Riverside TouchTek 4.0 Technician Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
TouchTek 4.0
Technician Manual
1
Rev 9.14.16

Advertisement

loading
Need help?

Need help?

Do you have a question about the TouchTek 4.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Riverside TouchTek 4.0

  • Page 1 TouchTek 4.0 Technician Manual Rev 9.14.16...
  • Page 2 Copyright Copyright Copyright © 2015. Riverside MFG LLC. All rights reserved. No part of this publication may be reproduced, transmitted in any form, transcribed, or stored in a retrieval system, without prior written consent from Riverside. This software product, including the manual and media, is copyrighted and contains proprietary information that is subject to change without notice.

  • Page 3: Precautions And Warnings

    All operators MUST read and understand the warnings and precautions prior to using this product. Riverside MFG LLC is not responsible for injuries, damages, or issues resulting from the failure to observe the precautions, warnings, and instructions in this manual. This product is safe if used in accordance with the guidelines set forth in this manual.
  • Page 4 General Specifications: Operating Voltage - 9 to16VDC Operating Temperature - -40 to +80 C Current Draw Ignition Off - Less than10 mA Max Relay Current Output - Six 20Amp Max Total System Current - 120Amp Key features of the TouchTek Control System: * Compact size * Adjustable LED backlighting and sunlight readable status indicator * Switch backlight changes from blue for off to red for on conditions...

  • Page 5: Installation

    Installation Power Distribution Center Horizontal Mini I/O Orientation Figure 1 Figure 2 is built with a rugged, weather resistant enclosure. It should be Power Distribution Center mounted using zinc plated ¼-20 bolts and washers (not included) through each of the four notches in the flanges of the extruded enclosure.
  • Page 6 Figure 4 The overlay on the power distribution center shows a circuit diagram to aid with install and configuration. All outputs are set to a default of latching, to change to momentary flip the dip switch for desired output to on position. Switch 7: Second switch panel.
  • Page 7 6 Button Switch Panel Installation Figure 5 The panel is recommended to be installed with 3/8” #6 Phillips head sheet metal screws or machine screws with nuts and washers (not included). Securely fasten but do not over torque. The end cap can then be installed with the #4 black machine screws. The end brackets seal up against a foam gasket but the 6 Button Switch Panel is not waterproof.

  • Page 8: Optional Mounting

    The assembly (Part Number: 15767) can be ordered from Riverside Manufacturing and includes mounting hardware, two ball mounts, a short 4” adjustable arm, and on an anodized aluminum back plate specifically for the 6 Button Switch Panel.
  • Page 9 Interlocks The TT4.0 has two interlocks, neutral and brake. The neutral interlock is enabled with switch #8. Switch number #8 is located on the 12-station DIP switch located on the PDC circuit board. The neutral governs output #2. When enabled by switch #8 the output #2 (controlled by button #2) will only function if the neutral input is held low (less than 4 volts).
  • Page 10 Insert sheet 270-8700 **Additional options available upon request Rev 9.14.16...
