal of the Mount Box Unit (Fig. D13) (Fig. D11)
  • Page 48 9.1.3.7. Removal of the Battery Door Unit (Fig. D14) 9.1.3.8. Removal of the Hinge SW FPC Unit and LCD Unit 1 (Fig. D15) (Fig. D16)
  • Page 49 9.1.3.9. Removal of the LCD IF P.C.B. and LCD Unit (Fig. D17) (Fig. D18)
  • Page 50 9.1.3.10. Removal of the Speaker and Rear Plate Unit (Fig. D20) (Fig. D19)
  • Page 51 9.1.3.11. Removal of the LVF Unit 1 (Fig. D22) 9.1.3.12. Removal of the LVF Module (Fig. D21) (Fig. D23)
  • Page 52 9.1.3.14. Removal of the Flash (Fig. D24) 9.1.3.13. Removal of the EXT MIC P.C.B. (Fig. D26) (Fig. D25)

  • Page 53: Disassembly And Assembly Procedure For The Lens

    (Fig. D28) NOTE: (When Installing) Make sure to confirm the following points when installing: • The Screw is tightened enough. • Installing conditions are fine. (No distortion, no abnormal- space.) • No dust and/or dirt on image sensor surface. (live mos) •...

  • Page 54: Measurements And Adjustments

    • Inspect it, not only corresponding part is replaced, but also camera body is shocked and/or dropped. • The Panasonic camera body in accordance with the Micro Four Thirds system (marketed commodity: operates normal) and a standard zoom lens H-FS014045 (marketed commodity: operates normal) is required as a reference machine.
  • Page 55 *4 NOTE: ( AVCHD function inspection) • Confirm self recording/playback motion picture of AVCHD mode by the LCD. • Confirm it on the TV with HDMI socket when repair HDMI relation. * There are no LCD adjustment model. *5 NOTE: (When AWB adjustment) •...

  • Page 56: Maintenance

    11 Maintenance 11.1. Notice in External Cleaning 11.1.1. About the Body NOTE: Before cleaning the camera, remove the battery and/or disconnect power plug from the outlet. Also, remove the memory card and lens unit. 11.1.1.1. Dust/Dirt on the Outer Casing Part (S) 1.

  • Page 57: Block Diagram

    12 Block Diagram 12.1. Overall Block Diagram MOUNT BOX UNIT MOS IMAGE SENSOR LENS UNIT 4/3” 16M pix MEMORY (Built in AFE) CARD (27MHz) LENS CONTACT SHUTTER X6001 SPEAKER SSWF TERMINAL UNIT (48MHz) ECM(L) STEREO MICROPHONE IC9101 ECM(R) SYSTEM IC Q9901 MICROPHONE IC4401...

  • Page 58: System Control Block Diagram

    12.2. System Control Block Diagram IC9101 TOP OPERATION FPC (SYSTEM IC) FP9001 PW D3.15V 19,29 (LED PWR OUT) (LED PWR OUT) FP9001 (Green) POWER LED LEDOUT0 LEDOUT3 (AFLED Cathode) (LED AF OUT) FP9001 AF LED LEDOUT2 FP9001 PW D5.0V (LED WiFi OUT) (LED FN K) (Blue) FP9001...

  • Page 59: Video/Audio Process(1) Block Diagram

    12.3. Video/Audio Process(1) Block Diagram IC6003 CTL SIG ADDRESS/DATA (NAND FLASH ROM/1G-bit) 7 8 9 16 17 18 19 MOUNT BOX UNIT IC6001 (SENSOR) (VENUS ENGINE) R25 R24 R23 T27 T26 T25 T24 T23 P23 P24 P27 R26 P26 FL2001 JK2002 (G HDMI D2+) SENSOR P.C.B.

  • Page 60: Video/Audio Process(2) Block Diagram

    12.4. Video/Audio Process(2) Block Diagram IC6001 (VENUS ENGINE) FLASH P.C.B. MAIN FLASH FPC (W-LAN MODULE) Wi-Fi ANTENNA (G WiFi CLK) (WiFi CLK) FP9002 FP8501 SDIO CLK (WiFi CMD) (WiFi CMD) FP9002 FP8501 SDIO CMD (WiFi DAT0) (WiFi DAT0) FP9002 FP8501 SDIO D0 (WiFi DAT1) (WiFi DAT1)

  • Page 61: Video/Audio Process(3) Block Diagram

    12.5. Video/Audio Process(3) Block Diagram HINGE FPC LCD IF P.C.B. FP9301 FP7201 FP7203 BUS54 EVF0-15 BUS54 EVF0-15 IC6001 (VENUS ENGINE) FP9301 FP7201 FP7203 (BUS54 EVFVD) (VSYNC) FP9301 FP7201 VSYNC FP7203 (BUS54 EVFHD) (HSYNC) FP9301 FP7201 HSYNC FP7203 (CLK54 EVF) (PCLK) PCLK FP9301 FP7201...

  • Page 62: Lens Block Diagram

    12.6. Lens Block Diagram MOUNT BOX UNIT IC9101 (SSWF UNIT) PW D5.0V (SYSTEM IC) Q9801 FP9004 SSWF OUT FP9004 (SSWF OUT0) UNREG GND SSWF0OUT T9801 (SSWF OUT1) SSWF1OUT IC6001 MOUNT BOX UNIT (VENUS ENGINE) (LENS CONTACT TERMINAL) FP9010 LEN4R2V PW LEN4.2V ( LSDET) FP9010 LSDET...

  • Page 63: Flash/Hot Shoe Block Diagram

    12.7. Flash/Hot Shoe Block Diagram PW D3.15V IC6001 D8002 (VENUS ENGINE) HOT SHOE FPC QR8004 (STX) FP9006 RL7108 12-14 (STB TRG) (TXD) STTXD FP9006 RL7106 QR8001 (RXD) STRXD FP9006 RL7107 HOT SHOE PW D3.15V (TTL) STRTTL FP9006 RL7110 Q8001 QR8002 FP9006 V50EXFL RL7109...

  • Page 64: Power(1) Block Diagram

    12.8. Power(1) Block Diagram PW UNREG CL1101 FLASH P.C.B. PW D1.2V 1 CL1001 CC8502 CC9001 CL1081 P8501 F8501 (UNREG) FP8501 FP9002 BAT+ 27-33 PW SD3.15V (THERMO) FP8501 FP9002 CL1201 BAT THERMO 2 BATTERY CATCHER CC8501 CC9002 BAT DET PW D3.15V IC1001 (UNREG GND) FP8501...

  • Page 65: Power(2) Block Diagram

    12.9. Power(2) Block Diagram IC1091 (SYNCHRONOUS STEP-DOWN CONVERTER) PW UNREG F1002 PVCC (PW UNREG SYS) PW D1.0V INTERNAL REGULATOR VREF VBIAS IC6001 IC6506 (VENUS ENGINE) (LOAD SW) BOOT 4 VOUT OVER CURRENT PW D1.0V A PVCC PROTECTION PW D1.2V UGATE CL1091 (PW DRAM1.2V A) UNDER &...

  • Page 66: Wiring Connection Diagram

    13 Wiring Connection Diagram 13.1. Interconnection Diagram BATTERY FP4401 Wi-Fi FPC STEREO MICROPHONE HOT SHOE FLASH P.C.B. RL8504 (COMPONENT SIDE) RL8503 EXT MIC P.C.B. : (FOIL SIDE) RL8502 RL8501 (FOIL SIDE) LVF MODULE DRIVE SW FPC HOT SHOE FPC FLASH TOP OPERATION FPC UNIT MAIN-FLASH FPC...

  • Page 67: Schematic Diagram

    14 Schematic Diagram Please click the radio button for “Diagrams II / Parts List” on the menu bar in XML Service Manual. If you want to print, please click the icon button for “Print” on the icon bar and select the item. 15 Printed Circuit Board Please click the radio button for “Diagrams II / Parts List”...
