- Page 1 Instruction manual The installation of this product must be made by a qualified professional.
- Page 2 11 • Technical features Term of warranty TARAMPS, located on Julio Budisk Highway, SN, KM 30 – Alfredo Marcondes, SP - Brazil, ZIP CODE 19180-000, guarantees this product against any defects on terms of project, making, assembling, and/or with solidarity, due to project vices which cause it improper or inadequate to its original use within 12 months from the date of purchase.
-
Page 3: Safety Requirements
CAUTION injury to user or product damage. Taramps reserves the right to modify the contents of this document at any time without prior notice and does not have the obligation to apply the changes in units which were previously produced. -
Page 4: Installation Procedure
Installation Procedure 1 - Follow all procedures described below; 2 - If you do not follow the proper procedures by qualified professionals, Taramps is exempled of any responsibility; 3 - Insulate completely all system connections, this avoiding electrical contact with the vehicle chassi;... - Page 5 Functions, input & output GAIN MONITOR SPEAKER 1 - INPUT: Connect to the RCA output of the Head Unit using good quality shielded cables to avoid noise pickup. The signals from the L and R inputs are mixed (added) internally. 2 - OUT: This output can send the same input signal (INPUT) to another amplifier.
-
Page 6: Power Supply Connector
Power supply connector 12VDC HIGH VOLTAGE 1 - 12.6 VDC POSITIVE TERMINAL (1.5A): Use an exclusive 12.6V battery and relay (driven by the remote signal from Head Unit. See diagram at the page 06) . 2 - POWER +: Positive power input for high voltage. POWER -: Negative power input for high voltage. - Page 7 VEHICLE ORIGINAL BATTERY Cable RCA EÍCULO Taramps To avoid electrical shock in the bodywork of the vehicle, it is extremely turn off the two circuit breakers before connecting the system batteries in the HIGH VOLTAGE series. Turn on them again only when all system is turned off.
-
Page 8: Charging The Battery Bank
As an example in the images we indicate the Taramps LED 90 source. It is expressly mandatory to use a 40A fuse or circuit breaker on the positive output of each battery. - Page 9 Examples of connectio 1: Installation together to HV 20,000 CHIPEO - 13 Batteries 21mm² IT IS MANDATORY INSTALLATION OF CIRCUIT BREAKERS - 70A 21mm² HIGH VOLTAGE IT IS MANDATORY INSTALLATION OF CIRCUIT BREAKER - 32A NOTE: In the case of drivers or tweeters, it is essential to install a passive filter on their positive terminal (Consult the manufacturer's manual).
- Page 10 Examples of connectio 2: Installation together to HV 40.000 CHIPEO 18 Batteries 130A 130A IT IS MANDATORY INSTALLATION OF CIRCUIT BREAKERS - 130A 21mm² 130A 21mm² HIGH VOLTAGE IT IS MANDATORY INSTALLATION OF CIRCUIT BREAKER - 32A NOTE: In the case of drivers or tweeters, it is essential to install a passive filter on their positive terminal (Consult the manufacturer's manual).
- Page 11 Examples of connectio 3: Installation together to HV 80.000 CHIPEO 24 Batteries 130A 130A 130A 21mm² IT IS MANDATORY INSTALLATION OF 130A CIRCUIT BREAKERS - 130A 21mm² HIGH VOLTAGE IT IS MANDATORY INSTALLATION OF CIRCUIT BREAKER - 32A NOTE: In the case of drivers or tweeters, it is essential to install a passive filter on their positive terminal (Consult the manufacturer's manual).
-
Page 12: Technical Features
Os valores citados são típicos e podem sofrer pequenas variações devido a tolerância de componentes ou do processo de fabricação. Para maiores informações ou em caso de dúvidas acesse nosso site ou entre em contato com o suporte da TARAMPS ELECTRONICS. - Page 13 Manufactured by : TARAMPS ELECTRONICS LTDA CNPJ / TAX ID: 11.273.485/0001-03 Street João Silvério, 121 • Res. Manoel Martins Alfredo Marcondes - SP Made in Brazil...
