ELCART LiFud LF-GSD150YV024A Manual

ART. 13/22270-00
Product Description
LF-GSD150YV024A is a 150W constant voltage tunable white LED driver supporting DALI or PUSH dimming. Its
input voltage ranges from 220 to 240Vac; rated output voltage: 24V; rated current: 6.25A. It features high
efficiency, low THD and flicker-free effect. It is suitable for indoor LED strips.
Features
IP20

Suitable for Class II light fixtures

Built-in active PFC function

Supports DALI DT8 dimming + PUSH dimming, dimming depth <0.1%

Flicker free

Small size; high efficiency (typical value ≥92%）

All-round protections: over voltage protection, over load protection, short circuit protection

5-year warranty (please refer to the warranty condition.)

Applications
LED strip

Luminous character

Light box

Naming
LF - GSD 150 YV 024A
www.lifud.com | Technical support: China (HQ): +86 755 8373 9299
ELCART DISTRIBUTION SPA via Michelangelo Buonarroti, 46 - 20093 Cologno Monzese (Milano) ITALY
Tel. +39 02.25117310 Fax +39 02.25117610 sito internet: www.elcart.com e-mail: tecnico@elcart.it
La divulgazione dei dati contenuti in questa scheda è da ritenersi un servizio puramente informativo e non costituisce alcun vincolo da parte della Elcart in merito a prestazioni ed utilizzo del prodotto.
The divulgation of data contained on this technical sheet are exclusively for informational reasons and establish no link on behalf of Elcart regard to the performances and the use of the product.
La divulgacion de los datos contenidos en esta ficha son un servicio unicamente informativo y no constituyen ningun vinculo de parte de Elcart respecto a las prestaciones y uso del producto.
ELCART
Manuale di istruzioni/Scheda tecnica
LF-GSD150YV024A
DALI-2 0.1% Dimming Depth Flicker-free LED Driver
024A: DC24V output; A: DALI DT8
YV: constant voltage series
150: rated power: 150W
G: isolated design; SD: DALI LED driver
PAGINA 1 DI 8
1
