WA913 User Manual

publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means,

electronic, mechanical, photocopying, recording or otherwise, without the prior written permission of

SMARTSAFE.

Neither SMARTSAFE nor its affiliates shall be liable to the purchaser of this unit or third parties for

damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: Accident,

misuse, or abuse of this unit, or unauthorized modifications, repairs, or alterations to this unit, or failure to

strictly comply with SMARTSAFE operating and maintenance instructions. SMARTSAFE shall not be

liable for any damages or problems arising from the use of any options or any consumable products

other than those designated as Original SMARTSAFE Products or SMARTSAFE Approved Products by

SMARTSAFE.

All information, specifications and illustrations in this manual are based on the latest information

available at the time of printing. SMARTSAFE reserves the right to make changes at any time without

prior written or oral notice.

Trademark Information

is a registered trademark of SHENZHEN SMARTSAFE TECH CO.,LTD. in China and other

countries. All other SMARTSAFE trademarks, service marks, domain names, logos, and company

names referred to in this manual are either trademarks, registered trademarks, service marks, domain

names, logos, company names of SMARTSAFE or are otherwise the property of SMARTSAFE or its

affiliates. In countries where any of the SMARTSAFE trademarks, service marks, domain names, logos

and company names are not registered, SMARTSAFE claims other rights associated with unregistered

trademarks, service marks, domain names, logos, and company names. Other products or company

names referred to in this manual may be trademarks of their respective owners. You may not use any

trademark, service mark, domain name, logo, or company name of SMARTSAFE or any third party

without permission from the owner of the applicable trademark, service mark, domain name, logo, or

company name. You may contact SMARTSAFE by visiting the website at www.newsmartsafe.com, or

writing to SHENZHEN SMARTSAFE TECH CO.,LTD., 3310, Building 11, Tianan Cloud Park, Bantian

Street, Longgang District, Shenzhen, Guangdong, China, to request written permission to use Materials

on this manual for purposes or for all other questions relating to this manual.

To avoid personal injury, property damage, or accidental damage to the product, please read all the

information in this chapter before using the product.

Table of Contents

Need help?

Do you have a question about the WA913 and is the answer not in the manual?

Questions and answers

Summary of Contents for SmartSafe WA913

Page 1 SMARTSAFE. Neither SMARTSAFE nor its affiliates shall be liable to the purchaser of this unit or third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: Accident, misuse, or abuse of this unit, or unauthorized modifications, repairs, or alterations to this unit, or failure to strictly comply with SMARTSAFE operating and maintenance instructions.
Page 2  After the vehicle maintenance is completed, all loosened bolts and components need to be checked and tightened as required to ensure safety.  Do not install the WA913 wireless touchless wheel aligner on a vibrating object or a tilted surface. Avoid direct sunlight and moisture.
Page 3: Table Of Contents
WA913 User Manual Table of Contents 1. Packing List .............................. 1 2. Overview ..............................3 2.1 Product Introduction ......................... 3 2.2 Features and Characteristics ......................3 2.3 Technical Parameters ........................4 2.4 Operating Environment Requirements .....................4 2.5 Instructions for Use ...........................5 3.
Page 5: Packing List
WA913 User Manual 1. Packing List The following list is for reference only. The configuration of the product varies for different markets, for details, please consult your local dealer or check the packing list that comes with the product. Main Unit and Accessories...
Page 6 WA913 User Manual Power Adapter - Charging Dock (12V 10A) Power Adapter - ST13 (12V 5A) ST13 Intelligent Link Terminal Installation Positioning Sticker Packing list Quick Reference Guide User Manual...
Page 7: Overview
2. Overview 2.1 Product Introduction WA913 Wireless Touchless Wheel Aligner is mainly used to measure the relative positions and angles between car wheels in order to determine the wheel alignment parameters. This guides automobile maintenance technicians in adjusting the wheel alignment parameters to meet the requirements of automobile design, ensuring smooth and safe driving, reducing fuel consumption and tire wear.
Page 8: Technical Parameters
WA913 User Manual 2.3 Technical Parameters Vehicle Specifications Supported Wheelbase: 2150~3700 mm Track width: 1430~1900 mm Wheel diameter: 590~880 mm Tire width: 165~325 mm Measurement parameters Measurement range Measurement error Total toe-in ±20 ±0.08 Toe-in ±10 ±0.04 Camber ±10 ±0.04 Caster ±20...
Page 9: Instructions For Use
WA913 User Manual 2.5 Instructions for Use The coordinated operation diagram of the WA913 wireless touchless wheel aligner is shown in Figure 2.1. The whole system is mainly composed of the data acquisition section and the ST13 intelligent link terminal.
Page 10: Instrument Structure
3. Instrument Structure 3.1 Overall Structure The WA913 wireless touchless wheel aligner is mainly composed of measuring units (front right/front left/rear right/rear left), calibration units (middle right/middle left), and charging bases (right/left). ST13 intelligent link terminal, turntable (optional), steering wheel fixing bracket (optional), and brake pedal fixing bracket (optional) are combined with a standard four-post lift (optional).
Page 11: Charging Base
Rubber Pad 3.4 Charging base The WA913 wireless touchless wheel aligner has 2 charging bases (including a left charging base used to store the middle left calibration unit + rear left measuring unit + front left measuring unit, and a right charging base used to store the middle right calibration unit + rear right measuring unit + front right measuring unit).
Page 12: Four-Wheel Alignment Operation Steps
WA913 User Manual 4. Four-Wheel Alignment Operation Steps 4.1 Preparations 4.1.1 Use of Positioning Sticker The product comes with positioning stickers to assist with the installation of the equipment. Attach the positioning sticker about 1cm away from the surface of the lift platform and ensure that the positioning sticker is parallel to the surface of the lift platform.
Page 13 WA913 User Manual Figure 4.2 4.2.1 Vehicle Selection Click on the Four-wheel Alignment icon on the main interface to enter the routine four-wheel alignment detection interface, and firstly select the vehicle. According to the information of the vehicle to be detected, select the Region -> Brand -> Model -> Year ->...
Page 14 WA913 User Manual Screen button instructions are as follows: Clicking this button allows you to quickly view equipment status, battery level, network connection signal, and other information (when all devices are online, the icon is displayed in green ; when there is a low battery level, the icon is displayed in orange ;...
Page 15 WA913 User Manual Figure 4.5 Screen button instructions are as follows: This function is used to customize the configuration information. Click Modify Configuration to enter the following interface: Modify Configuration Figure 4.6 After modifying the parameter value, click Save and enter the configuration name in the pop-up window, and then click OK to save the modified configuration to the custom database.
Page 16 WA913 User Manual If you need to modify the model information of custom data, you can click Car info Editor to modify the corresponding information and then click SAVE. Figure 4.8 Cancel: Cancel editing and return to the vehicle information confirmation interface.
Page 17 WA913 User Manual Select a vehicle again according to Region -> Brand -> Model -> Year -> Reselect Configuration. Confirm car Confirm vehicle information and enter the vehicle inspection interface. 4.2.2 Vehicle Inspection Figure 4.10 Complete vehicle tire inspection, tread and tire pressure inspection, vehicle height measurement, and chassis inspection, and enter relevant inspection information, then click Next to enter the Measurement interface.
Page 18 WA913 User Manual 4.2.2.2 Tire tread and pressure inspection After completing the tread and tire pressure inspection, click on the corresponding input box on this interface to enter the detection value. Under the Tread Depth option, you can click on the “+” or “-” to increase or decrease the input box to correspond to the number of grooves for different types of tires (2 to 5).
Page 19 WA913 User Manual Figure 4.13 4.2.2.4 Chassis Inspection Inspect the vehicle chassis according to the on-screen prompts and add relevant pictures (up to 5) and notes. Select corresponding options indicate status each component (Normal/Warning/Repair). After completing the chassis inspection, click Next to enter the Measurement interface.
Page 20 WA913 User Manual 4.2.3.1 Fixture Installation Figure 4.15 Click Fixture installation and install the relevant fixtures according to the on-screen instructions. 1) Align the front wheels of the vehicle to the center of the turntable. 2) After parking the vehicle steadily on the lift, install the wheel chocks on the rear wheels to prevent sliding.
Page 21 WA913 User Manual Note: It is recommended to install the matched positioning sticker on the side of the lift axle plate in advance to assist with the installation of the equipment. 1) Align the FR measuring unit with the front right tire of the vehicle, with the upper edge of the magnetic suction head aligned with the positioning sticker on the side of the lift axle plate, and turn the power on after magnetically attaching it to the side of the lift axle plate.
Page 22 WA913 User Manual Figure 4.18 4.2.3.3 Measurement Scanning After the equipment is installed, click Next to enter the measurement scanning interface. Confirm all measuring units and calibration unit icons display Connected before clicking Start Calibration. Figure 4.19 After completing the calibration, the measuring unit and calibration unit icons will display Ready.
Page 23 WA913 User Manual Figure 4.20 After the equipment calibration is completed, click on Start measurement to perform inclination measurement. After the inclination measurement is completed, switch to the Kingpin Measurement interface. Figure 4.21 4.2.4 Kingpin Measurement Kingpin measurement is specific to front wheels, including kingpin inclination and caster. The kingpin inclination angle can distribute the vehicle weight evenly on the bearings, protecting them from damage and making the steering force uniform and steering light.
Page 24 WA913 User Manual 4.2.4.1 Measurement Preparations Prepare the following according to the on-screen prompts: 1) Install the brake lock. 2) Remove the steeling wheel pin. 3) Remove the side-slip plate pin. After the preparation is completed, click [Next] to enter the "Kingpin Measurement" interface.
Page 25 WA913 User Manual gradually). When the wheel angle reaches or exceeds the set angle (12 degrees), the system will prompt you to turn the steering wheel in the opposite direction. Figure 4.24 3) Follow the on-screen prompt to steadily and gradually turn the steering wheel. When the wheel angle reaches or exceeds the set angle (12 degrees), the system will prompt you to return the steering wheel to the initial position.
Page 26 WA913 User Manual Figure 4.26 After the kingpin measurement is completed, switch to the Results interface. Note: If the lift shakes or is lifting a vehicle, please click the button to perform global calibration. 4.2.5 Results This function is used to view and save measurement results. The displayed by default are the "Global"...
Page 27 WA913 User Manual 4.2.6 Report This function is used to view, save, and share detection reports. On the right side of the screen, you can click to view the four-wheel alignment, before and after maintenance, before maintenance, current value, symmetrical value, chassis inspection, tire inspection, and body height inspection reports.
Page 28: Quick Inspection
WA913 User Manual Figure 4.30 Click Print report to print the current detection report or save the report as a PDF document. Figure 4.31 Click Complete the test and save the report to save the detection report on the tablet. You can click Inspection Records on the main interface to query and manage all saved reports.
Page 29 WA913 User Manual Figure 4.32 Follow the on-screen instructions to complete the steps of fixture installation, device installation, measurement scanning, etc. After completing the inclination measurement, go to the Results interface. 4.3.2 Results This function is used to view and save measurement results. The displayed by default are the global measurement results.
Page 30: Inspection Records
WA913 User Manual 4.3.3 Report This function is used to view, save, and share detection reports. On the right side of the screen, you can click to view the inspection reports for four-wheel alignment, before and after maintenance, before maintenance, current value, symmetrical value, etc.
Page 31 WA913 User Manual Figure 4.35 Clicking on a single record allows you to view the details of the inspection report, and you can also share and print the inspection report. Figure 4.36 Click Edit to manage the detection report.
Page 32: Database
WA913 User Manual Figure 4.37 Screen button instructions are as follows: View Details View the details of this detection report. Select All Select all expanded detection reports. Delete Delete the selected detection report. Share the selected detection report, only one report can be shared at a Share Report time.
Page 33 WA913 User Manual Figure 4.38 In the standard database, select the vehicle by Region -> Brand -> Model -> Year -> Configuration (you can quickly search by entering the corresponding keywords in the search box at the top of the screen) and enter the Car info interface to view the corresponding vehicle's parameter information.
Page 34 WA913 User Manual Figure 4.40 Figure 4.41 Click Modify configuration to modify the corresponding parameter values as needed, then click Save. In the pop-up dialog box, enter the configuration name and click OK to save the modified configuration as a custom configuration.
Page 35 WA913 User Manual Figure 4.42 Figure 4.43 4.5.2 Custom Database In addition to the standard database provided by the system, users can also add custom data to manually add vehicle model information that is not available in the standard data, making the system more suitable for maintenance station applications.
Page 36: Device Management
WA913 User Manual Figure 4.44 Screen button instructions are as follows: View Details View the details of this custom data. Edit configuration Used to select and delete single or multiple custom data. New configuration Used to add new custom data.
Page 37: System Settings
WA913 User Manual Screen buttons and display item descriptions are as follows: Equipment name Used to identify and distinguish different equipment. and identification When the equipment is not connected to the Internet, the icon is displayed in Connection status gray. After the equipment is connected to the Internet, the icon turns blue and displays the network signal strength.
Page 38 WA913 User Manual Figure 4.46 4.7.2 Customer Information Click Customer Info on the left side of the screen to enter the customer information management interface. Figure 4.47 Click on a single customer information, edit the corresponding information in the pop-up window, and...
Page 39 WA913 User Manual Figure 4.48 Click Edit, then select the checkbox in front of the customer information and click Delete, click OK in the pop-up dialog to delete the selected customer information. Figure 4.49 Figure 4.50 After clicking on Add, enter the corresponding customer information in the pop-up window, and then click...
Page 40 WA913 User Manual Figure 4.51 4.7.3 Shop info Click Shop info on the left side of the screen to enter the shop information management interface. Click Edit, then edit the corresponding store information, click Save to save the new shop information.
Page 41 WA913 User Manual Figure 4.53 Click on the language you want to switch to, and then click OK in the pop-up dialog to restart the application and switch to the new language. Figure 4.54 4.7.5 About Click About on the left side of the screen to the following interface, here you can check the application...
Page 42: Terms
WA913 User Manual Figure 4.55 Click Upgrade, the system will check for new application versions and upgrade the application to the latest version. 4.8 Terms Four-wheel alignment angle refers to the relative angle between the suspension system and various moving components. Maintaining the correct four-wheel alignment angle ensures the stability of the vehicle's movement and reduces tire wear.
Page 43 WA913 User Manual 4.57. The different angles can change the contact point and force point between the tire and the ground, directly affecting the tire's grip and wear condition, and changing the distribution of weight on the axle, avoiding abnormal wear of the bearings. In addition, the existence of the camber can be used to counteract the angular changes caused by the deformation of the suspension system components and the clearance between the moving surfaces after the vehicle body is subjected to loads.
Page 44 WA913 User Manual force between the vehicle weight and the ground will generate a large lateral shear stress on the axle, which can easily damage the axle and make the steering heavy. In addition, the kingpin inclination is also the source of the steering return force of the front wheels. The kingpin inclination has been set at the beginning of the vehicle suspension design and is usually non-adjustable.
Page 45 WA913 User Manual Figure 4.61 Figure 4.62 4.8.7 Thrust angle Thrust angle is defined as a angle formed by the bisector (thrust line) of the total toe-in angle of the rear wheels and the geometric centerline (see Figure 4.62). It is generally specified that the value is positive when the thrust line is leftward and negative when the thrust line is rightward.
Page 46 WA913 User Manual Figure 4.64 Figure 4.65 4.8.10 Track width difference Track width difference refers to the angle formed by the line connecting the front left wheel and the contact point with the ground, and the line connecting the rear left wheel and the contact point with the ground (also known as the wheel track width deviation).
Page 47 WA913 User Manual 4.8.13 Delay (angle) The relative offset in the longitudinal direction of a car between the two wheels on the same axle is referred to as "delay". When the right wheel on the front (rear) axle is behind the left wheel, the front (rear) delay is a positive value;...
Page 48: Warranty
For any problem met during the operation, please call +86-0755-89589810. If the device needs to be repaired, please send it back to SmartSafe, and attach the Warranty Card, Product Qualification Certificate, Purchase Invoice and problem description. SmartSafe will maintain and repair the device for free when it is within warranty period.
