Page 1 CLIMATE CONTROL BY RADIO Instruction Manual www.the-imcgroup.com...
Page 2 Issue No. Issue Date Changes 11 Jan 2002 First Issue 2 Feb 2004 All sections revised to reflect new CCR30 PCB design 5 Feb 2004 Section 4 revised to reflect new steamer unit 3 Jun 2004 Section 1.2.2 revised 16 Aug 2005 Section 1.1.1 battens added from wall securing.
Page 3: Table Of Contents
Table of contents Introduction Contact Hanwell Installing Siting the CCR30 Location Clearances & Access Requirements Connecting the Water Supply Supply Water Characteristics Mains Water Connection Water Tank Connection Connecting the Power Supply Connections on the PCB / to the OCB...
Page 4 Steamer Maintenance Replacing the steamer cylinder Technical Specification Mechanical Specification Temperature Range Humidity Range Power Requirement Measurement Range (Control Sensor) Measurement Accuracy (Control Sensor) Humidifier Dehumidifier Hot Gas Defrost Option www.the-imcgroup.com...
Page 5: Introduction
Introduction The CCR30 combines a Humidifier, a Dehumidifier and a radio control system into one unit, actuated by signals from Hanwell Temperature/RH telemetry units. • Both the humidity set point and the required dead band are adjustable by the user.
Page 6: Installing
Siting the CCR30 Location The CCR30 should be stood on either a solid floor or a secure shelf. It should never be positioned above or below anything of value. There are two holes in the back panel to allow the unit to be secured firmly: no weight should be taken on these, they are purely to prevent toppling.
Page 7: Connecting The Water Supply
In order for the system to function, there must always be a supply of tap water in the Feed Tank and the Drain Tank must not be completely full. If the Feed Tank runs dry or the Drain Tank is full a float switch will operate and the CCR30 will switch off until the problem is rectified.
Page 8: Connecting The Power Supply
The sump tank must be fitted below the CCR30 unit, e.g. under floor, or behind a wall sitting on a shelf directly under the CCR30. However the waste pipe from the CCR30 must not be kinked or run uphill in order to get to the sump tank.
Page 9: Connections On The Pcb / To The Ocb
Connections on the PCB / to the OCB The power connection from the mains terminal block to the control PCB is pre-wired. However the connection details are included in the diagram (Figure 2) below for your reference. The mains in cable fitted should be in accordance with Electrical rules and regulations and be capable of supporting a 1.5KW electrical load.
Page 10: Operation
55% and the deadband is set to +/-3%. The CCR30 has been designed to work with a local sensor unit to ensure reliability of radio reception regardless of the position of the receiver, and without an obtrusive aerial.
Page 11: Trouble Shooting
Otherwise the red Led will stay on close to full time as the modem continues to attempt network logon. Running the software on a machine that is also running another Hanwell USB application may cause erratic results as the USB Drivers are shared, shut down the other application.
Page 12: Setting Dead Band
ON. See example (right, white square indicates switch position). Setting RH set Point The RH Set Point is the Relative Humidity value the CCR30 required, within the possible range 10% to 80%RH. The factory default set point is 55%. Example...
Page 13: Setting The Sensor Id
Setting the Sensor ID The Sensor ID is the station number of the telemetry sensor which is intended to control the CCR30. Once set, the CCR30 will only receive signals from that sensor. This is set using binary code. Example To set the Sensor ID to 105: 1.
Page 14 • If the RH reading is below the RH setpoint + deadband, the Humidifier will come on (indicted by LED D8). Air will be drawn through the front vent and expelled, with the addition of water vapour from the steamer, from the top vent. •...
Page 15: Maintenance
Maintenance The CCR30 should be regularly maintained to ensure optimum operation. Regular checks are particularly important in hard water areas where it is essential that adequate water filtering is provided. The following schedules are recommended. Monthly Maintenance It is advisable to check the unit on a monthly basis to ensure the unit is operating safely and is leak free.
Page 16: Sump Tank Units
Replace the tank unit cover making sure that the Earth lead does not become trapped (it should lie between the 2 Tanks). 10. Turn the power back on to both the Tank Unit and the CCR30. Normal operation (see section 2.2) will resume as soon as a radio signal is received.
Page 17: Humidifier Steamer Operation Maintenance
The Steamer PCB is mounted on the CCR30 PCB, accessed via the left hand panel. The steamer Cylinder is mounted next to the humidifier in the main area of the CCR30. It is accessed via the front panel of the CCR30.
Page 18: Alarm Conditions
Steamer operation will stop. Resolve the problem. If the alarm condition is listed as automatic, the unit will be automatically rest. If the alarm condition is listed as manual, reset the steamer by switching off the CCR30 then restarting it. •...
Page 19 RED LED Type/reset Description Causes Solution Indication 2 Long Warning/ Cylinder Cylinder depleted Switch of CCR30 and Manual depleted replace Cylinder 3 Long Disabling/ Lack of supply Fill pipe blocked Switch off CCR30 and Manual water check the fill pipe for...
Page 20 Remove the left hand access panel on the CCR30. Press the drain switch on the CCR30 control PCB, as shown in figure 3. Switch off and isolate the mains supply to the CCR30 and allow the steamer unit to cool. Remove the front access panel of the CCR30.
Page 21 Technical Specification Mechanical Specification Case Height: 760mm Case Width: 1150mm NB 250mm FREE SPACE IS REQUIRED TO THE LEFT OF THE UNIT FOR CONTROL ACCESS Case Depth: 258mm Weight kg: 70kg Case Material: Powder coated steel Electrical Connection: 13amp 3-core Mains cable enters through 22mm cable gland under left of unit and connects to internal screw terminal block Unit should ideally be supplied from a readily accessible 10A fused and switched spur.
Page 22 Humidifier Type: Open electrode boiler Feed water pressure: 1…10bar Max. inlet Temperature: 50°C Inlet water conductivity: 125…150µS/cm Instantaneous max. inlet capacity: 0.6 litres/minute Instantaneous max. outlet capacity: 1.6 litres/minute Humidification Performance: 2kg/hour max. (100%, 75%, 50%, 25% selectable) Dehumidifier Refrigerant: R407C Delay Start Timer: Built-in Fan: Centrifugal, 550m3/hour Current consumption: 3.4A...
Page 23 Contact T: +44 (0)1462 688070 W: the-imcgroup.com The IMC Group Limited Pendle House Jubilee Road Letchworth Hertfordshire SG6 1SP Intelligent monitoring and control solutions: In Buildings | In Transit | Outdoor/Remote...
